Hytronik HBIR29/SV Guida rapida
1. Technical Specifications
Installation and Instruction Manual
3. Installation
1. Ceiling (drill hole φ66~68mm)
2. Carefully prise off the cable clamps.
3. Make connections to the pluggable
terminal blocks.
4. Insert plug connectors and secure using
the provided cable clamps, then clip
terminal covers to the base.
5. Fit detection blind (if required) and
desired lens.
6. Clip fascia to body.
7. Bend back springs and insert into ceiling.
Ø 78
75.2
70.5
62
4
5
2
3
1
Ø 66~68mm
* Install blind as required
A B
7
21
6
* Install lens as required
1 2 3
Mechanical Structure & Dimensions
HBIR29/SV HBIR29/SV/R
HBIR29/SV/H HBIR29/SV/RH
PIR Standalone Motion Sensor with Mesh
One DALI Channel Output
2. Download the App
HBIR29/SV/SV-20201012-A0
APP Store
Download on the
The access to Silvair apps
mobile app: Silvair on the App Store
web app: platform.silvair.com
Subject to change without notice.
Protocol
4 dBm
2.4 GHz - 2.483 GHz
Operation frequency
Transmission power
Range (Typical indoor)
10~30m
Stand-by power
Operating voltage
<
0.65W (Empty load)
220~240VAC 50/60Hz
Switched power
5s
Warming-up
Max. 40 devices, 80mA
Certification CB, CE , EMC, RED, RCM
360
O
Ta:-20
OC~+50OC
PIR detection
Sensor principle
Detection angle
Operation temperature
IP20IP rating
Mesh
EN300328, EN301489-1,
EN301489-17, EN62479,
EN55015, EN61547,
EN60669-1, EN60669-2-1,
EN62493
Standard compliance
Detection range (Max.)*
HBIR29/SV
Detection range (Max.)*
HBIR29/SV/H
Installation height：15m (forklift)
12m (person)
Detection range (Ø)：24m
Installation Height : 5m
Detection Range (Ø) :9m
Installation height：15m (forklift)
12m (person)
Detection range (Ø)：40m
Detection range (Max.)*
HBIR29/SV/R
Installation Height : 6m
Detection Range(Ø) :10m
Detection range (Max.)*
HBIR29/SV/RH
Wire Preparation
Pluggable screw terminal. It is recommended to make
connections to the terminal before fitting to the sensor.
0.75 - 2.5mm
7-8mm
Wiring Diagram
HBIR29/SV/SV-20201012-A0
Subject to change without notice.
220~240VAC
DA DA
DA DA
N
HBIR29/SV/SV
L
L N
LED
LED Driver Max.40pcs
– +
L
N
The device HBIR29/SV/SV can be reset by placing a strong magnet (e.g. N38 neodymium magnet, d=10mm*h=4mm) near the
sensor lens for 5 seconds. Once the factory reset is done successfully, the luminaire flashes and then permanent on, then the
device is being able to be re-commissioned by SILVAIR app.
4.Mesh Factory Reset
5.To Reprovision
Place a strong magnet on the site of the Reset/Hall effect sensor (see diagram 4 below). To trigger the reset the magnet must
be held in position for 5 seconds.
Diagram Status LED
Flashes rapidly when unprovisioned.
Flashes slowly when provisioned
Module/Antenna placement
Note: When change the lens part of HBIR29/SV/SV, please kindly make sure that the lens fits the right location,
where the “Reset dot” and “BLE dot”matches with the physical location on the PCB.
Reset zone
Magnet to be replaced
for reprovisioning
HBIR29/SV/SV-20201012-A0
Subject to change without notice.
HBIR29/SV/SV Provisioned
MESH package received 30ms ON
30ms ON
HBIR29/SV/SV Unprovisioned
Factory reset
15ms ON
Status LED blinking Sequence
100ms ON
Factory reset (initial burst)
500ms ONAttention (from network)
300ms OFF
2,000ms OFF
500ms ON 1,000ms OFF
1,000ms OFF
50ms OFF
500ms OFF
6. Detection Pattern & Optional Accessories
Radial (B)
Tangential (A)
2.5m
Mount height
Valid Range
6m
5m
4m
3m
insensitive sensitive insensitive sensitive
A: Tangential movement
Tangential: max. 9m
h = max.6m
A
B: Radial movement
Radial: max. 4m
h = max.6m
B
HBIR29/SV: Low-bay at lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height 2.5m-6m)
max 64m2 (Ø = 9m)max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 50m2 (Ø = 8m)
max 38m2 (Ø = 7m)
max 38m2 (Ø = 7m)
max 38m2 (Ø = 7m)
Blind Option 1 --- Aisle Detection
Optional Accessory --- Ceiling/Surface Mount Box: HA03
Optional Accessory --- Blind Insert for Blocking Certain Detection Angles
75
Ø
94
Blind Option 2 --- 180
O
Detection
1. HBIR29/SV (Low-bay)
Valid Range
HBIR29/SV/SV-20201012-A0
Subject to change without notice.
