Hytera PNC380 Manuale utente
1. Product Overview
Hytera Communications Corporation Limited
Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan
District, Shenzhen, People's Republic of China
2. Before Use
2.1 Installing the SIM Card and SD Card
1. Slide the battery latch to and remove the battery cover.
2. Remove the battery.
3. Open the card slot cover.
4. Put the card into corresponding slot.
2.2 Attaching the Battery
Use the approved battery to avoid the risk of explosion.
Dispose of the used battery according to “Precautions for Disposal” in the Safety Information
Booklet.
Attach the battery as shown below, then press the cover into place and slide the battery latch to the lock
position.
2.3 Charging the Battery
Use the approved charger to charge the battery.
Read the Safety Information Booklet before charging.
The remaining lithium-ion battery power is limited to 30% pursuant to the new lithium battery
shipment regulation approved by International Air Transport Association (IATA).
To charge the battery, connect the terminal to the power adapter, power bank, or computer with the USB
cable.
To determine the charging status, check the battery icon or percentage shown on the LCD display.
To ensure optimum waterproof and dustproof performance, close the USB port cover after charging the
terminal.
2.4 Attaching the Belt Clip
Attach the belt clip as shown below.
2.5 Attaching the Audio Accessory
Open the cover of the audio accessory connector and insert the audio accessory into the connector.
To ensure optimum waterproof and dustproof performance, close the cover after removing the audio
accessory.
3. Operation
3.1 Powering the Terminal On or Off
To power on the terminal, press and hold the key.
To power off the terminal, press and hold the key, and
select
Power Off.
3.2 Adjusting the Volume
To increase the volume, press + key.
To decrease the volume, press – key.
3.3 Turning the Screen On or Off
To turn off the screen when it is on, press the SK key.
To turn on the screen when it is off, press the SK key, Emergency Alarm key or any key on the keypad.
3.4 Using Flashlight
To turn the flashlight on or off when the screen is on, press and hold the key.
3.5 Setting the Shortcut Key
SK key is the programmable key of the terminal. For enhanced convenience, you can go to to
select Programmable key to set the key as the shortcut of certain functions.
3.6 Connecting to the Internet
You can connect to the Internet by using the cellular network or WLAN network.
To connect to the cellular network, install the SIM card and activate the cellular data service.
To connect to the WLAN network, do as follows:
1. Go to to select WLAN to enable the WLAN network.
2. Choose one of the listed networks.
If a password is required, enter the password and select Connect.
3.7 Checking the Device Information
To check information such as device status, model and version, go to to select “About phone”.
To avoid possible hearing damage,
do not listen at high audio volume
for long periods of time
4. PoC Service
Push-to-talk over Cellular (PoC) provides direct one-to-one and one-to-many voice communication
services over the cellular network.
This service is available only when you have installed the PoC application on the terminal.
You can access PoC menu to initiate a call.
1. Go to Home > PoC, and then press OK/Menu key.
2. Select the required contact.
3. Press and hold the PTT key and speak.
You can listen to a call without any operation.
ATBECYCZDK
EEFIFRDEEL
HUIEITLVLT
LUMTNLPLPT
SKSIESSEUK
BGROHR
In all EU member states,operation of 5150-5250MHz
is restricted to indoor use only
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
SAR tests are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power
level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the device while
operating can be well below the maximum value, in general, the closer you are to a wireless base station antenna, the lower the power output.
Before a new model device is a available for sale to the public, it must be tested and certified to the FCC that it does not exceed the exposure
limit established by the FCC, Tests for each device are performed in positions and locations (e.g. at the ear and worn on the body)as required
by the FCC.
For body worn operation, this model device has been tested and meets the FCC RF exposure guidelines when used with an accessory
designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 0 cm from
the body.
For face‐up,25 mm was used for test, this equipment should be installed and operated with minimum distance 25mm.
Non‐compliance with the above restrictions may result in violation of RF exposure guidelines.
This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard (s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,including
interference that may cause undesired operation of the device.
Le onjunc areil est conforme aux CNR d’ l’innovation, la science et le développement économique Canada licables aux areils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
(1) l’areil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, onj si le brouillage est susceptible d’en
compromettre le fonctionnement.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
Tous les changements ou modifications non expressément approuvée par le responsible de la conformité pourrait vider l’utilisateur
est habilité à exploiter l’équipemen.
SAR tests are conducted using standard operating positions accepted by the ISEDC with the device transmitting at its highest certified
power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the
device while operating can be well below the maximum value, in general, the closer you are to a wireless base station antenna, the lower the
power output.
Before a new model device is a available for sale to the public, it must be tested and certified to the FCC that it does not exceed the exposure
limit established by the ISEDC, Tests for each device are performed in positions and locations (e.g. at the face and worn on the body)as
required by the ISEDC.
For body worn operation, this model device has been tested and meets the ISEDC RF exposure guidelines when used with an accessory
designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 0 cm from
the body.
For face‐up,25 mm was used for test, this equipment should be installed and operated with minimum distance 25mm.
Non-compliance with the above restrictions may result in violation of RF exposure guidelines.
Les tests SAR sont effectués en utilisant des positions de fonctionnement standard acceptées par l'ISEDC avec l'appareil transmettant à son niveau
de puissance certifié le plus élevé dans toutes les bandes de fréquences testées, bien que le SAR soit déterminé au niveau de puissance
certifié le plus élevé, le niveau SAR réel du téléphone pendant son fonctionnement peut être bien en dessous de la valeur maximale, en
général, plus vous êtes proche d'une antenne de station de base sans fil, plus la puissance de sortie est faible.
Avant qu'un nouveau modèle de téléphone ne soit disponible à la vente au public, il doit être testé et certifié par la FCC qu'il ne dépasse pas
la limite d'exposition établie par l'ISEDC.Les tests pour chaque téléphone sont effectués dans des positions et des emplacements (par exemple au
visage et porté sur le corps) tel que requis par l'ISEDC.
Pour un fonctionnement porté sur le corps, ce modèle de téléphone a été testé et répond aux directives d'exposition ISEDC RF lorsqu'il est
utilisé avec un accessoire désigné pour ce produit ou lorsqu'il est utilisé avec un accessoire qui ne contient pas de métal et qui positionne le
combiné à au moins 0 cm du corps.
Pour la face visible, 25 mm ont été utilisés pour le test, cet équipement doit être installé et utilisé avec une distance minimale de 25 mm.
Le non-respect des restrictions ci-dessus peut entraîner une violation des directives d'exposition aux RF.
