IKEA NUTID MWC 6 Manuale utente

NUTID

MWC6

ENGLISH 4

Read carefully and keep for future

reference.

Do not heat, or use ammable materials in

or near the oven. Fumes can create a re

hazard or explosion.

Do not use your microwave oven for drying

textiles, paper, spices, herbs, wood, owers,

fruit or other combustible materials.

Fire could result.

If material inside / outside the oven should

ignite or smoke is observed, keep oven door

closed and turn the oven off. Disconnect the

power cord or shut off power at the fuse or

circuit breaker panel.

Do not over-cook food. Fire could result.

Do not leave the oven unattended,

especially when using paper, plastic or

other combustible materials in the cooking

process. Paper can char or burn and some

plastics can melt if used when heating foods.

Do not use corrosive chemicals or vapors

in this appliance. This type of oven is

specically designed to heat or cook food.

It is not designed for industrial or laboratory

use.

Only allow children to use the appliance

under adult supervision and after adequate

instructions have been given, so that the

child is able to use the appliance in a

safe way and understands the hazards of

improper use.

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

unless used under the supervision of a

person responsible for their safety.

WARNING! Accessible parts may

become hot during use, young children

should be kept away.

Do not use your microwave oven for heating

anything in airtight sealed containers. The

pressure increases and may cause damage

when opening or may explode.The door

seals and the door seal areas must be

regularly inspected for damage. If these

areas are damaged the appliance should

not be operated until it has been repaired

by a trained service technician.

IMPORTANT: Eggs: Do not use your

microwave oven for cooking or

reheating whole eggs with or without shell

since they may explode even after

microwave heating has ended.

Importantprecautions

General

This appliance is designed for domestic use

only!

The appliance should not be operated

without food inside. Operation in this

manner is likely to damage the appliance.

If you practice operating the oven, put a

glass of water inside. The water will absorb

the microwave energy and the oven will not

be damaged.Do not use the cavity for any

storage purposes.

Remove wire twist-ties from paper or plastic

bags before placing bag in the oven.

Deep-frying

Do not use your microwave oven for deep-

frying, because the oil temperature cannot

Safetyinformation 4

Productdescription 6

Controlpanel 8

Dailyuse 8

Cleaningandmaintenance 18

Whattodoif... 19

Technicaldata 20

Environmentalconcerns 21

IKEAGUARANTEE 22

SafetyInformation

Tableofcontents

ENGLISH 5

be controlled.

Use hot pads or oven mitts to prevent burns,

when touching containers, oven parts, and

pan after cooking.

Liquids

E.g. beverages or water. Overheating

the liquid beyond boiling point can occur

without evidence of bubbling. This could

result in a sudden boil over of the hot liquid.

To prevent this possibility the following steps

should be taken:

1. Avoid using straight-sided containers with

narrow necks.

2. Stir the liquid before placing the container

in the oven and let the teaspoon remain in

the container.

3. After heating, allow standing for a

short time, stirring again before carefully

removing the container from the oven.

Careful

Always refer to a microwave cookbook for

details. Especially, if cooking or reheating

food that contains alcohol.

After heating baby food or liquids in a baby

bottle or in a baby food jar, always stir and

check the temperature before serving. This

will ensure that the heat is evenly distributed

and the risk of scalding or burns can be

avoided.

Ensure the Lid and the Teat is removed

before heating!

Push-pushknobs

The knobs of this oven are aligned with

the buttons on the panel, at delivery. The

knobs will slide out if pushed and their

various functions can be accessed. It is not

necessary to have them protruding from the

panel during operation. Simply push them

back into the panel when you are done

with the setting and continue to operate the

oven.

ENGLISH 6

Productdescription

Accessories

Turntable support

Glass turntable

Baking plate

Wire rack

Baby bottle holder

1 Control Panel

2 Grill element

3 Inlet protection plate

4 Door

ENGLISH 7

General

There are a number of accessories available

on the market. Before you buy, ensure they

are suitable for microwave use.