Radial (B)
Tangential (A)
2.5m
Mount height
6m
5m
4m
3m
HBIR29/SV/R: Low-bay convex lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height 2.5m-6m)
max 79m2 (Ø = 10m)
max 79m2 (Ø = 10m)
max 64m2 (Ø = 9m)
max 50m2 (Ø = 8m)
max 50m2 (Ø = 8m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
2. HBIR29/SV/R (Reinforced Low-bay)
A: Tangential movement
Tangential: max. 10m
h = max.6m
A
B: Radial movement
Radial: max. 5m
h = max.6m
B
Optional Accessory --- Ceiling/Surface Mount Box: HA03
Optional Accessory --- Blind Insert for Blocking Certain Detection Angles
75
Ø
94
Valid Range
Blind Option 1 --- Aisle Detection Blind Option 2 --- 180
O
Detection
Valid Range
insensitive sensitive insensitive sensitive
HBIR29/SV/SV-20201012-A0
Subject to change without notice.
Blind Option 1 --- Aisle Detection Blind Option 2 --- 180
O
Detection
3. HBIR29/SV/H (High-bay)
Tangential: max. 20m
h = max.12m
A
Radial: max. 3m
h = max.12m
B
Radial (B)
Tangential (A)
10m
Mount height
14m
15m
13m
12m
11m max 452m2 (Ø = 24m)
max 380m2 (Ø = 22m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 201m2 (Ø = 16m)
max 201m2 (Ø = 16m)
max 201m2 (Ø = 16m)
max 177m2 (Ø = 15m)
max 133m2 (Ø = 13m)
max 113m2 (Ø = 12m)
A: Tangential movement
Tangential: max. 24m
h = max.15m
A
B: Radial movement
Radial: max. 16m
h = max.15m
B
HBIR29/SV/H: High-bay lens detection pattern for forklift @ Ta = 20
O
C
(Recommended ceiling mount installation height
10m-15m
)
Optional Accessory --- Ceiling/Surface Mount Box: HA03
Optional Accessory --- Blind Insert for Blocking Certain Detection Angles
75
Ø
94
Valid Range Valid Range
Radial (B)
Tangential (A)
2.5m
Mount height
11m
12m
10m
8m
6m max 104m2 (Ø = 11.5m)
max 50m2 (Ø = 8m)
max 154m2 (Ø = 14m)
max 227m2 (Ø = 17m)
max 269m2 (Ø = 18.5m)
max 314m2 (Ø = 20m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
A: Tangential movement B: Radial movement
HBIR29/SV/H: High-bay lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height
2.5m-12m
)
insensitive sensitive insensitive sensitive
insensitive sensitive insensitive sensitive
HBIR29/SV/SV-20201012-A0
Subject to change without notice.
7. Additional Information / Documents
Radial (B)
Tangential (A)
10m
Mount height
14m
15m
13m
12m
11m
max 907m2 (Ø = 34m)
max 962m2 (Ø = 35m)
max 1075m2 (Ø = 37m)
max 660m2 (Ø = 29m)
max 346m2 (Ø = 21m)
max 1256m2 (Ø = 40m)
max 154m2 (Ø = 14m)
max 177m2 (Ø = 15m)
max 177m2 (Ø = 15m)
max 154m2 (Ø = 14m)
max 113m2 (Ø = 12m)
max 113m2 (Ø = 12m)
A: Tangential movement
Tangential: max. 40m
h = max.15m
A
B: Radial movement
HBIR29/SV/RH: Reinforced high-bay lens detection pattern for forklift @ Ta = 20
O
C
(Recommended ceiling mount installation height 10m-15m)
Radial: max. 15m
h = max.15m
B
Optional Accessory --- Ceiling/Surface Mount Box: HA03
75
Ø
94
4. HBIR29/SV/RH (Reinforced High-bay with 3-Pyro)
Tangential: max. 30m
h = max.12m
A
Radial: max. 4m
h = max.12m
B
Radial (B)
Tangential (A)
2.5m
Mount height
11m
12m
10m
8m
6m max 154m2 (Ø = 14m)
max 38m2 (Ø = 7m)
max 314m2 (Ø = 20m)
max 531m2 (Ø = 26m)
max 615m2 (Ø = 28m)
max 707m2 (Ø = 30m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
A: Tangential movement B: Radial movement
HBIR29/SV/RH: Reinforced high-bay lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height 2.5m-12m)
insensitive sensitive insensitive sensitive
insensitive sensitive insensitive sensitive
1.Regarding precautions for PIR Sensors installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->PIR Sensors - Precautions for Product Installation and Operation
2.Data sheet is subject to change without notice. Please always refer to the most recent release on www.hytronik.com/products/bluetooth technology ->Partnership
3.Regarding Hytronik standard guarantee policy, please refer to www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy
