HYPERTECH®

POWER PROGRAMMER III™

FOR 5.7L LT1/LT4 CAMARO/FIREBIRD/CORVETTE

IMPALA SS/CAPRICE/ROADMASTER

STEP-BY-STEP INSTALLATION

INSTRUCTIONS

PP2

Part #895

7.7.06

TABLE OF CONTENTS

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Section 1: PowerStat™Installation . . . . . . . . . . . . . . . . . . . . .4

Section 2: Programming Instructions . . . . . . . . . . . . . . . . . . 6

Engine Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Rev Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Electric Cooling Fan Operating Range . . . . . . . . 9

Top-Speed Limiter . . . . . . . . . . . . . . . . . . . . . . . 10

Tire Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Rear Gear Ratio . . . . . . . . . . . . . . . . . . . . . . . . 11

Transmission Shift Point MPH & RPM . . . . . . 12

Transmission Shift Firmness . . . . . . . . . . . . . . . 15

Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Section 3:

Programming Back To Stock/Changing Options

Section 4: Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . 19

IMPORTANT

• The Power Programmer for GM LT1/LT4 vehicles is legal

for sale or

use on California pollution-controlled motor vehicles according

to the

CARB Executive Order process. In the interest of improved air quality,

the California Air Resources Board (CARB) requires new vehicle and

manufacturers of aftermarket parts to develop engine and emissions

equipment that either reduce or maintain specific air pollutants affected

by vehicle use. Both the California Vehicle Code (section 27156) and

Federal Clean Air Act (administered by the Environmental Protection

Agency) prohibit modifications that increase vehicle emissions.

Aftermarket parts manufacturers, particularly in the high-performance

segment, are required to obtain CARB approval in the form of executive

Orders (E.O.s) for any product not qualifying as a direct replacement

for an original equipment part. Hypertech includes meeting all E.O.

requirements in its product development process. This guarantees

that users of Hypertech “Power Tuning” products will meet certification

requirements when registering, selling, or needing to pass various

emissions tests or Inspection and Maintenance (I&M) programs

administered by state or local enforcement agencies. Make sure

that any emissions-related product you buy and install carries an E.O.

number or is pending an E.O. Without this verification you are at

risk, in potential violation of regulations and may incur unnecessary

financial obligations during vehicle inspections or emissions tests.

A CARB E.O. sticker is supplied. Keep this sticker in your vehicle or

attach it inside the door jam as proof that the Power Programmer is

street legal.

• Your vehicle’scomputer will not be programmed at the end

of the programming menus until you select “PRESS ‘Y’ TO

BEGIN PROGRAMMING” on page 15. Feel free to experiment

with the programming choices without the fear of accidentally

programming the wrong thing into your vehicle computer.

You can make any choice that you want to, change it again

and again, without programming it into your vehicle computer

until you are absolutely ready.

•While the programmer is programming:

*DO NOT leave the vehicle while programming is in process.

*DO NOT program your vehicle without a fully charged battery.

If after you have programmed your vehicle’s computer with the

Hypertech Power Programmer, you decide to change the tuning,

It is recommended that you recharge your vehicle’sbattery.

You may either drive the vehicle to charge the batteryor use a

batterycharger.But either way,MAKE surethat the battery

holds a full charge.

*DO NOT disturb the cable while programming.

*The ONLYtime you may remove the programmer cable from

the DLC safely is PRIOR to pressing ‘Y’ to program your

entries. However, any programming choices you have made

WILL NOT be saved. NOTE: It is NOT safe to unplug the

programmer cable any time AFTER you have pressed ‘Y’ to

program.

*DO NOT turn the key off UNLESS

instructed by the programmer.

*DO NOT start the engine.

Any of these actions will interrupt the programming process.

The programmer is designed to recover from these conditions,

but they should be avoided.

• You will achieve best performance if you replace your

stock thermostat with a Hypertech 160° or 180° PowerStat.

