IDW G-7 Manuale utente
www.idw-usa.com
990 N. Amelia Ave., San Dimas, CA 91773 | toll free: 877.307.2665 | ofce: 909.447.8254 | fax: 909.305.8756
G7
Instruction Manual
Instruction Manual
G7
G7
TABLE OF CONTENTS
Parts and Identification....................................2
Safety Instructions.............................................3
Installation...............................................................4
Electrical Requirements...................................4
Light Control............................................................6
Light Replacement..............................................7
Start.............................................................................8
Maintenance ..........................................................8
Cleaning................................................................. 10
Troubleshooting ................................................ 10
Warranty................................................................ 11
FOR YOUR FUTURE REFERENCE
• Thank you for using our product. This manual will guide you in getting the best use of your
cooler.
• Remember to record the model and serial number located on the back of the cooler.
• Staple your receipt to your manual. You will need it to obtain Warranty Service.
1
Model #:
Serial #:
Date of Purchase:
Instructional Manual
2
PARTS (Model SC-148/G-7)
1. Glass Door
2. Horizontal light cover for glass door
3. Glass door seal gasket
4. Upper Flat shelf
5. Shelf strip (short/long) (2/2)
6. Shelf clip (6)
7. Lower Flat shelf
8. Evaporator baffle brace (4)
9. Switch power board
10. Thermostat
11. Evaporator fan
12. Fan baffle
13. Bottom hinge
14. Evaporator
15. Evaporator baffle
16. Top hinge cover
17. Upper hinge
18. Cabinet
19. Compressor
20. Compartment grill
21. Condenser
22. Compressor base
23. Wire clip
24. Adjustable leg (4)
25. Power cord
26. Supporting board
27. LED board (6)
28. Cabinet light cover
29. Horizontal light cover for glass door (2)
30. Door stop (bottom)
G7
3
SAFETY INSTRUCTIONS
When using this appliance, always follow the basic safety precautions:
Read the entire User’s Manual before operating this appliance.1.
Use this appliance only for its intended purpose as described in this User’s Manual.2.
This cooler must be properly installed in accordance with the installation instructions before being used.3.
See grounding instructions on page 4.
IDW requires that a dedicated circuit be used for the unit. Failure to do so voids warranty.4.
Never unplug your cooler by pulling on the power cord. Always grasp the plug firmly and pull it straight out5.
from the outlet.
Unplug your cooler before cleaning or making any repairs.6. Note: If for any reason this product requires service,
we strongly recommend that a certified technician perform the service.
Immediately repair or replace all electrical cords that have become frayed or otherwise damaged. Do not7.
use a cord that shows cracks or abrasion damage along its length, the plug or the connector end.
This cooler should not be recessed or built into an enclosed cabinet. It is designed for freestanding8.
installation only.
Do not operate or store your cooler near or around explosive fumes, gasoline or other flammable vapors9.
and liquids.
Do not use flammable liquids to clean unit.10.
Setting the temperature control to the 0 position does not remove power to the light circuit, perimeter11.
heaters, or evaporator fans.
Please save these instructions!
DANGER!
Proper Disposal of the Refrigerator
PRE-CAUTION, NON-OPERATING COOLERS SHOULD HAVE:
Door removed.1.
Shelves kept in place in order to prevent any small child from climbing inside cooler.2.
FOR PROPER DISPOSAL OF COOLER: Distributors / retailers need to contact a qualified service technician:
To recover all Freon/refrigerant from the cooler1.
To remove the compressor or remove the oil from the compressor2.
Then the distributor/ retailer can contact their local metal recycling center to pick up the remaining cabinet,
shelves, etc. By law, disposal of hazardous wastes may be subject to fines and imprisonment under the
provisions of the environmental regulations. For more information please visit: http://www.epa.gov/osw/hazard/
index.htm
Instructional Manual
INSTALLATION
Ambient Environment
•Place cooler on an even surface to reduce vibration and noise.
•To transport, do not tilt the cooler beyond a 45 degree angle.
•Do not place cooler in direct sunlight or near any heat sources.
