IFM QHA210 Manuale
Instructions for set-up
moneo|appliance
QHA210
V1.9 or higher
11436162 / 0005 / 2022
GB
QHA210
2
Contents
1 Preliminary note ............................................................. 3
1.1 Symbols used.......................................................... 3
1.2 Further documents...................................................... 3
2 Safety instructions............................................................ 4
3 Intended use................................................................ 5
4 Function ................................................................... 6
5 Installation.................................................................. 7
6 Electrical connection.......................................................... 8
6.1 Grounding of the housing................................................. 8
6.2 Connecting operating voltage.............................................. 8
6.3 Wiring................................................................ 8
7 Set-up..................................................................... 10
7.1 Requirements.......................................................... 10
7.2 Preparations........................................................... 10
7.3 Set-up of moneo|appliance................................................ 10
7.3.1 Adapting the hostname............................................... 11
7.3.2 Adapting the IP address - Ethernet interface 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.3.3 Set-up completed................................................... 12
7.4 Opening the appliance management system (AMS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.4.1 Requirements...................................................... 12
7.4.2 Initial login via the browser ............................................ 12
7.5 Opening moneo ........................................................ 13
QHA210
3
1 Preliminary note
You will find instructions, technical data, approvals and further information using the QR code on the
unit / packaging or at www.ifm.com.
1.1 Symbols used
Requirement
Instructions
Reaction, result
[...] Designation of keys, buttons or indications
Cross-reference
Important note
Non-compliance may result in malfunction or interference.
Information
Supplementary note
1.2 Further documents
• Software manual moneo|appliance
The documents can be downloaded at: www.ifm.com
QHA210
4
2 Safety instructions
• The unit described is a subcomponent for integration into a system.
– The system architect is responsible for the safety of the system.
– The system architect undertakes to perform a risk assessment and to create documentation in
accordance with legal and normative requirements to be provided to the operator and user of
the system. This documentation must contain all necessary information and safety instructions
for the operator, the user and, if applicable, for any service personnel authorised by the
architect of the system.
• Read this document before setting up the product and keep it during the entire service life.
• The product must be suitable for the corresponding applications and environmental conditions
without any restrictions.
• Only use the product for its intended purpose (Ò Intended use).
• If the operating instructions or the technical data are not adhered to, personal injury and/or damage
to property may occur.
• The manufacturer assumes no liability or warranty for any consequences caused by tampering with
the product or incorrect use by the operator.
• Installation, electrical connection, set-up, operation and maintenance of the product must be
carried out by qualified personnel authorised by the machine operator.
• Protect units and cables against damage.
QHA210
5
3 Intended use
IT hardware to operate moneo; incl. management system for appliance maintenance.
QHA210
6
4 Function
The appliance management system (AMS) allows the user to carry out basic maintenance tasks for
the moneo|appliance, e.g.:
• Setting the network configuration and hostnames
• Setting of date and time
• Rebooting or shutting down the moneo|appliance
• Monitoring and restarting services
• Importing software updates
• Displaying contact details for technical support
• Setting the access for remote support
• Reading log files
• Data backup
The moneo|appliance is used to run the following software:
• moneo|configure for setting the parameters of connected devices
• moneo|RTM for monitoring the process data
The required licences to operate the moneo products must be ordered separately.
QHA210
7
5 Installation
uDisconnect the power of the plant before installation.
uAttach the device to a DIN rail using the bracket on the back.
uTo remove, pull down the retaining latch with a screwdriver.
The device is rated for convection cooling.
uDo not impede the air circulation.
Observe the operating conditions for the device specified in the data sheet. Further information at:
www.ifm.com
QHA210
8
6 Electrical connection
The device must be connected by a qualified electrician.
The national and international regulations for the installation of electrical equipment must be
adhered to.
6.1 Grounding of the housing
The device is supplied with a COMBICON connector for an external voltage input of 10 - 36 VDC.
The device offers good EMI shielding and a stable grounding point on the housing.
uUse a grounding cable to connect the housing ground to earth.
6.2 Connecting operating voltage
The device is designed to be powered by an approved power supply or DC power source. The adapter
is designed for 10 - 36 VDC and 7.7 - 1.31 A, as well as a maximum temperature of 70 °C (158 °F).
Before connecting the device, make sure of the following:
1. The terminal block is suitable for 12 - 24 AWG (12A) and 7 lb-in torque. Only copper wires must be
used.
2. The nominal temperature of the input cables should be higher than 95 °C (203 °F).
Connect the cables as follows:
uInsert the positive and negative wires into the V+ and V- contacts on the terminal block.
uTighten the screws of the cable clamps to prevent the wires from coming loose.
Pin Signal Description Pin layout
1
2
V+
V-
10 – 36 VDC
1 2
6.3 Wiring
Connect the device as follows:
QHA210
9
2
3
4
5
6
7
8
1
9
1: Status LED
2: On/off switch
3: 3x USB 3.0
4: 1x USB 2.0
5: Ethernet interface A
6: Ethernet interface B
7: 2x display port
8: Voltage supply
9: Ground
For special configurations observe the device’s operating instructions.
The device has DI / DO and COM ports which are inoperative and must not be used.
QHA210
10
7 Set-up
When the operating voltage has been applied, the moneo|appliance functions according to the factory
settings. The LEDs show the status of the devices and of the interfaces.
7.1 Requirements
For the moneo|appliance set-up, the following components are required.
• Monitor with display port
• Keyboard with USB connection
7.2 Preparations
uConnect the monitor to the display port.
uConnect the keyboard to the USB port.
uConnect the mains plug.
uConnect the network cable.
1. Ethernet interface A (designation on the device) / ETH 1 (designation AMS) - sensor network
2. Ethernet interface B (designation on the device) / ETH 2 (designation AMS) - IT network
moneo|appliance
Ethernet interface Labelling on the de-
vice Description Standard IP address Subnet mask
ETH1 A Sensor network 192.168.0.100 255.255.255.0
ETH2 B IT network DHCP DHCP
Once the operating voltage has been applied, the moneo|appliance can be switched on via the on/off
switch on the front of the device. Make sure that all cables have been connected according to the
description.
7.3 Set-up of moneo|appliance
The initial set-up of the moneo|appliance is made via the connected keyboard and the monitor.
The different menu items in the appliance management system can be selected using the
keyboard. Example: The keyboard shortcut [C] opens [C) Configure the system].
uStart the moneo|appliance.
wThe text "welcome to moneo appliance” is displayed on the monitor.
uEnter the login details and confirm with [Enter].
There is no visible feedback on the monitor for the input. For example, no ***** is displayed in
the input field. The field on the monitor remains empty despite input.
User name: administrator
Password: < serial number of moneo|appliance >
The serial number is provided on the product label on the bottom of the moneo|appliance.
wIf the login details are correct, the [Simple keyboard configuration menu] appears.
uSelect the corresponding keyboard layout and confirm by clicking on [Ok].
uConfirm the successful change by clicking on [Ok].
