IBM ThinkPad 310 Manuale del proprietario

S05L-1935-00

IBM Mobile Systems

ThinkPad 310, 310D, 310E, 310ED

Hardware Maintenance Manual

February 1998

S05L-1935-00

IBM Mobile Systems

ThinkPad 310, 310D, 310E, 310ED

Hardware Maintenance Manual

February 1998

IBM

Note

Before using this information and the product it

supports, be sure to read the general information

under “Notices” at the back of this manual.

First Edition (February 1998)

The following paragraph does not apply to the United

Kingdom or any country where such provisions are

inconsistent with local law: INTERNATIONAL

BUSINESS MACHINES CORPORATION PROVIDES THIS

PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY

KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT

NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE. Some states do not allow disclaimer of

express or implied warranties in certain transactions,

therefore, this statement may not apply to you.

This publication could include technical inaccuracies or

typographical errors. Changes are periodically made to

the information herein; these changes will be incorporated

in new editions of the publication. IBM may make

improvements and/or changes in the product(s) and/or the

program(s) described in this publication at any time.

This publication was developed for products and services

offered in the United States of America. IBM may not offer

the products, services, or features discussed in this

document in other countries, and the information is subject

to change without notice. Consult your local IBM

representative for information on the products, services,

and features available in your area.

Requests for technical information about IBM products

should be made to your IBM reseller or IBM marketing

representative.

 Copyright International Business Machines

Note to U.S. Government users–Documentation related to

Restricted rights–Use, duplication, or disclosure is subject

to restrictions set forth in GSA ADP Schedule Contract

with IBM Corp.

ii IBM Mobile Systems ThinkPad 310 (D/E/ED) HMM

About This Manual

This manual contains service and reference information for

IBM ThinkPad 310, 310D, 310E or 310ED (2600) products.

Use this manual along with the advanced diagnostic tests

to troubleshoot problems effectively.

The manual is divided into sections as follows:

The Introduction section provides general information,

guidelines, and safety information required to service

computers.

The product-specific section includes service,

reference, and product-specific parts information.

Important

This manual is intended for trained servicers who are

familiar with ThinkPad products. Use this manual

along with the advanced diagnostic tests to

troubleshoot problems effectively.

Before servicing an IBM mobile product, be sure to

review the safety information under “Safety Notices

(Multi-lingual Translations)” on page ix and “Safety

Information” on page xvi.

iii

Related Publications

The following mobile product publications are available

through IBM or your IBM Authorized Dealer.

Related Diskettes

The following diskettes are available through IBM or your

IBM Authorized Dealer.

Publication Part, Form Number

Mobile Systems HMM

Volume 1: Laptop,

Notebook, Portable, and

ThinkPad Computers

(Models L40, CL57, N45,

N51, P70/P75, ThinkPad

300, 350, 500, 510, 710T,

Expansion Unit, Dock I,

Dock II)

30H2356, S82G-1501-01

Mobile Systems HMM

Volume 2: ThinkPad

Computers

(Model 340, 355, 360, 370,

700, 701, 720, 750, 755)

