MPC-50A
10.4"LCD Panel PC
User Manual
Version 1.1
2
Copyright Notice
©Copyright 2003 by ICP Electronics Inc. All Rights Reserved.
The information in this document is subject to change without prior notice in order
to improve reliability, design and function and does not represent a commitment on
the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights
are reserved. No part of this manual may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Trademarks
MPC-50A is a registered trademark of ICP Electronics Inc. IBM PC is a registered
trademark of International Business Machines Corporation. Intel is a registered
trademark of Intel Corporation. Other product names mentioned herein are used
for identification purposes only and may be trademarks and/or registered
trademarks of their respective companies. If you have any questions or need other
information, please visit our web site.
http://www.ieiworld.com
3
Table of Contents
CHAPTER 1 PRODUCT INFORMATION.............................................................................4
1.1 GENERAL INFORMATION...........................................................................................................4
1.2 PRODUCT SPECIFICATIONS......................................................................................................4
1.3 CHECK LIST ..............................................................................................................................5
1.4 MECHANICAL DIMENSIONS......................................................................................................6
1.5 DISPLAY MODULE (MPC-50A)..............................................................................................6
CHAPTER 2 SYSTEM SETUP...................................................................................................6
2.1 MPC-50A PANEL PC INSTALLATION......................................................................................7
2.2 DISK DRIVE INSTALLATION.....................................................................................................8
2.3 POWER SUPPLY INSTALLATION................................................................................................9
2.4 COOLING FAN INSTALLATION ..................................................................................................9
2.5 BACKPLANE AND CPU CARD INSTALLATION ........................................................................10
2.6 COVER INSTALLATION............................................................................................................10
2.7 PANEL MOUNTING ..................................................................................................................11
APPENDIX A POWER SUPPLY SPECIFICATION........................................................12
APPENDIX B USER MODE OSD ITEM DESCRIPTION..............................................13
APPENDIX C DIMENSIONS OF BACKPLANES.............................................................16
4
Chapter 1 Product Information
1.1 General Information
The MPC-50A, 10.4”TFT LCD 4-slot Panel PC, takes advantages of modern
flat-panel displays technology. It consists of a CPU board, a power supply and a
passive backplane for minimum size. It is an IBM PC/AT compatible computer
specially designed to meet the applications for industrial environments.
1.2 Product Specifications
zFront Panel: Meets NEMA 4
zDisk Drive Bay: Supports one slim type CD-ROM driver space and three 3.5"
open drive spaces
zCooling Fan: One 80mm cooling fan with filter
zAnti-vibration card clamp included
zOptional Backplane:
9IP-4SA backplane for ATX power supply (ACE-816AP)
9BP-4S, IP-4S IP-4S2 and IP-4S3 backplane for AT power supply
(ACE-916AP)
zDimensions: Front panel: 312(W) x 242(H) x 9(D) mm
Cabinet: 288(W) x 218(H) x 212(D) mm
zLCD Display
Display Type 10.4” TFT color
LCD model UB104S01
DIAGONAL 10.4 inch
BRIGHTNESS 250 cd/m2
TEMPERATURE 0~50℃
Color configuration R.G.B. vertical stripe
LCD MTBF 50,000 hrs
Resolution (pixel) 800(H) x600(V)
zDynapro Touch Screen (optional)
9Type: Analog Resistive
9Resolution: Continuous
9Light Transmission: Typical value 75%
9Surface Hardness: 4H (Test condition: ASTM D3363-92A)
98-wire touch screen
9Support driver: Supports DOS, Windows 3.1, 95, 98, NT, 2000,
XP, DOS OS/2
5
zPlug-in Card Size
Maximum card size is 226mm
zIndustrial Power Supply
9Type:ACE-816AP (ATX), 150 Watt
ACE-916AP (AT), 150 Watt
9Shock: 10 G peaks acceleration (11 msec duration)
9Safety: meet UL/CSA/TUV
9EMI: meet FCC/CISPR class B
zEnvironmental specifications
9Operating Temperature : 0 ~ 50℃
9Relative Humidity: 10-95% @40 , non℃-condensing
9Vibration: 5 to 17 Hz, 0.1"double-amplitude displacement,17 to 640 Hz,
1.5 G Peak to peak
1.3 Check List
zUser Manual x 1
zPower Cable x 1
zVGA Cable D-SUB 15P M TO M x 1
zRound Cable D-SUB 9P (optional) x 1
zScrew Accessories x 1
zSetting Kit x3
zChassis Supporters x 8
6
1.4 Mechanical Dimensions
The following diagram indicates the dimensions of MPC-50A.
Front panel: 312(W) x 242(H) x 9(D)mm
Cabinet: 288(W) x 218(H) x 212(D) mm
1.5 Display Module (MPC-50A)
241.9
311.9
273.0
9.0
218.0
(227.1)
211.9
Unit :mm
100.0 100.0
288.0
15
21.524.4
7
Chapter 2 System Setup
The MPC-50A(10.4.") LCD 4-slot Panel PC is easy to setup for operation. The
following sections demonstrate how to remove the upper cover, and then install
backplane, CPU card, display control card, hard disk drive and other I/O cards
required by the application.
2.1 MPC-50A Panel PC Installation
8
2.2 Disk Drive Installation
MPC-50A (10.4") provides one slim type CD-ROM drive space and Three 3.5” drive
spaces.
The following diagram shows how to install the slim CD-ROM drive and the 3.5"
FDD.
For installing the two 3.5" HDDs, please remove the bottom panel by releasing the
screws as the below diagram shown.
9
2.3 Power Supply Installation
This Panel PC is equipped with ACE-816AP or ACE-916AP power supply, which is
fastened by 4 screws as the diagram shown below.
2.4 Cooling Fan Installation
MPC-50A is equipped with one 80mm cooling fan for system. The following diagram
indicates the location of the fan.
Warning: Do not use the wet filter to filter out the dirt.
10
2.5 Backplane and CPU Card Installation
The figure below illustrates how to install the Backplane and CPU card on the
MPC-50A.
2.6 Cover Installation
Figure below illustrates how to install the cover on the MPC-50A.
