Hyundai 2011 EQUUS Manuale utente

Quick Reference Guide

미국_영어

H_VI_고급1.0[USA_N] QRG.indd 1급1.0[USA_N] QRG.indd 1 2015-04-07 오전 9:39:312015-04-07

H_VI_고급1.0[USA_N] QRG.indd 2급1.0[USA_N] QRG.indd 2 2015-04-07 오전 9:39:332015-04-07

1. Component Names and Functions

1-1. Head Unit

1-2. Front Central Controller

1-3. Using the Soft Keys

1-4. Using the MENU Key

1-5. Using the HOME Key

1-6. Using the BACK Key

2. Radio/Media

2-1. Starting FM/AM Mode

Switching to TUNE Mode

Switching to Preset Mode

Saving Stations Manually

2-2. HD Radio

HD Radio On/Off

Changing HD Radio stations

2-3. Jukebox

3. Starting Navigation

Searching Destinations

Set as Destination

Route Guidance

Route Options

Cancel Route

Mute

4. Bluetooth

Pairing and Connecting a Phone

Cautions when connecting a Bluetooth®Phone

Downloading Mobile Contacts

5. Voice Recognition

Starting Voice Recognition

Creating a suitable cabin environment

Voice Command List

6. FAQ

H_VI_고급1.0[USA_N] QRG.indd 3급1.0[USA_N] QRG.indd 3 2015-04-07 오전 9:39:332015-04-07

1. Component Names and Functions

1-1. Head Unit

No Name Details

󱂓DISC OUT DISC eject key

󱂔DISP Turns off the screen or display the default image

󱂕POWER/VOL Turns device power ON/OFF and control the volume

󱂖SEEK/TRACK Changes to the previous/next channel, track, ﬁle or chapter

󱂗FM/AM Press to change mode in order of FM1 →FM2 →AM

󱂘SAT Press to change mode in order of XM1 →XM2 →XM3

󱂙MEDIA Press to operate mode in order of DISC →Jukebox →USB/iPod →AUX →

Bluetooth Audio

󱂚TUNE/FILE Searches frequencies / tracks / channels / ﬁles

1-2. Front Central Controller

No Name Details

󱂓Left Soft Key Synchronized with the button shown on the bottom left side of the screen

󱂔MENU Displays the MENU popup screen

󱂕Right Soft Key Synchronized with the button shown on the bottom right side of the screen

󱂖HOME Displays the HOME screen

󱂗PHONE Displays the Bluetooth Hands-free screen

󱂘BACK Displays the previous screen

󱂙Controller Operates all desired functions by turning, 8-directional pushing and pressing

the controller

󱂚MAP

VOICE Displays the current location in the map

󱂛DEST Displays the Destination setup menu

󱂜Blue Link Displays the Blue Link screen

󱂓

󱂓 󱂔 󱂕

󱂖 󱂚

󱂙

󱂗 󱂛

󱂘 󱂜

󱂔

󱂕

󱂗 󱂘 󱂙

󱂚

󱂖

H_VI_고급1.0[USA_N] QRG.indd 4급1.0[USA_N] QRG.indd 4 2015-04-07 오전 9:39:332015-04-07

1-3. Using the Soft Keys

The screen soft keys are set with features most frequently used within the

current screen.

No Name Description

󱂓

If the left soft key is pressed, the function displayed on the bottom left side of

the current screen is operated. For example, pressing the left soft key within

the Radio Screen will operate the Scan feature

󱂔

If the right soft key is pressed, the function displayed on the bottom right side

of the current screen is operated. For example, pressing the right soft key

within the Radio Screen will display the Presets screen

󱂓 󱂔

󱂓󱂔

H_VI_고급1.0[USA_N] QRG.indd 5급1.0[USA_N] QRG.indd 5 2015-04-07 오전 9:39:332015-04-07

1. Component Names and Functions

1-4. Using the MENU Key

If an additional function exists in the current screen, a MENU icon is always

displayed at the bottom of the screen.

Press the

key to view a list of accessible features in the current

screen.

After selecting the desired feature, press the controller to start operating feature.

Press the

key again to hide the menu window.

H_VI_고급1.0[USA_N] QRG.indd 6급1.0[USA_N] QRG.indd 6 2015-04-07 오전 9:39:332015-04-07

1-5. Using the HOME Key

Press the

HOME

key to display the System Home screen.

Turn the controller to left/right to select the desired mode.

1-6. Using the BACK Key

Press the

BACK

key to display the previous screen or close the popup menu

and window.

H_VI_고급1.0[USA_N] QRG.indd 7급1.0[USA_N] QRG.indd 7 2015-04-07 오전 9:39:342015-04-07

2. Radio/Media

2-1. Starting FM/AM Mode

Press the

HOME

key ▶Select the FM or AM icon.

Switching to TUNE Mode

In the radio screen ▶Push the controller up to enter TUNE mode.

Within the TUNE mode, turn the controller left/right to search for frequencies.

Switching to Preset Mode

In the radio screen ▶Push the controller down to enter Preset mode.

In Preset mode, turn the controller left/right to search previously saved

broadcasts as presets.

H_VI_고급1.0[USA_N] QRG.indd 8급1.0[USA_N] QRG.indd 8 2015-04-07 오전 9:39:352015-04-07

Saving Stations Manually

Select the desired frequency ▶Press and hold the controller.

Select position to save station.

Stations can also be saved manually by pressing the

key ▶Selecting

Save Station

Press and hold the controller to

save station.

H_VI_고급1.0[USA_N] QRG.indd 9급1.0[USA_N] QRG.indd 9 2015-04-07 오전 9:39:352015-04-07

2. Radio/Media

2-2. HD Radio

HD Radio On/Off

In the radio screen ▶Press the

key ▶Select HD Radio.

You can select HD Radio from the menu and listen to HD Radio Broadcasts.

Changing HD Radio stations

HD Radio channel can be changed only in the tune mode.

To Change HD Radio stations, push the controller up to enter TUNE mode.

Turn the controller to left/right and

select the desired HD Radio station.

If HD Radio station is not tuned, then

frequencies will be captured manually.

In HD Radio channel 1, if the system

cannot receive HD radio, it will

automatically switch to analog. In HD

Radio channel 2~8, if the system cannot

receive HD radio, It remains mute.

H_VI_고급1.0[USA_N] QRG.indd 10급1.0[USA_N] QRG.indd 10 2015-04-07 오전 9:39:362015-04-07
