iDevices IGRILL MINI Manuale utente
User Manual
Table of Contents
In the Box 3
Quick Start Instructions 3
Getting Started 4
iDevices Connected App 4
Battery Replacement 4
Powering On & Off 5
Connecting 5
Mounting 6
Probe Use 7
Probe Wrap Use 8
Using the iGrillmini 9
Smart LED 9
Proximity Sensor 9
Custom & Preset Alarms 10
Renaming Probes 11
Timer Tool 11
Globe Tool 12
Graph Tool 12
Problem Solving 13
Frequently Asked Questions 15
Disclaimer 15
Regulations 15
3
In the Box
Inside your iGrillmini box, you will nd:
• 1 iGrillmini
• 1 Coin Cell Battery (Installed)
• 1 Meat Probe
• 1 Colored Probe Indicator
• 1 Probe Wrap
• 1 Optional Magnetic Disc
• Quick Start Guide
Quick Start Instructions
• Download the iDevices Connected app from the App StoreSM and
launch it from your iPhone®(4S and later), iPad®(3rd generation and
later), iPad mini™ (all generations), or iPod touch®(5th generation
and later).
• Enable Bluetooth®on your smart device under ‘Settings’.
• Separate the iGrillmini from its base by rmly holding the base with
one hand and gently pulling the iGrillmini top upwards with the other
hand.
• On the underside of the iGrillmini, remove the battery door by
twisting it counter-clockwise. Remove the battery pull tab. Ensure
the battery is in place and replace the battery door.
• Clip the iGrillmini top back into its base.
• Plug the Meat Probe into the probe port of the iGrillmini.
• Press the power button located at the center of the faceplate for
two seconds. The display will light up, indicating the iGrillmini has
powered on.
4
• Open the iDevices Connected app to connect to your iGrillmini. Tap
on the iDevices logo in the gray toolbar at the top of the app. Select
your iGrillmini from the device manager.
• You are ready to use your iGrillmini!
Getting Started
iDevices Connected App
The iDevices Connected app provides all of the functionality and
customization you’ll need to get the most out of your iGrillmini. The iDevices
Connected app is compatible with the following devices:
• iPhone (4S and later)
• iPad (3rd generation and later)
• iPad mini (all generations)
• iPod touch (5th generation and later)
You must be running iOS 7+ on your smart device to use the iDevices
Connected app. Please visit the App StoreSM to download the free iDevices
Connected app.
Once you’ve downloaded the app, you’ll have access to links
for instructional videos, step-by-step instructions and FAQ’s for
troubleshooting.
Battery Replacement
To replace your iGrillmini battery, follow these steps:
• Separate the iGrillmini from its base by rmly holding the base with
one hand and gently pull the iGrillmini top upwards with the other
hand.
• On the underside of the iGrillmini, remove the battery door by
twisting it counter-clockwise
• Replace the battery with a CR2032 coin cell battery (available at
local drugstores in the specialty battery section).
5
• Ensure the battery is in place and replace the battery door.
Powering On & Off
To turn on the iGrillmini, follow these steps:
• Press the power button located at the center of the faceplate.
• The Smart LED will blink blue while waiting for pairing.
To turn off the iGrillmini, follow these steps:
• Press and hold down the power button located in the center of the
faceplate for three seconds.
• The Smart LED will illuminate solid white and will then turn off.
Auto Shut-Off:
• The iGrillmini will stay powered on for ve minutes before
automatically turning off if there is no probe installed and it is not
paired to a smart device.
• The iGrillmini will stay powered on for eight hours before
automatically turning off if not paired to a smart device and the
probe is installed.
• The iGrillmini will stay powered on until the battery is depleted if it is
paired with a smart device, even if there is no probe installed.
Connecting
To connect your iGrillmini to your iPhone, iPad or iPod touch, follow these
steps:
• Open Settings
• Tap Bluetooth
• Set Bluetooth to On
• While turned on, place your iGrillmini next to your smart device
and open the iDevices Connected app. Your smart device will
automatically recognize any available iDevices products and display
them in the device manager. You can view your device manager by
tapping the iDevices logo at the top of the app.
6
• Select your iGrillmini from the device manager. You will then be sent
a pairing request. Once you accept, your smart device will pair with
the iGrillmini and you are ready to congure your settings and start
cooking!
To connect an additional iGrillmini (or other iDevices product) to your
iPhone, iPad or iPod touch follow these steps:
• While turned on, place your iGrillmini (or other iDevices product) next
to your smart device and open the iDevices Connected app.
• Tap on the gray bar located at the top of the screen to expose the
device manager. Select the product you would like to pair with
from the device manager. Your smart device will display a pairing
request. Once accepted, your smart device will pair with the
additional product and you are ready to congure your settings and
start cooking!
Mounting
• The iGrillmini‘s base is magnetic for convenient positioning on a cool
portion of your grill, smoker or other magnetic surfaces.
• The iGrillmini can be taken out of its base, rotated 180° and set back
into its base for two different viewing angles.
• The iGrillmini comes with an optional magnetic disc with an adhesive
on one side. This allows the iGrillmini to magnetically mount on a
non-magnetic surface. The magnetic disc has a protective cover on
its face to protect it from being scratched.
To mount your magnetic disc, please follow the below steps:
• Clean the surface thoroughly where the magnetic disc will be
adhered to ensure proper bonding.
• Remove the protective lm covering the adhesive on the magnetic
disc.
• Adhere the magnetic disc to your desired surface.
• Let the magnetic disc bond to the surface for at least 6-12 hours
before mounting your iGrillmini to the disc.
• Place your iGrillmini on the magnetic disc.
7
The magnetic base is not designed to withstand high heat
and it must be placed on a cool surface. If the surface is too
hot to touch, it is too hot for the iGrillmini base!
Probe Use
• Meat Probe Acceptable Temperature Range: -22°F to 572°F (-30ºC
to 300ºC)
• Pro Meat Probe and Pro Ambient Temperature Probe Acceptable
Temperature Range (sold on iDevicesinc.com): -22ºF to 700ºF (-30ºC
to 371ºC)
• The Meat Probe should always be inserted into the center of the
item being cooked for an accurate temperature reading.
• When using a standard Meat Probe, be sure to route the probe wire
where it will not be exposed to ames or temperatures exceeding
572° (300°C).
• The Pro Ambient Probe should be clipped between two grates
inside the oven. Ensure that the tip of the probe does not touch the
grates.
• The probe wrap allows for convenient storage of your probe and
is magnetic so that it can be stored under your iGrillmini when not in
use.
The colored probe indicator is for visual identication of the
probe within the app and cosmetic purposes only. It is not
designed for heat safety.
The probe should be cleaned by hand with a dishcloth,
standard dishwashing soap and warm water. The probe is
not dishwasher safe. Take precaution not to get the probe’s
wiring wet.
8
Be sure to avoid water exposure to the probes’ wiring as
well as the area where the probes’ wiring meets the probe.
The probe is not waterproof and damage may result from
water exposure. The probe should never be submersed in
water.
Temperatures below -22°F or above 572°F (-30ºC or above
300ºC) will not display in the iDevices Connected app and
will cause the probe to disappear from connection.
Probe Wrap Use
To wrap your probe:
• Hold the probe wrap so that the clip segment is on the bottom left
and the iDevices logo is legible in the center of the probe wrap.
• Snap the probe into the probe wrap’s clip, ensuring that the probe’s
body follows the contour of the probe wrap and leaves a ½ inch gap
between the probe and the wire channel of the probe wrap. The tip
of the probe should be pointed downward.
• Wrap your probe’s wire clockwise around the probe wrap.
• When you reach the adapter end of the probe wire, it can be
inserted into the probe wrap’s wire channel to secure the wrapping.
9
Using the iGrillmini
Smart LED
The Smart LED allows the iGrillmini to display the connected probe
temperature reading through the use of color. Below is a list of all of the
light combinations you will see on the Smart LED and their associated
meanings:
Connection
• Solid White: Powering off or reset complete
• Solid Blue: Conrms pairing of new device
• Blinking Blue: Awaiting pairing or no alarm set
Peak Preset
• Solid Green: Initial temperature
• Solid Yellow: Target temperature is 15° F away
• Solid Orange: Target temperature is 5° F away
• Blinking Red: Target temperature reached
• Solid Red: Target temperature reached and alarm acknowledged
Range Preset
• Solid Green: Temperature inside range
• Blinking Red: Temperature outside range
Proximity Sensor
The use of Bluetooth®Smart allows the iGrillmini to sense when a paired
smart device moves in or out of range. The iGrillmini will automatically wake
and sleep at the below distances to conserve power:
• Sleep ~ 30 feet away
• Wake ~ 5 feet away
10
Custom & Preset Alarms
Manage iPhone, iPad or iPod touch alarms:
If you are having issues hearing the alarms from the iDevices Connected
app, try these steps.
• Open Settings on your smart device
• Tap “Notication Center”
• Choose the iDevices Connected app and make sure to enable
notications, including “Sounds” and “Alerts”.
Make sure the volume setting for your phone is properly set.
If your sounds are off or set at a low setting, you may not
hear the alarm properly.
Manage iDevices Connected app alarms:
Within the app, tap “Set Preset” to the right of a connected probe’s
running temperature. This will bring you to your “Choose Preset” options.
Preset Alarms:
The iDevices Connected app offers preset alarms for many types of meats
and cooking temperatures. Tapping a preset alarm will set it. You can also
create your own custom preset alarm for any desired temperature. There
are two different types of presets:
• Peak: Alarm will sound when probe temperature reaches set peak
temperature.
• Range: Alarm will sound when probe temperature is above the high
temperature or below the low temperature.
Creating a custom preset alarm:
• Tap “Set Preset”
• Tap “Create New”
