iGUIDE IMS-5 Manuale utente
1. Create a project
2. Enter wall thickness
3. Create a floor
4. Turn laser scanner ON
5. Create a scan in every space
6. Switch floors when necessary
1. Place the camera in a suitable location
2. Ensure rotator is clicked into one of three
positions
3. Press Shoot button
4. Rotate clockwise into the next position
5. Press Shoot button
6. Rotate clockwise into the next position
7. Press Shoot button
8. Align data using Pano: Move and Save
1. Copy data from USB drive to your computer
2. Open project folder in Stitch
3. Check scan data alignment
4. Check panorama alignment and color
5. Disable panoramas if desired
6. Export data
7. Upload data to manage.youriguide.com
MAPPING SPACE CREATING SCANS EDITING DATA
IMS5 INDICATORS
QUICK REFERENCE
SURVEY
SYSTEM BATTERY
LEVEL
SYSTEM BATTERY
TIME REMAINING
CAMERA TILT
INDICATOR
DSLR BATTERY
LEVEL
MOVEMENT SPEED
INDICATOR
LASER SCANNER
ROTATOR
SYSTEM
CONTROLLER
SYSTEM BATTERY
CHARGING PORT
SHOOT
STILL PICTURE
RELOAD
SHRINK MAP
QUICK START GUIDE
Plug the AC adapter into the battery holder
attached to the system to charge the main
battery
Insert the DSLR battery into the DSLR charger
Wait until charging is complete before using the
system for the first time
Go to the software section of
manage.youriguide.com and download Stitch
Place the camera on a tripod
Press the power button on the system controller
Turn the DSLR camera ON
Connect to the camera’s Wi-Fi hotspot
(hotspot name: planitar-xxxxxx, password:
p1234567)
Enter the URL 192.168.5.1 into your browser
address bar (save the website to the
home screen for quick access)
Go to Manage tab and enter a new secure Wi-Fi
password. Tap Save Settings button
CONNECT
CONNECT
CHARGE CONTACT
Sales
1-519-568-1723 x1200
1-844-568-1723 x1200 (Toll-Free)
iGUIDE Operator Support
1-519-568-1723 x1100
1-844-568-1723 x1100 (Toll-Free)
iGUIDE Operator Billing
1-519-568-1723 x1003
1-844-568-1723 x1003 (Toll-Free)
Planitar Inc. rev 2.0
Thank you for choosing the iGUIDE IMS-5 Camera System.
To get started:
