iAN QII-11381 Manuale utente
MODEL: QII-11381
Please read carefully before using your equipment
and store this manual for future reference.
Por favor léalo cuidadosamente antes de usar su equipo
y guárdelo para uso de futuras consultas.
USER MANUAL / MANUAL DE USUARIO
2
WARRANTY AND PRODUCT
INFORMATION
These terms shall be governed and construed under laws of the
jurisdiction in which the product was purchased, if any term here is
held to be invalid or unenforceable, such term (in so far as it is invalid
or unenforceable) shall be given no effect and deemed to be excluded
without invalidating any of the remaining terms. Qian reserves the right to
amend any term at any time without notice.
3
DISCLAIMER
1 .Please use the original power supply, we cannot be held
responsible for any problems or failures caused by any third party
adapters.
2.Users may use music videos, images and software provided
by third parties, but we cannot be held responsible for copyright
issues or software failures.
3.If the product failure, we will strictly abide by the warranty terms,
but we will not be held responsible for any property damage or
nancial loss that may be caused during use.
4. The equipment comes with built-in software at the factory,
which can be used after the actual test. However, it will not affect
the machine in any way if it is removed or not when looking for
compatibility or other issues. Please note that it is not a product
quality issue.
5. The company reserves the right to make improvements to its
products and product specications and designs are subject to
change without notice! Please refer to the actual product.
4
PRODUCT INTERFACE DESCRIPTION
QUICK INSTALLATION
5
UPGRADING MEMORY AND
REPLACING HARD DRIVE
Preparation for upgrade
A. Switch off all peripheral devices connected to the Mini PC.
B. Turn off the Mini PC and disconnect the power cord.
C. Open the top magnetic cover.OP: 200mV
1.Replacing memory
To upgrade the memory, please be sure to select a memory
module that meets the following requirements:
DDR4 :2133/2400/3200MHz SO-DIMM
Note: If you intend to install only one memory module, please
install it in the lower memory slot.
Remove the old memory module Gently unfold the metal retaining
clips on each end of the memory slot to allow the module to pop
out of the slot (C). Hold the module by its edges and remove it
from the socket, then store it in its anti-static packaging.
Install the new memory module Firstly, align the notch on the
bottom edge of the memory module with the protrusion on the slot
holder, then insert the bottom edge of the memory module into the
socket (A) at a 45 degree angle. After inserting the module, push
down on the outer edge of the module until the retaining clip snaps
into place (B), and ensure the clips are securely in place.
6
2.REPLACE OR INSTALL M.2 SSD
(INSTALLATION OF NEW SSD REQUIRES SYSTEM RE-INSTALLATION)
Remove the pre-installed (if any) SSD from the connector with a
screwdriver counterclockwise (shown in Figure 3); align the notch
on the bottom of the new M.2 SSD with the tab on the connector,
then insert the bottom edge of the M.2 SSD into the connector
(shown in Figure 4), and nally use a screwdriver clockwise to
Secure the M.2 SSD to the bracket with screws (shown in Figure 5).
7
INSTALLATION OF VESA BRACKET
Please follow the instructions below to install and use the VESA
mounting bracket:
1 .Fix the two brass screws A included in the box into the
corresponding screw holes on the back of the mini pc (as shown in
Figure 6).
2. Using the four small black screws included in the box, attach the
VESA bracket to the back of the monitor or TV (as shown in Figure 7).
3. Fix the mini pc through the two screws A xed to the bottom
of the main unit, slip over the VESA mounting bracket hole B to
complete the installation.
PACKING LIST
8
PRECAUTIONS
1 .Be extremely careful when performing operations that may
cause le damage or loss.
2.Pay attention to the virus protection, try to use the virus rewall
during using this Mini PC.
3.If you don’t use the device for a long time, please trun off it, and
disconnect the power.
4. Do not turn on and off the device frequently for a short period of
time.
It is recommended that the interval between two boots should be
at least 10 seconds, preferably no less than 60 seconds.
5. Pay attention to moisture, keep the use environment clean and
sanitary, if there is dust on the device, please wipe it with a dry soft
cloth.
6. Avoid direct exposure of strong light to the device, and stay
away from strong magnetic elds.
7. Don’t get water, food and other uids onto the device, and don’t
pull the data and power lines with force.
9
GARANTÍA E INFORMACIÓN DEL
PRODUCTO
Estos términos se regirán e interpretarán de acuerdo con las leyes de la
jurisdicción en la que se compró el producto, si alguno de los términos
en este documento se considera inválido o inaplicable, dicho término
(en la medida en que sea inválido o inaplicable) no tendrá efecto y se
considerará excluido sin invalidar ninguno de los términos restantes.
Qian se reserva el derecho de modicar cualquier término en cualquier
momento sin previo aviso.
10
DESCARGO DE RESPONSABILIDAD
1 Por favor, util ice la fuente de alimentacion original, no nos
hacemos responsables de cualquier problema o fallo causado por
cualquier adaptador de terceros.
2.Los usuarios pueden utilizar videos musicales, imagenes y
software proporcionados por terceros, pero no nos hacemos
responsables de los problemas de derechos de autor o de los
fallos del software.
3.Si el producto falla, nos atendremos estrictamente a los terminos
de la garantia, pero no nos responsabilizaremos de los dahos
materiales ni de las perdidas economicas que puedan producirse
durante su uso.
4. EI equipo viene con un software incorporado de fabrica, que
puede ser utilizado despues de la prueba real. Sin embargo, no
afectara a la maquina de ninguna manera si se quita o no cuando
se busca la compatibilidad u otras cuestiones. Tenga en cuenta
que no es un problema de calidad del producto.
5. jLa empresa se reserva el derecho de realizar mejoras en sus
productos y las especicaciones y disehos de los mismos estan
sujetos a cambios sin previo aviso! Por favor, consulte el producto
real.
