IEI Technology WAFER-JL-N5105 Manuale utente

3.5" SBC Supports 11th Gen 10nm Intel® Atom™ or Celeron®

On-board SoC with Dual HDMI, DP, Triple GbE LAN Port, M.2, COM,

SATA 6Gb/s, USB 3.2 Gen 2, Audio and RoHS

WAFER-JL-N5105

Quick Installation Guide

Version 1.0

February 22, 2022

Package List

WAFER-JL-N5105 package includes the following items:

1 x WAFER-JL-N5105 single board computer

1 x SATA with power cable kit

1 x QIG

Specifications

CPU:

11th Gen 10nm Intel® Celeron® N5105

Memory:

One 260-pin 2933 MHz dual-channel DDR4 SO-DIMM slot,

supporting up to 16 GB

BIOS:

AMI UEFI BIOS

Graphics Engine:

11th Gen Intel® UHD Graphics

Display Output:

Dual independent displays

1 x HDMI 1.4

1 x DP 1.4

Ethernet:

3 x PCIe 2.5 GbE with Intel® I225-V (colay with I225-LM)

External I/O Interface:

2 x USB 3.2 Gen 2x1 (10Gb/s)

Internal I/O Interface:

1 x SATA 6Gb/s with 5V SATA power connector (No RAID)

2 x USB 2.0 (2x4 pin, p=2.0)

2 x RS-232 (1x9 pin, p=1.25) from EC

Embedded Controller:

ITE IT5571

Audio:

1 x HD Audio (2x5 pin, support 7.1 channel HD Audio by

AC-KIT-888HD-R10)

Front Panel:

1 x Power LED & HDD LED (1x6 pin, p=2.0)

1 x Power button (1x2 pin, p=2.0)

1 x Reset button (1x2 pin, p=2.0)

LAN LED:

3 x LAN LED (1x2 pin, p=2.0)

Expansions:

1 x M.2 A-Key 2230 for Wi-Fi & Bluetooth

1 x M.2 B-Key 3042/2280 for 5G with SIM slot (PCIe)

Digital I/O:

1 x 12-bit digital I/O (2x7 pin, p=2.0)

SMBus:

1 x SMBus (1x4 pin, p=1.25)

TPM: integrated in CPU

Fan Connector:

1 x System fan connector (1x4 pin, p=2.54)

Power Supply:

+12V DC input power (AT/ATX mode)

Power Consumption:

[email protected] (Intel® Pentium® Silver N6000 3.30 GHz TDP 6W

with one 16 GB 2933 MHz DDR4 memory)

Watchdog Timer:

Software programmable support 1–255 sec. system reset

Operation Temperature: -20°C –60°C

Storage Temperature: -30°C –70°C

Operation Humidity: 5% –95%, non-condensing

Dimensions: 115 mm x 165 mm

Weight: GW:600 g / NW:250 g

Ordering Information

WAFER-JL-N5105-R10:

3.5" SBC Supports 11th Gen 10nm Intel® Atom™ or Celeron®

On-board SoC with Dual HDMI, DP, Triple GbE LAN Port, M.2, COM,

SATA 6Gb/s, USB 3.2 Gen 2, Audio and RoHS

CB-USB02A-RS:

Dual-port USB 2.0 cable, 210mm, p=2.0

32005-003500-200-RS:

RS-232/422/485 cable, 250mm, p=1.25

19XM0B619-0002001-000-RS:

Cooler module, 157 mm x 100 mm x 20 mm, with pad and fan

19XM0B619-0002002-000-RS:

Cooler module, 157 mm x 100 mm x 20 mm, with pad

All the drivers and utility for the

WAFER-JL-N5105 are available on IEI

Resource Download Center. Type

WAFER-JL-N5105 and press Enter to

find all the relevant software, utilities, and

documentation. To install software from

the downloaded ISO file, mount the file

as a virtual drive to view its content.

