IKEA DJUPFRYSA Manuale utente

DJUPFRYSA

ENGLISH 4

Contents

Safety information 4

Safety instructions 5

Installation 7

Product description 9

Operation 9

First use 11

Daily use 11

Hints and tips 12

Care and cleaning 13

Troubleshooting 14

Technical information 17

IKEA GUARANTEE 18

Subject to change without notice.

Safety information

Before the installation and use of the appliance, carefully read

the supplied instructions. The manufacturer is not responsible if

an incorrect installation and use causes injuries and damages.

Always keep the instructions with the appliance for future

reference.

Children and vulnerable people safety

•This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved.

•Do not let children play with the appliance.

•Cleaning and user maintenance shall not be made by

children without supervision.

•Keep all packaging away from children.

General Safety

•This appliance is intended to be used in household and

similar applications such as:

–Farm houses; staff kitchen areas in shops, offices and other

working environments

ENGLISH 4

–By clients in hotels, motels, bed and breakfast and other

residential type environments

•Keep ventilation openings, in the appliance enclosure or in

the built-in structure, clear of obstruction.

•Do not use mechanical devices or other means to accelerate

the defrosting process, other than those recommended by the

manufacturer.

•Do not damage the refrigerant circuit.

•Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

•Do not use water spray and steam to clean the appliance.

•Clean the appliance with a moist soft cloth. Only use neutral

detergents. Do not use abrasive products, abrasive cleaning

pads, solvents or metal objects.

•Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

•If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons

in order to avoid a hazard.

Safety instructions

Installation

Warning! Only a qualified

person must install this

appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction supplied

with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure the air can circulate around

the appliance.

• Wait at least 4 hours before connecting

the appliance to the power supply. This

is to allow the oil to flow back in the

compressor.

• Do not install the appliance close to

radiators or cookers, oven or hobs.

• The rear of the appliance must stand

against the wall.

• Do not install the appliance where there

is direct sunlight.

• Do not install this appliance in areas that

are too humid or too colds, such as the

construction appendices, garages or

wine cellars.

• When you move the appliance, lift it by

the front edge to avoid scratching the

floor.

ENGLISH 5

Electrical connection

Warning! Risk of fire and

electrical shock.

• The appliance must be earthed.

• All electrical connections should be made

by a qualified electrician.

• Make sure that the electrical information

on the rating plate agrees with the

power supply. If not contact an

electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

electrical components (e.g. mains plug,

mains cable, compressor). Contact the

Service or an electrician to change the

electrical components.

• The mains cable must stay below the

level of the mains plug.

• Connect the mains plug to the mains

socket only at the end of the installation.

Make sure that there is access to the

mains plug after the installation.

• Do not pull the mains cable to disconnect

the appliance. Always pull the mains

plug.

Use

Warning! Risk of injury, burns,

electrical shock or fire.

• Do not change the specification of this

appliance.

• Do not put electrical appliances (e.g. ice

cream makers) in the appliance unless

they are stated applicable by the

manufacturer.

• Be careful not to cause damage to the

refrigerant circuit. It contains isobutane

(R600a), a natural gas with a high level

of environmental compatibility. This gas

is flammable.

• If damage occurs to the refrigerant

circuit, make sure that there are no

flames and sources of ignition in the

room. Ventilate the room.

• Do not let hot items to touch the plastic

parts of the appliance.

• Do not put soft drinks in the freezer

compartment. This will create pressure

on the drink container.

• Do not store flammable gas and liquid in

the appliance.

• Do not put flammable products or items

that are wet with flammable products in,

near or on the appliance.

• Do not touch the compressor or the

condenser. They are hot.

• Do not remove or touch items from the

freezer compartment if your hands are

wet or damp.

• Do not freeze again food that has been

thawed.

• Obey the storage instructions on the

packaging of frozen food.

Care and cleaning

Warning! Risk of injury or

damage to the appliance.

• Before maintenance, deactivate the

appliance and disconnect the mains plug

from the mains socket.

• This appliance contains hydrocarbons in

the cooling unit. Only a qualified person

must do the maintenance and the

recharging of the unit.