30H2357, S82G-1502-03

Mobile Systems HMM

Volume 3: ThinkPad

Computers

(Model 365, 380, 385, 560,

760, SelectaDock

84H8099, S82G-1503-05

Mobile Systems HMM

Volume 4: ThinkPad

Computers

(Model 365, 380, 385, 560,

760, 765, 770, SelectaDock

05L1271, S05L-1270-01

Diskette Part, Form Number

ThinkPad 310 Diagnostics

Diskette 05L1936, S05L-1936

ThinkPad 310 Maintenance

Diskette 05L1770, S05L-1770

iv IBM Mobile Systems ThinkPad 310 (D/E/ED) HMM

Contents

Introduction . . . . . . . . . . . . . . . . . . . vii

How to Use Error Messages .......... viii

How to Read POST Error Messages ...... viii

Safety Notices (Multi-lingual Translations) ..... ix

Safety Information . . . . . . . . . . . . . . . . xvi

General Safety . . . . . . . . . . . . . . . . xvi

Electrical Safety . . . . . . . . . . . . . . . xvii

Safety Inspection Guide ........... xviii

Handling Electrostatic Discharge-Sensitive Devices xx

Grounding Requirements . . . . . . . . . . . . xx

Laser Compliance Statement ........... xxi

ThinkPad 310, 310D, 310E, 310ED (2600) .... 1

Read This First .................. 1

Note for Warranty: ................ 2

Checkout Guide . . . . . . . . . . . . . . . . . 3

BIOS Utility . . . . . . . . . . . . . . . . . . . . 11

Power Management Features ........... 12

Symptom-to-FRU Index . . . . . . . . . . . . . . 14

Related Service Procedures ............ 24

Utility Program Diskette .............. 29

Product Overview . . . . . . . . . . . . . . . . . 32

FRU Removals and Replacements ......... 33

Locations . . . . . . . . . . . . . . . . . . . . . 65

310 - System Unit Parts Listing .......... 70

310D - System Unit Parts Listing .......... 71

310/310D - System Unit FRU List ......... 72

310/310D LCD Unit Parts Listing .......... 75

310E System Unit Parts Listing .......... 77

310ED System Unit Parts Listing .......... 78

310E/310ED System Unit FRU List ........ 79

310E/310ED LCD Unit Parts Listing ........ 82

310E/310ED LCD Module FRU list ......... 83

310E (2600-Axx/Cxx/Exx/Fxx) System Unit Parts

Listing . . . . . . . . . . . . . . . . . . . . . 84

310ED (2600-Bxx/Dxx) System Unit Parts Listing . . 85

310E/310ED (2600-Axx/Bxx/Cxx/Dxx/Exx/Fxx) System

Unit FRU List .................. 86

310E/310ED LCD Unit Parts Listing ........ 89

310/310E/310D/310ED Miscellaneous and Other Parts 91

 Copyright IBM Corp. 1998 v

vi IBM Mobile Systems ThinkPad 310 (D/E/ED) HMM

Introduction

Important

Diskette fixes are customer installable. The diskette

fixes are located on the PC Company Bulletin Board

Service (BBS). The direct phone line for modem

connection is 919-557-0001 or tieline 255-0001.

Advise customers to contact the PC Company

HelpCenter at 800-772-2227 if they need assistance in

obtaining or installing any diskette fixes.

Customers in Canada should call IBM HelpPC at

800-565-3344 for assistance or down-load information.

The Canadian BBS phone numbers are:

Montreal 514-938-3022

Toronto 905-316-4255

Vancouver 604-664-6464

Winnipeg 204-934-2735

FRU Replacement Strategy

Ensure that all diskette fixes are installed prior to replacing

any FRUs. And, use the following strategy to prevent

unnecessary FRU replacement and service expense:

If you are instructed to replace a FRU and that

does not correct the problem, reinstall the original

FRU before you continue.

Some computers have both a processor board and a

system board. If you are instructed to replace either

the processor board or the system board, and the first

board that you replaced does not correct the problem,

reinstall the original board, then replace the other

(processor or system) board.

If an adapter or device consists of more than one

FRU, an error code may be caused by any of the

FRUs. Before replacing the adapter or device,

remove the FRUs, one by one, to see if the

symptoms change. Replace only the FRU that

changed the symptoms.

Attention

A customized setup configuration (other than default

settings) may exist on the computer you are servicing.

Running Automatic Configuration may alter those

settings. Note the current configuration settings (using

the View Configuration option) and verify that the

settings are in place when service is complete.

The advanced diagnostic tests are intended to test

only

IBM products. Non-IBM products or modified options can

give false errors and invalid responses.

 Copyright IBM Corp. 1998 vii

Hard Disk Drive Replacement Strategy:

Always try to run a low-level format before replacing a hard

disk drive.

Attention

The drive startup sequence in the computer you are

servicing might have been changed. Be extremely

careful during write operations such as copying,

saving, or formatting. Data or programs can be

overwritten if you select an incorrect drive.

How to Use Error Messages

Use the error codes displayed on the screen to diagnose

failures. If more than one error code is displayed, begin

the diagnosis with the first error code. The cause of the

first error code can result in false error codes being

displayed. If no error code is displayed, see if the error

symptom is listed in the Symptom-to-FRU Index for the

computer you are servicing.

How to Read POST Error Messages

POST error messages are displayed on the screen as

three, four, five, or eight digits. The error messages that

can be displayed as shorter POST messages are

highlighted in this index. Some digits will represent

different information for SCSI errors versus non-SCSI

errors.

The following example shows which digits display the

shorter POST error messages and also defines the SCSI

information in an eight-digit error message.

Shorter POST Messages

┌────┬────┬────┬────┐

│ │ │ │ │

┌────┬────┬────┬────┬────┬────┬────┬────┐

│ ð│ ð│ ð│ ð│ ð│ ð│ ð│ ð│

└────┴────┴────┴────┴────┴────┴────┴────┘

│ │ │ │ │ │ │ │

Reserved ││││││Size (SCSI)

└────┴────┘ │ │ Slot Number (SCSI)

Device Code │ Logical Unit Number (SCSI)

ID (SCSI)

All SCSI devices are set to a different SCSI ID.

Duplicate SCSI ID settings can generate a false error

message. Use the SCSI ID to determine whether the error

message is coming from an internal or an external device.

viii IBM Mobile Systems ThinkPad 310 (D/E/ED) HMM