•Do not place cooler in environment temperatures that exceed 109°F.
•Do not place cooler in below normal temperatures.
•Do not place cooler in extreme humid environments, this may cause components to rust.
•Do not place cooler near constant running or splattering water, this may cause immediate damage to
refrigeration system.
•Must allow at least 2” between rear of cooler and wall for proper ventilation and heat dissipation of
cooler.
•Do not place furniture or other articles with sharp edges near the cooler in order to prevent damage to
the glass door.
PREPARATION PRIOR TO OPERATION
Unpackaging
•Remove all packaging materials before using cooler.
This includes: foam pedestal, adhesive tape (used to fix accessories) and protective gaskets.
•Inspect cooler for concealed damage. Immediately file a claim with the freight carrier if there is damage.
IDW is not responsible for damage incurred during shipping.
•Cooler must remain unplugged in an upright position for 1 hour prior to use.
•Clean the interior surface with a soft cloth and lukewarm water before operation.
•Ensure that drain hose or hoses are positioned in the pan.
•Remove plug and cord from inside the lower rear of the cooler.
Electrical Requirements
•This model operates with a 110V/60Hz power supply. Check the electrical outlet for proper voltage.
•Dedicate one outlet for the use of the cooler.
•Do not use an extension cord or any other multiple connectors as this can lead to compressor failure.
•If the cord is damaged, it must be replaced.
•For your safety, plug the unit into a grounded wall outlet. Please check with a certified electrician for
details.
WARNING: Do not use extension cords.
WARNING: Compressor warranties are void if compressor burns out due to low voltage.
WARNING: Power supply cord should not be removed!
4
G7
5
Leveling/Location
•Place unit in a well-ventilated area.
WARNING: Warranty is void if ventilation is insufficient.
•For proper operation, place the cooler on a dry, level surface
•Unit must be leveled for proper operation, this will help prevent condensation.
•The cooler should be leveled front to back and side to side with a leveler.
Shelving Installation
•Hook shelf clips on shelf strip
•Position all shelf clips equal in distance from the floor to flat shelves
•Place shelf on shelf clips
Instructional Manual
6
Removal of Light Canopy and Instruction
•The top-placed independent light canopy is removable in the G-7 cooler.
1Unplug the cooler, then unscrew (6) Screws using a Phillip’s screwdriver.
2Pull the LED light strip out of its protective cover.
3Disconnect the LED light strip at the Quick Disconnect.
4Replace the old LED light strip with a new light strip.
5To install LED lights follow the above directions in reverse order.
G7
Lamp Decoration, Illumination and Switches
•There are LED lights inside the top of the cabinets and in the door. G7 coolers have top canopy lights
and inner side lights.
Replacement of LED Lights in the Door
1Unplug the cooler.
2Remove plastic cover. Gently wedge a flat-head screwdriver under the cover to help loosen the cover.
4Disconnect light strand at the Quick Disconnect.
5Remove entire light strand.
6To install LED lights follow the above directions in reverse order.
Notes: If there are any malfunctions with the main control panel of LED lights, please contact a
professional for replacement.
7
3Unscrew light strand
Instructional Manual
8
Startup, Operation and Temperature Adjustment
Operation
•Prior to stocking cooler with product, it should be operated empty for a half an hour.
Temperature Adjustment
•It is recommended that the thermostat is set position 3 for the most efficient performance.
REPAIR AND MAINTENANCE FOR REFRIGERATION COMPONENTS
* A CERTIFIED TECHNICIAN IS REQUIRED TO REPAIR ALL REFRIGERATION COMPONENTS FOR
WARRANTY PURPOSES.
•For convenient repair, the refrigeration components (compressor, evaporator, condenser, evaporation
fan, condensation fan and filter) are designed using a split system; any component can be easily
replaced. Replacement procedure is as follows:
1Unplug the unit.
2Remove the (7) screws from the grill and then remove the grill.
3Unplug all connections and
terminals that are in need of
repair.
4Using a screwdriver, remove screws from component.
5After repair, re-install all parts using the reverse procedure.