The programmer will work with a stock thermostat but our

best performance tuning was specifically developed for a

cooler running engine.

• Hypertech Power Tuning was developed for premium grade

gasoline (the highest octane rating available in your area).

Make sure you have premium gasoline in your vehicle

before installing Hypertech’s engine Power Tuning.

HYPERTECH POWER PROGRAMMER III

INSTALLATION INSTRUCTIONS OVERVIEW

Congratulations! You are the owner of the Power Programmer III,

the latest in high-performance tuning technology. Now you can optimize

your engine’s tuning, as well as adjust other vehicle parameters

(see table of contents), all at the touch of a button.

Your vehicle has an onboard computer that controls the engine

and transmission. Inside your vehicle’scomputer is a FLASH

memory chip which contains the vehicle’s programming. The

programmer actually reprograms this FLASH computer chip,

according to your specifications, with Hypertech’s Power Tuning.

This is the only way an individual can reprogram some 1994-1995

and all 1996 and newer vehicles sold in the United States.

To reprogram your vehicle’s computer, simply plug the

programmer cable into the vehicle’s diagnostic connector

located under the dash panel on the driver’s side. Set the parking

brake. Next, turn the ignition key to RUN but do not start the

engine. Press the sarrow on the programmer.It will then identify

your vehicle and display a series of options on its screen. When

completed, turn the key to OFF and disconnect the cable from the

diagnostic connector.Now you’re ready to Feel the Power!

Hypertech’s Power Tuning can be stored in only one (1)

vehicle at a time. The Power Programmer can be reconnected

to remove the Power Tuning and return the vehicle to the factory

programming at any time. After you have performed this step,

your vehicle will be in its stock configuration.

You may also reconnect your programmer at any time to change

the programming. For example, if you have replaced your factory

tires with different diameter tires, you will want to correct your

speedometer, odometer, and automatic transmission shift points.

Simply reconnect your programmer, answer the necessary option(s),

and reprogram your vehicle. You do not have to return to stock first.

SECTION 1: POWERSTAT INSTALLATION

Tools and supplies required

8mm socket and ratchet

1/4” flathead screwdriver

DEX-COOL anti-freeze coolant (GM part #1234-6290)

Part#1008 - 160° PowerStat

Part #1022 - 180° PowerStat

See Figures A or B. Disconnect the intake air temperature sensor

connector located in the air intake duct between the mass air

flow sensor and the throttle body.

2. Use a flathead screwdriver to loosen the clamps on the air

intake duct and remove the duct.

3. With the radiator cap on, remove the two (2) thermostat

housing bolts. Remove the thermostat housing leaving the

radiator hose attached to expose the stock thermostat. A small

amount of coolant may be lost at this point.

4. Lift out the stock thermostat. Use a screwdriver to gently pry,

if necessary. Clean all the sealing surfaces.

5. Make sure that the rubber “O” ring is positioned flat side

down on the PowerStat. Next, install the PowerStat, making

sure that it’s positioned correctly (spring end facing down into

intake manifold).

6. Reinstall the thermostat housing and bolts. Torque the bolts to

7ft.-lbs.

7. Remove the radiator cap (or coolant reservoir cap on

Corvette). Place a rag or towel under the pressure side bleed

screw on the thermostat housing to prevent coolant from

splashing on the distributor. Open the pressure side bleed

screw while watching the coolant level in the radiator (or

coolant reservoir on Corvette). The coolant level will drop

when the bleed screw is fully opened.

8. Slowly fill the radiator with the DEX-COOL coolant. Close

the bleed screw when the bubbles disappear and only coolant

is escaping from the bleed screw.At this point, finish filling

the radiator and reinstall the radiator cap.

IMPORTANT:

NEVER MIX ORDINARYANTI-FREEZE (GREEN)

WITH THE DEX-COOL ANTI-FREEZE (ORANGE)

OR YOU MAYDAMAGE THE COOLING SYSTEM.

