I-Tech NVP1015 Manuale utente

USER

NVP1015 / 1017– 801/1601

1U 15” / 17” LCD

Keyboard Drawer with PS/2 KV

ANUAL

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

Table of Contents

1. Table of Content P.1

2. Introduction P.2

3. Features P.2

4. Package Contents P.3

5. Optional Accessories P.4

6. Peripheral Products P.4

7. Important Safeguards P.5

8. Structure Diagram P.6

9. Dimension Diagram

N P1015-8/1601 P.7

N P1017-8/1601 P.8

10. LCD Session

LCD Membrane Diagram P.10

LCD OSD Control

Main Menu P.10

Sub Menu P.11-12

Resolution Settings

For Windows P.13

For SUN Servers P.14

11. KV Session

Front iew P.16

Rear iew P.17

Installation Steps P .18

Cascading P.19

12. Start Up P.20

HotKey Command P.20

HotKey Command Operation P.21-22

K M On Screen Display Control

OSD Structure Diagram P.23

OSD Menu Operation P.24

13. FAQ P.25

14. Technical Specification P.26-27

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

2. Introduction

N P Series is a combination of keyboard, mouse and monitor into a drawer, with features such as

flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an

administrator to control PC system.

N P Series provides cost effective for your limited IT budget over using CRT and rack mounting.

Also, it will be space saving for your compact environment rack and effective assistant for an

administrator to control PC system.

3. Features

• Adjustable mounting brackets from 390 to 790mm (front to rear 19”mount)

• Lightweight aluminium construction—with black anodise finish

• Slim Size keyboard with GlidePoint touch pad mouse

• Standard D-Sub 15-pin GA input connector

• Supplied with 12 5A remote power adapter (single power resource)

• Built in On Screen Display controlled by integral membrane switches

• 1U Height, separate sliding screen and keyboard using unique miniature Cyber slides

• Unique monitor flip-up design allows viewing through closed glass door of cabinet.

• Built-in K M switch function for easy controlling and monitoring up to 16 residing servers / platforms

• Support eight characters password protection and search PC server name

• Auto scan mode for monitoring PCs and flexible scan time from 5 ~ 99 seconds

• Hot Pluggable—Add or remove computers without powering down the switch

• Easily switch individual button to select the PC channel using the pushbutton channel selector

switches, Hot keys, or via the On-Screen

Disclaimer

This information is subject to change without notice. The producer of this manual accepts no

responsibility for damage or claims, resulting from misuse or misinterpretation

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

4. Package Contents

LCD Monitor Drawer with PS/2 K M Switch 1 Piece

User Manual 1 Piece

DC Power Adapter 1 Piece

Power Cord 1 Piece

Mounting Bracket 1 Pair

Fasteners 4 Pieces

ND-6 3-in-1 K M cable 8 Pieces

Before Unpacking

It is very important to locate the LCD Keyboard Drawer in a suitable environment.

• The surface for placing and fixing the LCD Keyboard Drawer should be stable and level

or mounted into a suitable cabinet.

• Make sure the place has good ventilation, is out of direct sunlight, away from sources of

excessive dust, dirt, heat, water, moisture and vibration.

• Convenience for connecting the LCD Keyboard Drawer to the related facilities should

be well considers too.

Unpacking

The LCD Keyboard Drawer comes with the standard parts shown as above. Check and make

sure they are included and in good condition. If anything is missing, or damage, contact the

supplier immediately.

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

5. Optional Accessories

KV Cable

ND-6 / 10 / 15 6ft / 10ft / 15ft PS/2 3-in-1 cable

Cascade Cable

NA-2 / 6 / 10 / 15 2ft / 6ft / 10ft / 15ft PS/2 3-to-3 cable

Conversion Adapter

SUN-31 SUN / iMAC USB to PS/2 adapter

Others Video Input

12 / 24 / 48 DC Power Supply

6. Peripheral Products

odel Description

N -401 / N -801 / N -1601 N -401 / N -801 / N -1601

N -1602 16-Port 2-Console PS/2 K M switch

N -S801 / N -S1601 8-Port /16-port USB K M switch

N -S1602 16-port 2-Console USB K M switch

N -101 CAT.5 PS/2 K M extender

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

7. Important Safeguards

What the warranty does not dover

1. Any product, on which the serial number has been defaced, modified or removed.

2. Damage, deterioration or malfunction resulting from:

a) Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized

product modification, or failure to follow instructions supplied with the product.

b) Repair or attempted repair by anyone not authorized by us.

c) Any damage of the product due to shipment.

d) Removal or installation of the product.

e) Causes external to the product, such as electric power fluctuation or failure.

f) Use of supplies or parts not meeting our specifications.

g) Normal wear and tear.

h) Any other causes which does not relate to a product defect.

3. Removal, installation, and set-up service charges.

Please read all of these instructions carefully before you use the device.

Save this manual for future reference.

• Unplug the LCD Keyboard Drawer from the power outlet before cleaning.

• Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a neutral

detergent (e.g. clean water) and squeeze it tight, then clean the screen slightly with it.

• Do not expose the LCD Keyboard Drawer directly to rain, water, moisture or sunlight.

• Avoid pressure on the LCD screen to prevent permanent damage to the display.

• Do not attempt to service the device yourself. Improper operation may void your

warranty. Refer all servicing to qualified service personnel.

•

Safe storage environment of the LCD Keyboard Drawer is ranging between –20

and 60

C. Permanent damage could occur if the LCD Keyboard Drawer is stored

outside the safe range.

• Unplug the LCD Keyboard Drawer immediately and call qualified service

personnel under the following conditions:

1. If the monitor has been exposed to rain, liquid or water.

2. If the monitor has been dropped or the casing has been damaged.

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

8. Structure Diagram

1. PS/2 keyboard

2. Aluminium front panel

3. Class A active matrix TFT LCD panel

4. Rear metal case

5. Analog to digital signal converter board

6. LCD inverter

7. LCD membrane

8. Ball bearing telescopic slides with stopper

9. Adjustable mounting bracket

10. KV membrane & KV switch board

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

9. Dimensions Diagram

NVP1015-8/1601 1U 15” LCD Keyboard Drawer with PS/2 K M

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

9. Dimensions Diagram

NVP1017-8/1601 1U 17” LCD Keyboard Drawer with PS/2 K M

i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@iTechK M.com • WEB: www.iTechK M.com

NVP1015 / NVP1017 User anual

LCD

Session
