iGenix IG2071 Manuale utente
Please read these instructions carefully before use and retain for future reference
Before switching on your appliance,
always check for any damage which may have been caused in transit
PO Number:
USER MANUAL
IG2071
20 Litre 700W Manual Microwave - White
2
CONTENTS
Important Safety Instructions...............................................2-7
Product Specication..................................................................8
Appliance Overview...................................................................8
Installation.....................................................................................9
Operating Instructions............................................................ 10
Cleaning & Maintenance ......................................................... 11
Trouble Shooting Guide.......................................................... 12
Mains Plug Fuse Replacement ............................................... 13
Disposal Information............................................................... 13
Igenix Warranty Information ........................................... 14-15
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open
since this can result in harmful exposure to microwave energy. It is
important not to break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the
door or allow soil or cleaner residue to accumulate on sealing
surfaces.
(c) WARNING: If the door or door seals are damaged, the oven
must not be operated until it has been repaired by a competent
person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its
surface could be degraded and affect the lifespan of the apparatus
and lead to a dangerous situation.
3
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of re, electric shock, injury to persons or exposure to
excessive microwave oven energy when using your appliance, follow basic
precautions, including the following:
1. Read and follow the specic: “PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” on page 2.
2. This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised. Children less
than 8 years of age shall be kept away unless continuously supervised.
3. Keep the appliance and its cord out of reach of children less than 8
years.
4. If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a
hazard. (For appliance with type Y attachment)
WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
WARNING: It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection against
exposure to microwave energy.
WARNING: Liquids and other foods must not be heated in
sealed containers since they are liable to explode.
5. When heating food in plastic or paper containers, keep an eye on
the oven due to the possibility of ignition.
6. Only use utensils that are suitable for use in microwave ovens.
7. If smoke is emitted, switch off or unplug the appliance and keep
the door closed in order to stie any ames.
4
8. Microwave heating of beverages can result in delayed eruptive
boiling, therefore care must be taken when handling the
container.
9. The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
10. Eggs in their shell and whole hard-boiled eggs should not be
heated in microwave ovens since they may explode, even after
microwave heating has ended.
11. The oven should be cleaned regularly and any food deposits
removed.
12. Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life of
the appliance and possibly result in a hazardous situation.
13. The appliance must not be installed behind a decorative door in
order to avoid overheating. (This is not applicable for appliances
with decorative door.)
14. Only use the temperature probe recommended for this oven
(for ovens provided with a facility to use a temperature-sensing
probe.)
15. The microwave oven shall not be placed in a cabinet.
16. The microwave oven must be operated with the decorative door
open (for ovens with a decorative door.)
17. This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, ofces and other working
environments;
- by clients in hotels, motels and other residential type
environments;
- farm houses;
- bed and breakfast type environments.
18. The microwave oven is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads, slippers,
sponges, damp cloth and similar may lead to risk of injury, ignition
or re.
5
19. Metallic containers for food and beverages are not allowed
during microwave cooking.
20. The appliance shall not be cleaned with a steam cleaner.
21. The appliance is intended to be used freestanding.
22. The rear surface of appliances shall be placed against a wall.
To Reduce the Risk of Injury to Persons Grounding
Installation
DANGER
Electric Shock Hazard Touching some of the internal components
can cause serious personal injury or death. Do not disassemble this
appliance.
WARNING
Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do
not plug into an outlet until appliance is properly installed and
grounded.
This appliance must be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with
a grounding plug.The plug must be plugged into an outlet that is
properly installed and grounded.
Consult a qualied electrician or serviceman if the grounding
instructions are not completely understood or if doubt exists as to
whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire
extension cord.
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a longer
cord.
2. If a long cord set or extension cord is used:
6
1) The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on by
children or tripped over unintentionally.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for anyone other than a competent person to carry
out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy.
See the instructions on “Materials you can use in microwave oven
or to be avoided in microwave oven.” There may be certain non-
metallic utensils that are not safe to use for microwaving. If in doubt,
you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml)
along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use
it for microwave cooking.
4. Do not exceed 1 minute cooking time.
7
Materials you can use in a microwave oven
Browning dish Follow manufacturer’s instructions.The bottom of browning dish
must be at least 3/16 inch (5mm) above the turntable. Incorrect
usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not
use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic
trim. Do not use cracked or chipped dishes.