•

WARNING: NEVER ATTEMPT TO CHANGE

A THERMOSTAT ON A HOT ENGINE

•

SERIOUS INJURY CAN OCCUR IF THE

RADIATOR CAP IS REMOVED WHILE THE

COOLING SYSTEM IS HOT

•

THE ENGINE SHOULD ALWAYS BE COLD

WHEN INSTALLING THE POWERSTAT

NOTE: After installing the

PowerStat, if any coolant

needs to be added to the

vehicle, make sure you

put the same color coolant

back into the vehicle. If

your vehicle has orange

coolant, replace with orange

coolant. If green, replace

with green.

9. Reinstall the mass air flow sensor side of the air intake duct.

To install the throttle body side of the duct, use the flathead

screwdriver to secure the lower side of the duct onto the

underside of the throttle body, then work the sides and the top

of the duct onto the throttle body assembly.

10. Tighten the hose clamp using the flathead screwdriver.

11. Reconnect the intake air temperature sensor connector.

12. Start the vehicle and allow it to warm up to normal operating

temperature.

13. Check the coolant level in the radiator overflow/fill reservoir

and fill as needed.

Figure A

Throttle

body

Thermostat

housing

Pressure side

bleed screw

Mass air

flow sensor

CAMARO/FIREBIRD/IMPALA SS/CAPRICE/

ROADMASTER POWERSTAT INSTALLATION

CORVETTE POWERSTAT INSTALLATION

Figure B

Throttle

body

Thermostat

housing

Mass air

flow sensor

Pressure side

bleed screw

SECTION 2: PROGRAMMING INSTRUCTIONS

• Connect one (1) end of the provided cable to the black plastic

adapter using the thumbscrews as in Figure C. Connect the

other end of the cable to the programmer as shown in Figure D,

and tighten the thumbscrews.

•Connect one (1) end of the provided cable to the programmer

as in Figure E and tighten the two (2) thumbscrews.

• See Figure F. Locate the Data Link Connector (DLC) under the

driver’s side of the dash panel near the driver’s right knee.

Figure F

Figure E

Programmer

FOR 1994 CAMARO/FIREBIRD AND

1994-1995 IMPALA SS/CAPRICE/ROADMASTER:

FOR ALL OTHER LT1/LT4 VEHICLES:

Data link cable

Data link

adapter

Programmer

cable

Programmer

Figure D

Figure C

Thumbscrew

•

Plug the programmer cable (or adapter) into the DLC. Make sure

the cable is plugged in completely to ensure a good connection.

• Set the parking brake and turn the ignition key to the RUN

position but do not start the engine.

IMPORTANT:

-DO NOT leave the vehicle while programming is in process.

-Make sure the vehicle battery is fully charged before programming.

-The key must remain in the RUN position, without the engine

running, during the entire programming process..

-DO NOT operate electrical accessories

(radio, windows, wipers, etc.) while programming.

-DO NOT attempt programming while the

vehicle is connected to a batterycharger.

• Press the sarrow on the programmer. The following displays

should appear immediately on the LCD screen (where X.X.X.X

is the version number):

•If these screens do not appear, for 1994-1997 LT1/LT4 vehicles

make sure that both ends of the cable are securely attached

and press the sarrow again. For 1994-1995 LT1 vehicles,

check and/or replace the battery as described in #6 of the

Troubleshooting Guide.

• Next, the programmer will show applications and copyright

information. Then, a screen similar to this should appear with

adescription of your vehicle:

•If this screen does not appear, make sure that the key is in the

RUN position with the engine NOT running.

YOUR VEHICLE IS:

1996 CHEVROLET CAMARO 5.7L LT1

VERSION

X.X.X.X

HYPERTECH

POWER PROGRAMMER

SYSTEM TEST

WAIT

FOR XXXX-XXXX

LT1/LT4 VEHICLES

• The programmer will display a series of options. For each

option, press the ‘Y’ button to make a change. Press the ‘N’

button to make no change and proceed to the next option. For

some options, you will use the sand tarrows to point to a

particular option. Pressing the ‘Y’ button will then lock in your

selection. For example, use the sand tarrows to select your

top-speed limiter, then press the ‘Y’ button to lock in your choice.