Ensure that the utensils you use are oven

proof and allow microwaves to pass through

them before cooking.

When you put food and accessories in the

microwave oven, ensure that they do not

come in contact with the interior of the oven.

This is especially important with accessories

made of metal or metal parts.

If accessories containing metal comes in

contact with the oven interior, while the oven

is in operation, sparking can occur and the

oven could be damaged.Always ensure that

the turntable is able to turn freely before

starting the oven.

Turntablesupport

Use the turntable support under the Glass

turntable. Never put any other utensils on

the turntable support.

Fit the turntable support in the oven.

Glassturntable

Use the Glass turntable with all cooking

methods. It collects the dripping juices and

food particles that otherwise would stain

and soil the interior of the oven.

Place the Glass turntable on the turntable

support.

BakingPlate

Use the baking plate when cooking in

forced air only or when grilling. Never use it

in combination with microwaves.

WireRack

Use the wire rack when cooking and baking

with Forced Air, Grill, Forced Air Combi,

Auto Forced Air Combi or Turbo Grill Combi.

When grilling without microwaves, place

the wire rack on the baking plate in order to

elevate the food closer to the grill element in

the ceiling.

Babybottleholder

Use the baby bottle holder when heating

baby food in bottles that are too tall to

stand-alone in the oven. Please see also, the

chapter “Precautions”, for more information

about heating baby food.

ENGLISH 8

Controlpanel

1 Multifunction Knob

2 Auto

3 Stop button

4 Display

5 Start button

6 Select button

7 +/- knob

7654321

Startprotection/keylock

This automatic safety function is activated

one minute after the oven has returned to

“stand by mode”. (The oven is in “stand by”

when the 24-hour clock is displayed or if the

clock has not been set, when the display is

blank).

The door must be opened and closed e.g.

putting food into it, before the safety lock is

released. Else the display will show “DOOR”.

Pauseorstopcooking

To pause cooking:

The cooking can be paused to check, turn

or stir the food by opening the door. The

setting will be maintained for 10 minutes.

If you don’t want to continue cooking:

Remove the food, close the door and press

the STOP button.

Tocontinuecooking:

Close the door and press the

Start button Once. The cooking is resumed

from where it was paused.

Pressing the start button twice will increase

the time by 30 seconds.

A beep signal once a minute for 10 minutes

when the cooking is nished. Press the STOP

button or open the door to cancel the signal.

NOTE: the oven will only hold the settings

for 60 seconds if the door is opened and

then closed after the cooking is nished.

Doneness

Doneness is available in the following

functions:

Auto Reheat

Auto Cook

Auto Forced Air Combi

In the above functions, you have the

possibility to personally control the end

result through the Adjust doneness feature.

This feature enables you to achieve higher

or lower end temperature compared to the

default standard setting.

When using one of these functions the oven

chooses the default standard setting.

This setting normally gives you the best

result. But if the food you heated became

too warm to eat at once, you can easily

adjust this before you use that function the

next time.

Dailyuse

ENGLISH 9

This is done by selecting a Doneness level

with the adjust knob right after you have

pressed the Start button.

NOTE:

The doneness can only be set or altered

during the rst 20 seconds of operation.

Doneness

Level Effect

H 2 YIELDS HIGHEST END

TEMPERATURE

H 1 YIELDS HIGHER END

TEMPERATURE

- - - - DEFAULT STANDARD SETTING

Lo1 YIELDS LOWER END

TEMPERATURE

Lo2 YIELDS LOWEST END

TEMPERATURE

Coolingdown

When a function is nished,the oven carries

out a cooling procedure.

This is normal.

After this procedure the oven switches off

automatically.

The cooling procedure can be interrupted

without any harm to the oven by opening

the door.

Kitchentimer

Use this function when you need a kitchen

timer to measure exact time for various

purposes such as cooking eggs or letting the

dough rise before baking etc.

1 2

1. Turn the multifunction knob to zero

position.