Oven cooking
bags
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Paper plates and
cups
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should
be labelled “Microwave Safe”. Some plastic containers soften, as the
food inside gets hot. “Boiling bags” and tightly closed plastic bags
should be slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Materials to be avoided in microwave oven
Aluminium tray May cause arcing.Transfer food into microwave-safe dish.
Food carton with
metal handle
May cause arcing.Transfer food into microwave-safe dish.
Metal or metal-
trimmed utensils
Metal shields the food from microwave energy. Metal trim may
cause arcing.
Metal twist ties May cause arcing and could cause a re in the oven.
Paper bags May cause a re in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and may split
or crack.
8
PRODUCT SPECIFICATION
Model: IG2071
Rated Voltage: 220-240V~ 50Hz
Rated Input Power (Microwave): 1050 W
Rated Output Power (Microwave): 700 W
Oven Capacity: 20 L
Turntable Diameter: Ø 255mm
Product Dimensions: 440 x 340 x 259 mm
Net Weight: Approx. 11kg
APPLIANCE OVERVIEW
Remove the oven and all materials from the carton and oven cavity. Your oven comes
with the following accessories:
A. Control Panel
B. Turntable Shaft
C . Turntable Ring Assembly
D. Glass Tray
E. Observation Window
F. Door Assembly
G. Safety Interlock System
• Glass Tray x1 • Turntable Ring Assembly x1 • Instruction Manual x1
A
BCDE
F
G
Turntable Installation:
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly
must always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service centre.
Hub (underside)
Glass Tray
Turntable Shaft
Turntable Ring Assembly
9
Counter-top Installation
Remove all packing material and accessories. Examine the oven for any damage such as
dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective lm found on the microwave oven cabinet surface. Do
not remove the light brown Mica cover that is attached to the oven cavity to protect the
magnetron.
Installation
1. Select a level surface that provides enough open space for the intake and/or outlet
vents.
a. The minimum installation height is 85cm.
b. The rear surface of appliance shall be placed against a wall.
IMPORTANT: Leave a minimum clearance of 30cm above the oven, a minimum
clearance of 20cm is required between the oven and any adjacent walls.
c. Do not remove the legs from the bottom of the oven.
d. Blocking the intake and/or outlet openings can damage the oven.
e. Place the oven as far away from radios and TV as possible. Operation of microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency
is the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing
appliance. If installed near or over a heat source, the oven could be damaged and
the warranty would be void.
The accessible surface may be hot during operation.
INSTALLATION
0cm 30cm
20cm
20cm
min
85cm
10
1. To set cooking power turn the
power knob to desired level.
2. To set the cooking time turn
the timer knob to desired time
per your food cooking guide.
3. The microwave oven will
automatically start cooking after
power level and time are set.
4. After the cooking time is up, a
beep will sound to indicate the
microwave has stopped.
5. If the unit is not in use, always
set time to “0”.
OPERATING INSTRUCTIONS
Function/Power Output Application
Low 17% micro. Soften ice cream
Med. Low (Defrost) 33% micro. Soup stew, soften butter or defrost
Med. 55% micro. Stew, sh
Med. High 77% micro. Rice, sh, chicken, ground meat
High 100% micro. Reheat, milk, boil water, vegetables, beverage
Note: When removing food from the oven, please ensure that the oven power
is switched off by turning the timer switch to 0 (zero). Failure to do so, and
operating the microwave oven without food in it, can result in overheating and
damage to the magnetron.
Altri manuali per IG2071
1
Indice
Altri manuali iGenix Forno a microonde
iGenix
iGenix IGM0820W Manuale utente
iGenix
iGenix IG2096 Manuale utente
iGenix
iGenix IG2980 Manuale utente
iGenix
iGenix IG1750 Manuale utente
iGenix
iGenix IG2070 Manuale utente
iGenix
iGenix IG2590 Manuale utente
iGenix
iGenix IG2800 Manuale utente
iGenix
iGenix IG2095 Manuale utente
iGenix
iGenix IG2940 Manuale utente
iGenix
iGenix IG2084 Manuale utente