A. ENGINE TUNING

• Press the ‘Y’ button to install engine tuning. Press ‘N’ to keep

the stock vehicle tuning.

B. REV LIMITER

• Press ‘N’ to keep the stock engine rev limiter. Making this

choice will skip to the next option.

• Press ‘Y’ to adjust the engine rev limiter to a value other than

stock. The stock rev limiter may vary depending on year and

engine size of the vehicle. Please refer to the owner’s manual

for the stock engine rev limiter.

• Press the sand tarrows to increase or decrease the engine

rev limiter.The rev limiter can be increased or decreased in

100 RPM increments. Press ‘Y’ to lock in the desired value.

NOTE: At any time, you may press ‘N’ to allow you to either

try again or skip to the next option.

PRESS Y TO INSTALL HYPERTECH POWER TUNING

PRESS N TO KEEP FACTORY ENGINE TUNING

PRESS Y TO ADJUST ENGINE REV LIMITER

PRESS N TO KEEP STOCK ENGINE REV LIMIT

USE UP/DOWN ARROWS TO ADJUST ENGINE REV LIMITER, THEN PRESS Y TO SELECT OR N TO EXIT.

_ _ _ _RPM

C. ELECTRIC COOLING FAN OPERATING RANGE

•Press ‘N’ if you do not wish to change the temperature at which

the electric cooling fans turn on and turn off.

• Press ‘Y’ if you want to lower the temperature at which the

electric cooling fans turn on and turn off, even with the stock

thermostat. A cooler combustion chamber will produce more

power. By making this selection, you will now go to the next

screen to pick the operating temperature range of the cooling

fans. This screen will appear:

• Use the sand tarrows to select between optimizing the

cooling fan temperature settings for:

180°Hypertech PowerStat

Fans on/off at: 213°F/205°

160° Hypertech PowerStat

Fans on/off at: 192°F/185°F

Stock Cooling Fan Temperatures:

Fans on/offat: 240°F/225°F

USE UP/DOWN ARROWS TO SELECT THERMOSTAT TEMP, THEN PRESS Y TO SELECT OR N TO EXIT.

_ _ _F

PRESS Y TO PROGRAM ENGINE COOLING FAN TEMPERATURE RANGE

PRESS N TO LEAVE COOLING FAN TEMPERATURE UNALTERED

Altri manuali per POWER PROGRAMMER III

Indice

Altri manuali Hypertech Accessori per automobili

Hypertech

Hypertech 2000 Manuale utente

Manuali Accessori per automobili popolari di altre marche

James Baroud

James Baroud Odyssey Manuale utente

Motorola

Motorola i50sx Manuale utente

Yakima

Yakima 9MM STANDARD BIKE MOUNT Manuale utente

Feniex

Feniex T3 Manuale utente

Renault

Renault 77 11 423 180 Manuale utente

Kia

Kia E8300-4D000 Manuale utente

Brink

Brink 756843 Manuale utente

Whispbar

Whispbar K085W Manuale utente

v.link

v.link CI-VL2-PC-HSD Manuale utente

Viking

Viking Stack-Rack Guida rapida alla configurazione

Aries

Aries 203015 Manuale utente

Choetech

Choetech AT0005 Manuale utente

ZZ2

ZZ2 ZZAIR-PRO Manuale utente

Holman

Holman 4A80L Manuale utente

Thule

Thule 2075 Manuale utente

Motorola

Motorola T325 Manuale utente

TAUBENREUTHER

TAUBENREUTHER 16-3950 Guida all'installazione

DV8

DV8 FBJL-02 Manuale utente