IEI Resource Download Center

https://download.ieiworld.com

Jumpers Setting and Connectors

LABEL

FUNCTION

J_CMOS1

Clear CMOS button

J_ATX_AT1

AT/ATX power mode setting

ME_FLASH1

ME override setting jumper

AUDIO1

Internal audio connector

PWR1

ATX 12V power connector

DIO1

Digital I/O connector

CPU_FAN1

Fan connector

F_PANEL1

Power LED & HDD LED connector

JLAN_LED1

LAN1 link LED connector

JLAN_LED2

LAN2 link LED connector

JLAN_LED3

LAN3 link LED connector

PWR_BTN1

Power button connector

RST_BTN1

Reset button connector

COM1, COM2

RS-232 serial port connectors

SATA1

SATA 6Gb/s connectors

SATA_PWR1

SATA power connector

I2C1

SMBus connector

JSPI1

Flash SPI ROM connector

USB2_CN1

Internal USB 2.0 connector

M2_1

M.2 B-key slot

M2_A1

M.2 A-key slot

SIM1

SIM slot

LAN1, LAN2, LAN3

External 2.5GbE RJ-45 connectors

USB1

External USB 3.2 Gen 2x1 Type-A connector

DP1

External DisplayPort connector

HDMI1

External HDMI connector

J_CMOS1: Clear CMOS Button

PIN NO.

DESCRIPTION

NC (default)

Keep CMOS Setup

(Normal Operation)

Press button

Clear CMOS Setup

J_ATX_AT1: AT/ATX Power Mode Setting

PIN NO.

DESCRIPTION

Short A - B

ATX Power Mode (default)

Short B - C

AT Power Mode

ME_FLASH1: ME Override Setting Jumper

PIN NO.

DESCRIPTION

Open

Disable (default)

Short

Enable

AUDIO1 : Internal Audio Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

HDA_SYNC_R

HDA_BIT_CLK_R

HDA_SDOUT_R

HDA_PCBEEP_R

HDA_SDIN_R

HDA_RST#_R

P5V

GND

P12V

GND

PWR1: ATX 12V Power Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

+12V

GND

+12V

DIO1 : Digital Input/Output Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

VCC

DOUT5

DOUT4

DOUT3

DOUT2

DOUT1

DOUT0

DIN5

DIN4

DIN3

DIN2

DIN1

DIN0

CPU_FAN1: Fan Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

+12V

FANIO

PWM

F_PANEL1: Power LED & HDD LED Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

VCC

GND

PWR_LED+

PWR_LED-

HDD_LED+

HDD_LED-

JLAN_LED1: LAN1 Link LED Connector

DESCRIPTION

+3.3V

LAN1_LED_LNK#_ACT

JLAN_LED2: LAN2 Link LED Connector

DESCRIPTION

+3.3V

LAN2_LED_LNK#_ACT

JLAN_LED3: LAN2 Link LED Connector

DESCRIPTION

+3.3V

LAN3_LED_LNK#_ACT

RST_BTN1: Reset Button Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

Reset+

Reset-

PWR_BTN1: Power Button Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

PWR_BTN+

PWR_BTN-

COM1, COM2: RS-232 Serial Port Connectors

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

DCD

DSR

RXD

RST

TXD

CTS

DTR

GND

SATA1: SATA 6Gb/s Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

SATA_RX‐

SATA_TX+

SATA RX+

SATA_TX‐

GND

N/C

SATA_PWR1: SATA Power Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

+5V

GND

I2C1: SMBus Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

SMB_CLK

SMB_DATA

+5V

JSPI1: Flash SPI ROM Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

+3.3V

SPI_CS#

SPI_SO

SPI_CLK

SPI_SI

GND

USB2_CN1: Internal USB 2.0 Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

VCC

GND

USB_DATA-

USB_DATA+

USB_DATA-

GND

VCC

M2_1: M.2 B-key Slot

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

CONFIG_3

+3.3V

GND

+3.3V

GND

POWER_OFF

USB_D+

W_DISABLE

USB_D-

DAS/DSS#

GND

Module Key

N/C

CONFIG_0

N/C

GNSS_DISABLE

GND

N/C

PCIE_RXN1

UIM_RST

PCIE_RXP1

UIM_CLK

GND

UIM_DATA

PCIE_TXN1

UIM_VCC

PCIE_TXP1

DEVSLP

GND

N/C

PCIE_RXN0

N/C

PCIE_RXP0

N/C

GND

N/C

PCIE_TXN0

N/C

PCIE_TXP0

PERST#

GND

CLKREQ#

REFCLKN

PEWAKE

REFCLKP

N/C

GND

N/C

WWAN_RST

N/C

PEDET

+3.3V

GND

+3.3V

GND

+3.3V

CONFIG_2

M2_A1: M.2 A-key Slot

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

+V3.3A

USB+

+V3.3A

USB-

GND

Module Key

GND
