INSTALLATION & SAFEGUARDS
All the safety and operating instructions should be read before operation.
Environment Condition for Installation
1. To prevent electric shock or other hazard, do not expose this unit to rain, moisture, or dust.
2. Place this unit in a well-ventilated place and do not place heat-generating objects on this
unit.
3. This unit should not be located in an area where it is likely to be subjected to mechanical
shocks.
Before You Start
1. Ensure the power switch is in the OFF position prior to installation.
2. Opening or removing the cover may expose you to dangerous voltage or other hazards.
3. Operate this unit within the range of room temperature and humidity.
4. Supply power through the type of power source indicated on the manufacturer’s label and
with the
p
ower su
pp
l
y
included in this unit.
pppy
5. Keep this unit out of direct sunlight and heat .
6. Make sure conductive material does not go into the fan hole.
Notice
1. Before initial configuration or operation, first set TIME/DATE, and then set this unit to the
FACTORY DEFAULT setting, and lastly HDD clear. Follow these steps in order. Otherwise it
may cause non
-
recording on the HDD or non saving setting value. Or it may record, but you
may
cause
non
recording
on
the
HDD
or
non
saving
setting
value.
Or
it
may
record,
but
you
will not be able to search recorded data.
2. This unit is compatible with large sized HDD.
3. When setting RECORDING SETUP after installation, set not only RECORD CONFIGURATION,
but also SCHEDULE SETUP. Setting Schedule setup is necessary as this unit records
according to Record type & Schedule setup. Default setting value for Schedule setup is
Continuous mode.
4. Stop recording before powering off this unit by entering setup menu. Powering off while
recordin
g
ma
y
cause critical malfunctions such as Recordin
g
Error, Pla
y
back Error, or S
y
stem
gy g y y
Error.
FCC Information
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when
the e
q
ui
p
ment is o
p
erated in a commercial environment.
qp p
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operated the equipment under FCC rules.
2
CONTENTS
CHAP. 1 General Information ---------------------------------------------------------------- 5
1-1. Package Contents &
Description ---------------------------------------------------------------- 5
CHAP. 2 Function of Buttons ---------------------------------------------------------------- 6
2-1. Front Panel ---------------------------------------------------------------- 6
2-2. Rear Panel ---------------------------------------------------------------- 8
CHAP. 3 Installation ---------------------------------------------------------------- 10
3-1. Configuration ---------------------------------------------------------------- 10
3-2. Detailed Configuration ---------------------------------------------------------------- 11
1
)
Rack Mount ---------------------------------------------------------------- 11
)
2) HDD (Hard Disk Drive) ---------------------------------------------------------------- 11
3) Camera ---------------------------------------------------------------- 13
4) Audio ---------------------------------------------------------------- 13
5) Monitor ---------------------------------------------------------------- 14
6
)
Power Cable ---------------------------------------------------------------- 14
)
7) SPOT Output, Video Printer ---------------------------------------------------------------- 14
8) Others ---------------------------------------------------------------- 15
CHAP. 4 Display Configuration ---------------------------------------------------------------- 17
4-1. Display ---------------------------------------------------------------- 18
4
2
Main Menu
19
4
-
2
.
Main
Menu
----------------------------------------------------------------
19
4-3. Record, Playback Panel ---------------------------------------------------------------- 22
4-4. Panic Recording ---------------------------------------------------------------- 22
4-5. SEARCH ---------------------------------------------------------------- 23
4-6. PAN/TILT/ZOOM Control ---------------------------------------------------------------- 24
4
-
7
Data Backup (CD/DVD)
----------------------------------------------------------------
24
4
7
.
Data
Backup
(CD/DVD)
24
4-8. Data Backup (USB) ---------------------------------------------------------------- 25
CHAP. 5 Operation ---------------------------------------------------------------- 26
5-1. System Login ---------------------------------------------------------------- 26
5-2. Factory Default ---------------------------------------------------------------- 26
5
-
3
Key Lock
----------------------------------------------------------------
27
3
5
3
.
Key
Lock
27
5-4. Playback ---------------------------------------------------------------- 27
CHAP. 6 DVR Setup ---------------------------------------------------------------- 28
6-1. General Operation ---------------------------------------------------------------- 28
6-2. SYSTEM Setup ---------------------------------------------------------------- 29
6-3. DISPLAY Setup ---------------------------------------------------------------- 32
6-4. RECORD Setup ---------------------------------------------------------------- 34
6
5
CAMERA Setup
36
6
-
5
.
CAMERA
Setup
----------------------------------------------------------------
36
6-6. DEVICE Setup ---------------------------------------------------------------- 38
6-7. NETWORK Setup ---------------------------------------------------------------- 40
CHAP . 7 Network Setup ---------------------------------------------------------------- 43
6-8. Language Setup ---------------------------------------------------------------- 42
7-1. DVR Network ---------------------------------------------------------------- 43
7-2. DDNS ---------------------------------------------------------------- 45
7-3. Web Application ---------------------------------------------------------------- 46
CHAP. 8 Remote Viewer Program ---------------------------------------------------------------- 48
8-1. IRS Operation ---------------------------------------------------------------- 48
8-2. Backup Operation ---------------------------------------------------------------- 51
8-3. Transmitter Operation ---------------------------------------------------------------- 53
8-4. Player Operation ---------------------------------------------------------------- 59
CHAP. 9 Specification / Dimension ---------------------------------------------------------------- 62
CHAP.10 Remote Controller ---------------------------------------------------------------- 64
4
1
1
Package
Contents & Description
1. General Information
1
-
1
.
