IKEA SNABB VAGAD Manuale utente

SNABB

VÅGAD

ENGLISH 4

DEUTSCH 19

FRANÇAIS 37

ITALIANO 55

ENGLISH 4

Read carefully and keep for future

reference.

Do not heat, or use ammable materials in

or near the oven. Fumes can create a re

hazard or explosion.

Do not use your microwave oven for

drying textiles, paper, spices, herbs,

wood, owers, fruit or other combustible

materials. Fire could result.

If material inside / outside the oven

should ignite or smoke is observed, keep

oven door closed and turn the oven off.

Disconnect the power cord or shut off

power at the fuse or circuit breaker panel.

Do not over-cook food. Fire could result.

Do not leave the oven unattended,

especially when using paper, plastic or

other combustible materials in the cooking

process. Paper can char or burn and some

plastics can melt if used when heating

foods.

Do not use corrosive chemicals or vapors

in this appliance. This type of oven is

specically designed to heat or cook

food. It is not designed for industrial or

laboratory use.

Eggs

Do not use your microwave oven for

cooking or reheating whole eggs with or

without shell since they may explode even

after microwave heating has ended.

This appliance can be used by children

aged from 8 years and above and

persons with reduced physical, sensory or

mental capabilities or lack of experience

and knowledge if they have been given

supervision or instruction concerning

use of the appliance in a safe way and

understand the hazards involved.

Children shall not play with the appliance.

Use, cleaning and user maintenance

shall not be made by children unless they

are aged from 8 years and above and

supervised.

WARNING! The appliance and its

accessible parts may become hot

during use.

Care should be taken to avoid

touchingheating elements.

Children less than 8 years of age shall be

kept away unless continuosly supervised.

Do not use your microwave oven for

heating anything in airtight sealed

containers. The pressure increases and

may cause damage when opening or may

explode.

If the mains cord needs replacing it

should be replaced by the original mains

cord, which is available via our service

organization.

The mains cord may only be replaced by a

trained service technician.

Service only to be carried out by a trained

service technician. It is hazardous for

anyone other than a trained person to

carry out any service or repair operation,

which involves the removal of any cover,

which gives protection against exposure to

microwave energy.

Do not remove any cover.

The door seals and the door seal areas

must be regularly inspected for damage.

Safety information 4

Product description 6

Control panel 8

Daily use 9

Cleaning and maintenance 14

What to do if ... 15

Technical data 16

Installation 17

Electrical connection 17

Environmental concerns 18

Safety Information

Table of contents

ENGLISH 5

If these areas are damaged the appliance

should not be operated until it has been

repaired by a trained service technician.

WARNING!

- The power cable must be long enough for

connecting the appliance, once tted in

its housing, to the main power supply.

- For installation to comply with current

safety regulations, an allpole disconnect

switch with minimum contact gap of 3 mm

must be utilized.

Important precautions

General

This appliance is designed for domestic use

only!

This appliance is intended to be used built-

in.

Do not use it freestanding.

This appliance is intended for heating food

and beverages. Drying of food or clothing

and heating of warming pads, slippers,

sponges, damp cloth and similar may lead

to risk of injury, ignition or re.

The appliance should not be operated

without food inside. Operation in this

manner is likely to damage the appliance.

If you practice operating the oven, put a

glass of water inside. The water will absorb

the microwave energy and the oven will

not be damaged.

Do not use the cavity for any storage

purposes.

Remove wire twist-ties from paper or

plastic bags before placing bag in the

oven.

Deep-frying

Do not use your microwave oven for deep-

frying, because the oil temperature cannot

be controlled.

Use hot pads or oven mitts to prevent

burns, when touching containers, oven

parts, and pan after cooking.

Liquids

E.g. beverages or water. Overheating

the liquid beyond boiling point can occur

without evidence of bubbling. This could

result in a sudden boil over of the hot

liquid.

To prevent this possibility the following

steps should be taken:

1. Avoid using straight-sided containers

with narrow necks.

2. Stir the liquid before placing the

container in the oven and let the teaspoon

remain in the container.

3. After heating, allow standing for a

short time, stirring again before carefully

removing the container from the oven.

Careful

Always refer to a microwave cookbook for

details. Especially, if cooking or reheating

food that contains alcohol.

After heating baby food or liquids in a

baby bottle or in a baby food jar, always

stir and check the temperature before

serving. This will ensure that the heat is

evenly distributed and the risk of scalding

or burns can be avoided.

Ensure the Lid and the Teat is removed

before heating!

ENGLISH 6

Product description

Accessories

Turntable support

Glass turntable

Crisp handle

Crisp-plate

1Control Panel

2 Grill element (Quartz)

3 Cavity Lamp

4Door

ENGLISH 7

General

There are a number of accessories available

on the market. Before you buy, ensure they

are suitable for microwave use.

Ensure that the utensils you use are oven

proof and allow microwaves to pass through

them before cooking.

When you put food and accessories in the

microwave oven, ensure that they do not

come in contact with the interior of the oven.

This is especially important with accessories

made of metal or metal parts.

If accessories containing metal comes in

contact with the oven interior, while the oven

is in operation, sparking can occur and the

oven could be damaged.