2. Turn the adjust knob to set the time to

measure.

The timer automatically starts the countdown

after 1 second.

An acoustic signal will be heard when the

timer has nished to count down.

Clock

When the appliance is rst plugged in or

after a power failure, the display is blank. If

the clock is not set, the display will remain

blank until the cooking time is set.

13/52/4/6

1. Turn the multifunction knob to zero

position.

2. Press the select button (3 seconds) until

the left-hand digit (hour’s) icker.

3. Turn the adjust knob +/- to set the hours.

4. Press the select button again. (The two

right hand digits (minutes) icker).

5. Turn the adjust knob to set the minutes.

6. Press the select button again.

The clock is set and in operation.

If you wish to remove the clock from the

display once it has been set, simply press the

Select button again for 3 seconds and then

press the Stop button.

To reinstate the clock , follow the above

procedure.

NOTE: keep the door openwhile setting

the clock. This gives you 10 minutes to

complete the setting of the Clock. Otherwise,

each step must be accomplished within 60

seconds.

ENGLISH 10

Cookandreheatwithmicrowaves

Use this function for normal cooking and

reheating, such as vegetables, sh, potatoes

and meat.

5 3

12/4

1. Turn the multifunction knob to the

microwave position.

2. Turn the adjust knob to set the cooking

time.

3. Press the select button to select power

level.

4. Turn the adjust knob to set the preferred

power level.

5 Press the start button.

Once the cooking process has been started:

the time can easily be increased in

30-second steps by pressing the Start

button. Each press increases the time with

30 seconds.

You may also alter the time by turning the

adjust knob to increase or decrease the

time.

By pressing the select button you may switch

between cooking time and power level.

Both can be altered during cooking by

turning the adjust knob after selection.

Powerlevel

Microwavesonly

Power Suggested use:

Jet (900

Reheating of beverages , water,

clear soups, coffee, tea or other

food with a high water content. If

the food contains egg or cream

choose a lower power.

750 W Cooking of sh, meat,

vegetables etc.

650 W Cooking dishes not possible to

stir.

500 W More careful cooking e.g. high

protein sauces, cheese and egg

dishes and to nish cooking

casseroles.

350 W Simmering stews,melting butter.

160 W Defrosting.Softening butter,

cheeses.

90 W Keep warm

0 W Setting the standing time

Jetstart

This function is used for quick reheating of

food with a high water content such as clear

soups, coffee or tea.

1 2

1. Turn the multifunction knob to the

microwave position. You may also alter

the time by pressing the +/- buttons to

increase or decrease the time after the

function has started.

2. Press the start button.

This function automatically starts with

maximum microwave power level and

the cooking time set to 30 seconds. Each

additional press increases the time with

30 seconds. You may also alter the time

Altri manuali per NUTID MWC 6

Indice

Altri manuali IKEA Forno

Manuali Forno popolari di altre marche

Bosch

Bosch HVA531NS0 Manuale utente

Electrolux

Electrolux EOF6P46X Manuale utente

NEFF

NEFF B44S32 5GB Series Manuale utente

Combi

Combi BLODGETT BC142GDS Manuale utente

AEG

AEG COMPETENCE 311704300 Manuale utente

Falcon

Falcon DOMINATOR PLUS G3106 Series Guida utente

Rational

Rational SCC WE 61G Manuale utente

Smeg

Smeg DOSPA38X Manuale di installazione e funzionamento

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuale utente

Miele

Miele HR 1954-2 Manuale utente

KHIND

KHIND OT50 Manuale utente

Henny Penny

Henny Penny Smoker Box Manuale utente

Lang

Lang ECOD-AP Manuale utente

AEG

AEG BEK455310M Manuale utente

Frigidaire

Frigidaire FNGE90JGR Manuale utente

Hotpoint

Hotpoint FE9 S831 JSH IX Manuale utente

GE Advantium SCB2000 Manuale utente

AEG

AEG DE401301DM Manuale utente