Package
Contents
&
Description
1. DVR Main Unit 2. Remote Control
3. Power Cable 4. Power Adapter 5. User’s Manual 6. Software CD
7. Rubber Pad 8. HDD Absorber 9. Rack Mount Bracket
HDD Bolts 10. Mouse
8. Batteries
Contents Description
1 DVR Main Unit
Stand
-
Alone DIGITAL VIDEO RECORDER
1
.
DVR
Main
Unit
Stand
Alone
DIGITAL
VIDEO
RECORDER
2. Remote Control Remote Control
3. Power Cable AC power supply to adapter
4. Power Adapter DC power supply
5. User’s Manual User’s Manual
6. Software CD Remote Viewer SOFTWARE
7. Rubber Pad Prevent DVR from slipping by attaching on the bottom of the unit
8. HDD Absorber Absorbing the mechanical shock of HDD against the case bottom
9. Batteries Batteries for Remote Control
10. Rack Mount Bracket /
Bolts
Rack Mount Bracket / 6 Bolts for fixing Rack Mount Bracket to DVR / 4 Bolts
for fixing DVR with Rack Mount Bracket to 19” Rack / 8 Bolts for fixing HDD
into DVR
5
11. Mouse DVR function control
2
-
1
Front
2. Function of Buttons
2
1
.
Front
1 2 3 4 5
Name Function
1LEDL
St t f ti
6 7 8
1
.
LED
L
am
p
s
St
a
t
us o
f
o
p
era
ti
on
2.Jog Shuttle Jog shuttle activate only when in Pause: Pressing Jog Shuttle button will pause
playback.
Rotating clockwise causes it to move into ever-faster forward speed, and
counter-clockwise causes it to move into ever-faster reverse speed.
In Setup Menu, its rotation Increases or Decreases value.
3.Function Key MENU Enter SYSTEM MENU
PANIC Panic recording at continuous mode at highest quality (120ips,
Highest, 1/1x)
BOOKMARK Check the bookmark while playback for bookmark search.
PLAY Playback recorded data on HDD
AUDIO Select audio channel. Turn volume up/down
KLOCK
Locking the key
K
.
LOCK
Locking
the
key
.
To unlock, keep pressing the button for a few seconds and
input password (Same password for Setup Menu)
SEARCH Search recorded data on HDD
STOP Stop Playback.
4.LIVE View
Control Key
PTZ Shift LIVE mode to PTZ control mode
MODE Switch screen division from full screen to 16 s
p
lit screen
(
in 1
,
p(,
4, 9, 13, 16 sequence )
SEQ Auto camera image sequence in full screen mode
PIP Picture In Picture mode
FRZ Freeze Live display
ZOOM Zoom image
6
Name Function
4-1.Control Key FUNC Main menu panel On/Off
ESC Cancel selected menu panel
+ Increase setting value, page shift
- Decrease setting value, page shift
5A k
Nitith
5
.
A
rrow
k
e
y
N
av
ig
a
t
e
i
n
th
e menu
6. USB Device For Firmware upgrade and USB backup
7.Camera Selection
/ PTZ Control
1~16 Button : Select camera channel in full screen mode
NEAR : FOCUS NEAR PRESET + : Increase PRESET NO.
FAR : FOCUS FAR PRESET - : Decrease PRESET NO.
WIDE : ZOOM IN PTZMENU : PTZ MENU POPUP
TELE : ZOOM OUT F1 : USER 1
SET : PRESET SET F2 : USER 2
CLEAR : PRESET CLEAR F3 : USER 3
GOTO : PRESET GOTO F4 : USER 4
AUTO : AUTO SCAN F5 : USER 5
8.CD/DVD-ROM For Firmware upgrade and CD/DVD backup
7
2-2. Rear
[Rear Panel for 4ch DVR]
257
11
13
4689
10 12
[Rear Panel for 8ch DVR]
25711
1
3
4
6
8
9
10
12
[Rear Panel for 16ch DVR]
1
3
4
6
8
9
10
12
1
234
57
10 11
8
68912
Name Function
1 RS 485 Connection with PTZ Camera or other external devices using RS 485
RELAY Output Relay Output terminal
SENSOR Input Sensor Input terminal
2 VGA VGA Output to CRT or TFT LCD Monitors
3 ETHERNET Connection to Ethernet devices
4 RS-232C Connection to external devices such as PC using RS-232C to control DVR
5 Camera Input Connection with NTSC/PAL Cameras
6 Loop Out Camera Loop out
7 Monitor Output Connection with NTSC/PAL Composite Monitor
8 SPOT Output Connection from Analog backup output to external devices
9 DC Power DC 12V 6.67A Adaptor
10 PS2 Mouse Connection to PS2 Mouse
11 Audio Microphone input and Audio output
12 POWER
SWITCH
Power ON/OFF Switch
NOTE : You can not mix PAL and NTSC equipment. For example, you cannot
use a PAL camera and NTSC monitor.
9
3. Installation
3-1. Configuration
[ Typical Digital Video Recorder Installation ]
10