Always ensure that the turntable is able to

turn freely before starting the oven

Turntable support

Use the turntable support under the Glass

turntable. Never put any other utensils on

the turntable support.

Fit the turntable support in the oven.

Glass turntable

Use the Glass turntable with all cooking

methods. It collects the dripping juices and

food particles that otherwise would stain

and soil the interior of the oven.

Place the Glass turntable on the turntable

support.

Crisp handle

Use the supplied special Crisp handle to

remove the hot Crisp plate from the oven.

Crisp-plate

Place the food directly on the Crisp-plate.

Always use the Glass turntable as support

when using the Crisp-plate.

Do not place any utensils on the Crisp-plate

since it will quickly become very hot and is

likely to cause damage to the utensil.

ENGLISH 8

Control panel

1 Multifunction knob

2 Stop button

3 Back button

4 Display

5 OK button

6 Start button

7 Adjust knob

7654321

VÅGAD

SNABB

765

321

ENGLISH 9

Start protection / key lock

This automatic safety function is activated

one minute after the oven has returned to

“stand by mode“. (The oven is in “stand by”

when the 24-hour clock is displayed or if the

clock has not been set, when the display is

blank).

The door must be opened and closed e.g.

putting food into it, before the safety lock is

released. Else the display will show “DOOR”.

Cooling down

When a function is nished, the oven

may carry out a cooling procedure. This

is normal. After this procedure the oven

switches off automatically.

The cooling procedure can be interrupted

without any harm to the oven by opening

the door.

Settings

When the appliance is rst plugged in it will

ask you to set the clock.

After a power failure the clock will ash and

needs to be reset.

Your oven has a number of functions which

can be adjusted to your personal taste.

1 2 3

1. Press the Stop button until Setting is

shown (aprox. 3 sec).

2. Use the Adjust knob to choose one of the

following settings to adjust

Clock

Sound

ECO

Brightness

3. Press the stop button to exit the settings

function and save all your changes when

you are done.

Clock

135

1. Press the OK button (the left-hand digits

(hour’s) icker).

2. Turn the Adjust knob to set the hours.

3. Press the OK button (The two right hand

digits (minutes) blink).

4. Turn the Adjust knob to set the minutes.

5. Press the OK button again.

The clock is set and in operation.

If you whish to remove the clock from the

display once it has been set simply enter the

clock setting mode again and press the Stop

button while the digits icker.

Sound

1. Press the OK button.

2. Turn the Adjust knob to turn the buzzer

ON or OFF.

3. Press the OK button again to conrm the

change.

Daily use

ENGLISH 10

Eco

1. Press the OK button.

2. Turn the Adjust knob to turn the ECO

setting ON or OFF.

3. Press the OK button again to conrm the

change.

When ECO is on, the display will

automatically turn off after a while to save

energy. It will automatically light up again

when a button is pressed or the door is

opened.

Brightness

1. Press the OK button.

2. Turn the Adjust knob to set the level of

brightness suitable to your preference.

3. Press the OK button again to conrm the

change.

Jet start

This function is used for quick reheating

of food with a high water content such as;

clear soups, coffee or tea.

1. Turn the multifunction knob until you nd

the Jet Start function.

2. Press the Start button to automatically

start with full microwave power level

and the cooking time set to 30 seconds.

Each additional press increases the time

with 30 seconds.

You may also alter the time by the Adjust

knob to increase or decrease the time.

Cook and reheat with microwaves

Use this function for normal cooking and

reheating, such as vegetables, sh, potatoes

and meat.

351 24

1. Turn the multifunction knob until you nd

the microwave function.

2. Turn the Adjust knob to set the

microwave power level.

3. Press the OK button to conrm your

selection.

4. Turn the Adjust knob to set the cooking

time.

5. Press the Start button.

Once the cooking process has been

started: the time can easily be increased

in 30-second steps by pressing the Start

button. Each press increases the time with

30 seconds.

You may also alter the time by turning the

adjust knob to increase or decrease the

time.

Pressing the Back button enables you to

change cooking time and power level. Both

can be altered with the adjust knob during

cooking.

Indice

Lingue:

Manuali Forno popolari di altre marche

Bosch

Bosch HVA531NS0 Manuale utente

Electrolux

Electrolux EOF6P46X Manuale utente

NEFF

NEFF B44S32 5GB Series Manuale utente

Combi

Combi BLODGETT BC142GDS Manuale utente

AEG

AEG COMPETENCE 311704300 Manuale utente

Falcon

Falcon DOMINATOR PLUS G3106 Series Guida utente

Rational

Rational SCC WE 61G Manuale utente

Smeg

Smeg DOSPA38X Manuale di installazione e funzionamento

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuale utente

Miele

Miele HR 1954-2 Manuale utente

KHIND

KHIND OT50 Manuale utente

Henny Penny

Henny Penny Smoker Box Manuale utente

Lang

Lang ECOD-AP Manuale utente

AEG

AEG BEK455310M Manuale utente

Frigidaire

Frigidaire FNGE90JGR Manuale utente

Hotpoint

Hotpoint FE9 S831 JSH IX Manuale utente

GE Advantium SCB2000 Manuale utente

AEG

AEG DE401301DM Manuale utente
