Hyco Accona Scheda tecnica

Product Instruction Manual

Accona

Panel Heater

AC500T, AC1000T, AC1500T,

AC2000T, AC24000T

v24.1.4

Overview

Thank you for purchasing an Accona Panel Heater. A xed heating solution, available in 0.5,

1.0, 1.5, 2.0 and 2.4 kW models. These are suitable for application in both home and oce

environments.

Please read and follow these instructions to ensure that installation and operation are as

simple and safe as possible.

This appliance should only be installed and maintained by a competent person in

accordance with any local electrical regulations.

This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

Children of less than 3 years should be kept away unless continuously supervised.

Children aged from 3 years and less than 8 years shall only switch on/o the

appliance provided that it has been placed or installed in its intended normal

operating position and they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the hazards involved.

Children aged from 3 years and less than 8 years shall not plug in, regulate, and

clean the appliance or perform user maintenance.

Some parts of this appliance can become very hot and cause burns. Particular

attention has to be given where children and vulnerable people are present.

In order to avoid overheating, do not cover the heater.

If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualied persons in order to avoid a hazard.

Important Safety Points

The appliance must be permanently connected to the electrical supply through an

appropriately rated isolating switch with a contact separation in all poles.

This appliance must be earthed.

Only connect the appliance to an electrical supply that meets the specication

detailed on the rating label.

The appliance must not be located immediately below a socket outlet.

Select a location for the appliance ensuring the mounting surface is suitable for the

weight and heat of the appliance.

This appliance is not designed for outdoor use or use in very damp environments.

If the appliance is located in a bathroom, it must be installed so that switches and

other controls cannot be touched by a person in the bath or shower.

The appliance is only intended for horizontal installation, re risk exists if installed

in any other orientation.

Ensure there are no hidden cables or pipework before commencing any drilling.

To avoid overheating risk, ensure minimum clearances are observed when installing

the appliance (see diagram 1).

Diagram 1

Wall Mounting

1. Installation

Min 300 mm

Min 150 mm

Do not install the appliance in very dusty environments. Dust can burn as

it passes over the heating element and adhere to the outer surface and

immediate surroundings of the appliance, leading to permanent marking.

Model AC500T AC1000T AC1500T AC2000T AC2400T

‘L’ value 155 mm 155 mm 250 mm 250 mm 250 mm

• Drill the two ‘L’ holes as marked in the previous step and insert 2 wall plugs and

screws. Leave at least 5 mm of exposed thread to hang the appliance onto.

• Assemble the two brackets supplied, as shown in diagram 1, to the rear of the

appliance. Once in place, secure the brackets using the supplied screws.

• Fit the spacer onto the rear of the appliance (see diagram 3). The rear of the spacer

has hooks that engage into the corresponding slots of the appliance as it is pushed

down.

• Hang the appliance on the screws by locating them into the centre of the two

corresponding top brackets and then sliding the appliance down, right and down

(see diagram 4).

Diagram 2 Diagram 3

• Mark the two ‘L’ holes as shown in diagram 2. The distance between the centres of the

holes are model dependent, consult the table for the specic model being tted.

Diagram 5

• Fit the nal xing bracket via the air inlet grilles located on the underside of the

appliance (see diagram 5).

• Slide the xing bracket along the air inlet grille until it contacts ush to wall. Mark

the hole requirement on the wall and then remove the appliance by reversing the

movement in the earlier step.

• Drill the hole and insert a wall plug.

• Return the appliance to the wall and insert the nal screw into the xing bracket to

complete the wall mounting.

Diagram 4

Start position

End position

Fixing bracket

end position

Fixing bracket

start position

Spacer Spacer

2. Electrical Connection

If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualied persons in order to avoid a hazard.

The appliance must be permanently connected to the electrical supply through an

appropriately rated isolating switch with a contact separation in all poles.

This appliance must be earthed.

Only connect the appliance to an electrical supply that meets the specication

detailed on the rating label.

The appliance must not be located immediately below a socket outlet.

• Make connections as below;

- Green/ yellow earth wire to terminal marked or ‘E’

- Brown live wire to the terminal marked‘L’

- Blue neutral wire to the terminal marked ‘N’

3. Controls

Number Description

1 On/ o

2 Full / half power mode

3 Element on indicator

4 Half power

5 Full power

6 Open window detection

7 Manual mode active

8 Automatic mode active

LCD Display

Number Description

9 Run on timer mode

10 Up

11 Down

12 Manual/ auto mode select

13 Time (HH:MM)

14 Target temperature*

15 Set select

16 Ok select

* primarily represents target temperature however, where referenced it displays current segment/

child lock active.

4. Preparing the Appliance

Setting the Time and Date

• Switch the power supply to the appliance on.

• Turn the appliance on using the rocker switch on the right hand side of the appliance.

A blue light will be illuminated above to the on/ o button.

• Press the button and the LCD display will now be illuminated.

• The appliance will time out if no button is pressed within 4 seconds and the

process will need to be restarted. Take time to read through each section before

performing each task.

• When setting the time and day it is essential to ensure that ONLY the day of the week

is ashing e.g. MON and no other icons. Press OK to exit and restart if required.

• Press OK rst (keep holding this down) followed by SET and hold both until the

appliance beeps.

• The day of the week will ash. Use the arrows to select the day and press SET

to conrm.

• The hour will ash. Use the arrows to select the hour and press SET to conrm.

• The minutes will ash. Use the arrows to select the minutes and press SET to

conrm or leave to time out.

• During the setting process use SET when conrming the day/ hour/ minute required. Do

NOT press OK as this will exit the process and you will need to restart.

Switching the Appliance On

To see a video for setting the time and date scan this QR code.

Setting the Target Temperature

• Use the arrows to set the target temperature. The temperature display will

briey ash, when it stops ashing it is now set and ready to use.

• To change the target temperature at any time, use the arrows.

Manual Mode

• Manual mode is the simplest way to use your appliance. No timers are running.

The thermostat will control the heating element to reach and maintain the target

temperature.

• Select manual mode by pressing until the M (manual) icon is displayed.

Nb. Setting the time and date is not essential for M (manual) mode.

Run on Timer Mode

• Whilst in manual mode it is possible to control the length of time the appliance

operates for using a run on timer function. This is most convenient if you require the

appliance to turn itself o after a period of time.

• Select manual mode by pressing until the M (manual) icon is displayed.

• Press SET to enter the run on timer programming screen.

• The hour, day of week and icon will ash (see section 3. Controls).

• Use the arrows to select the hour for the appliance to turn o and press SET.

• The minutes will ash. Use the arrows to select the minutes for the appliance

to turn o.

• Once the desired hour and minute for the appliance to stop heating are displayed,

press OK to conrm.

• The appliance will now display the icon to conrm run on timer mode is active.

• Run on timer mode will be cleared if the appliance is switched o.

Selecting the Operating Mode

• On rst power on the appliance will default to manual mode, M will be illuminated.

• To select your chosen operating mode press to choose either M (manual) or A

(automatic).
