Hy-Gain MK-80 Manuale utente

GENERAL DESCRIPTION PACKING LIST

The Hy-Gain MK-80 add on kit contains • 5 hose clamps all

of the necessary parts and instructions

to make a Hy-Gain 14AVQ vertical • 10 36" spokes (2 extra) resonate on 80

meters. The 80-meter kit • Loading coil assembly features stainless steel hardware

and

hose clamps. The loading coil is wound • 18 4-40 screws (2 extra)

onto a 1 inch fiberglass tube using #14 • 18 4-40 kep nuts (2 extra)

Teflon insulated wire for extended life.

The antenna is capable of 1 KW PEP on , 1 1/8" X 17" aluminum tube 80-

meters. secure the MK-80 to an existing AV

1. Remove the parts from the 14AVQ antenna. See Figure 1.

packaging. Check to see that each is

present using the packing list above. 6. Place four capacitance spokes into

each of the spoke rings located on the

2. Place a 4-40 screw in each of the 16 loading coil assembly and secure holes on the

capacitance spoke rings them in place by tightening the 4-40 and secure them using a

4-40-kep screws.

nut. Refer to figure 1. Snug each one

using a 5/16" nut driver. Be careful

not to lose the screws and nuts.

3. Place the large end of the 1 1/8" X

17" aluminum tubing over the end of

the loading coil assembly tube as

shown in Figure 1.

4. Secure the tubing in place with one of

the supplied hose clamps. Be sure to

place the connection tab between the

aluminum tubing and the clamp as

shown in Figure 1.

5. Place the remaining hose clamp onto the

aluminum tube. This clamp is used to

SETUP

already on the antenna, remove it.

Refer to Figure 1.

The AV

14AVQ should be assembled and

tuned using the instructions supplied with

the

antenna. The following section

describes the

preparations for the installation of the MK-

80 to

the AV-14AVQ.

PREPARATION

1. Assemble

the antenna using the supplied

instructions. Figure 1 on

page 4 of the

AV-14AVQ manual

gives approximate

dimensions.

2. In addition to normal assembly, hose

clamps need to be

placed above each

of the black covers on the traps.

These will provide extra strength to

the traps for the additional weight of

the MK-80.

a. Place one of the hose clamps

supplied

with the MK-80 directly

above the

black ABS cover of trap 11-

10.

Figure 1 on page 4 shows

the

location of this trap.

b. Place one of the hose clamps

supplied

with the MK-80 directly

above the

black ABS cover of trap 14-

15.

Figure 1 on page 4 shows

the

location of this trap.

c. Place one of the hose clamps

supplied

with the MK-80 directly

above the

black ABS cover of trap 15-

20.

Figure 1 on page 4 shows

the

location of this trap.

d. Do not place tubing section M5

onto the antenna. If this section is

3. Place the assembled MK-

80 onto the

assembled AV-14AVQ antenna. The

1/8" x

17" tubing has been fitted to

accept the AV-14AVQ.

4. Secure the tubing in place by

tightening

the hose clamp placed on the MK-

in step 5 of the assembly section.

5. Follow the instructions given to

choose a

mounting location for the

antenna.

NEVER IN

STALL AN ANTENNA

NEAR POWER LINES.

TUNING

Place the antenna in its final operating location

for tuning. Connect an SWR

analyzer to the

antenna with a suitable

length of 50 Ohm coax.

An SWR meter and

radio may be used instead

of an analyzer.

10,15,20 METERS

Tune the AV-

14AVQ according to the

instruction manual. Figure 1 on page 4

gives the dimensions for operation on 10,

15, and 20 meters. Remember to start

with

the 10 meter band.

40 METERS

The antenna length above the 20 Meter

trap is the frequency ad

justment for 40

below for proper tuning. Follow the

steps

below for proper tuning. Never cut

the

capacitance spokes on the rounded ends.

Check the resonance of the antenna on

the

40 Meter band. The SWR should be

at a

minimum near 7 MHz or below.

2. To raise the operating frequency cut

small

lengths such as 1/4 inch lengths

from each of

the four 40 Meter spokes.

Check the

resonance point again.

Continue the previous steps until the desired

frequency is reached.

80 METERS

The 2:1 band-with on 80 mete

rs is

approximately 40KHz. The top

capacitance

spokes are adjusted to

change the resonant

frequency on 80 meters. Cutting the

four

upper capacitance spokes will raise

the

resonant frequency. Follow the steps

below

for proper tuning. Never cut the

capacitance spokes on the rounded ends.

1. Check the resonance of the antenna

on the 80 Meter band with the spokes

installed.

The SWR should be at a

minimum near 3.5 MHz.

2. To raise the operating frequency cut

small lengths such as '/4

inch lengths

from each of the four 80 Meter

spokes.

Check the resonance point again.

Continue the previous steps until the desired

frequency is reached.

SERVICE INFORMATION

If you have a problem you are unable to

resolve or if you need to order

replacement

parts, you should contact the Hy-

Gain

Customer Service Department.

You should fully research your problem

by going through this manual before you

contact the Customer Service Department.

You should retain your sales receipt or

other proof of purchase for items that are

still under warranty.

All requests, inquires, warranty claims, or

for ordering replacement parts, you

should contact:

Hy-Gain

308 Industrial Park Road

Starkville, MS 39759 USA

Tel: 662-323-9538

Fax: 662-323-6551

NOTES:

gain®

LIMITED WARRANTY

hy-gain Warrants to the original owner of this product, if manufactured by hy-gain

and

purchased from an authorized dealer or directly from hy-gain

to be free from defects in

material and workmanship for a period of 12 months for rotator products and 24 months

for

antenna products from date of purchase provided the following terms of this warranty

are

satisfied.

1. The purchaser must retain the dated proof-of-purchase (bill of sale, canceled check,

credit

card or money order receipt, etc.) describing the product to establish the

validity of the

warranty claim and submit the original or machine reproduction of such proof-of-

purchase

to hy gain at the time of warranty service. hy-gain shall have

the discretion to deny

warranty without dated proof-of-purchase.

Any evidence of alteration, erasure, or forgery

shall be cause to void any and all warranty terms immediately.

2. hy-gain agrees to repair or replace at hy-gain's option without charge to the original

owner

any defective product under warranty, provided the product is returned postage

prepaid to

hy-gain with a personal check, cashiers check, or money order for $8.00

covering postage

and handling.

3. Under no circumstances ishy-gain liable for consequential damages to person or property by

the use of anyhy-gain products.

4. Out-of-warranty Service: hy-gain will repair any out-of-warranty product provided

the unit

is shipped prepaid. All repaired units will be shipped COD to the owner. Re

pair charges will

be added to the COD fee unlessother arrangements are made.

5. This warranty is given in lieu of any other warranty expressed or implied.

6. hy-gain reserves the right to make changes or improvements

in design or manufacture

without inc

urring any obligation to install such changes upon any of the products previously

manufactured.

7. All hy-gain products to be serviced in-warranty or out-of-warranty should be

addressed to hy gain, 308 Industrial Park Road, Starkville,

Mississippi 39759, USA and must be accompanied by a letter describing the

problem in detail along with a copy of your dated proof-of-purchase.

8. This warranty gives you specific rights, and you may also have other rights which vary from

state to state.