• Regularly examine the drain of the

appliance and if necessary, clean it. If

the drain is blocked, defrosted water

collects in the bottom of the appliance.

Disposal

Warning! Risk of injury or

suffocation.

• Disconnect the appliance from the mains

supply.

• Cut off the mains cable and discard it.

• Remove the door to prevent children and

pets to be closed inside of the appliance.

ENGLISH 6

• The refrigerant circuit and the insulation

materials of this appliance are ozone-

friendly.

• The insulation foam contains flammable

gas. Contact your municipal authority for

information on how to discard the

appliance correctly.

• Do not cause damage to the part of the

cooling unit that is near the heat

exchanger.

Installation

Warning! Refer to Safety

chapters.

Location

Refer to the assembly instructions

for the installation.

To ensure best performance, install the

appliance well away from sources of heat

such as radiators, boilers, direct sunlight etc.

Make sure that air can circulate freely

around the back of the cabinet.

Positioning

This appliance should be installed in a dry,

well ventilated indoor (garage or cellar)

also, but for optimum performance install

this appliance at a location where the

ambient temperature corresponds to the

climate class indicated on the rating plate

of the appliance:

Climate class Ambient temperature

SN +10°C to + 32°C

N +16°C to + 32°C

ST +16°C to + 38°C

T +16°C to + 43°C

Electrical Connection

Caution! Any electrical work

required to install this appliance

should be carried out by a

qualified electrician or

competent person.

Warning! This appliance must be

earthed. The manufacturer

declines any liability should these

safety measures not be

observed.

The wires in the mains lead are coloured in

accordance with the following code:

ENGLISH 7

A B

•A - green and yellow: Earth

•C - brown: Live

•D - blue: Neutral

As the colours of the wires in the mains lead

of this appliance may not correspond with

the coloured markings identifying the

terminals in your plug, proceed as follows:

1. Connect the wire coloured green and

yellow to the terminal marked either

with the letter “E“ or by the earth symbol

or coloured green and yellow.

2. Connect the wire coloured blue to the

terminal either marked with the letter

“N“ or coloured black.

3. Connect the wire coloured brown to the

terminal either marked with the “L“ or

coloured red.

4. Check that no cut, or stray strands of

wire is present and the cord clamp (E) is

secure over the outer sheath.

Make sure the electricity supply voltage

is the same as that indicated on the

appliance rating plate.

5. Switch on the appliance.

The appliance is supplied with a 13 amp

fuse (B). In the event of having to change

the fuse in the plug supplied, a 13 amp

ASTA approved (BS 1362) fuse must be

used.

Warning! A cut off plug inserted

into a 13 amp socket is a serious

safety (shock) hazard. Ensure

that it is disposed of safely.

ENGLISH 8

Product description

Product overview

1Control panel

2Freezer drawers

3Rating plate

4Defrost water drain

Coldest zone

Operation

Control panel

1 2 43 5

1Pilot light

2Temperature regulator

3Fast Freezing light

4Fast Freezing switch/Alarm reset switch

5Alarm light

Switching on

Insert the plug into the wall socket.

The pilot light will light up and you will hear

the buzzer.

ENGLISH 9

If the temperature inside the

appliance is too high the Alarm

light will blink. Active the Fast

Freezing function.

Switching off

To turn off the appliance, turn the

Temperature regulator to the "O" position.

The pilot light will switch off and you will

hear the buzzer.

Temperature regulation

The temperature is regulated automatically.

A medium setting is generally the

most suitable. However, the

exact setting should be chosen

keeping in mind that the

temperature inside the appliance

depends on:

• room temperature,

• how often the door is opened,

• the quantity of food stored,

• the location of the appliance.

1. Turn the Temperature regulator toward

lower settings to obtain the minimum

coldness.

2. Turn the Temperature regulator toward

higher settings to obtain the maximum

coldness.

Caution! If the ambient

temperature is high or the

appliance is fully loaded, and the

appliance is set to the lowest

temperatures, it may run

continuously causing frost to form

on the rear wall. In this case the

dial must be set to a higher

temperature to allow automatic

defrosting and therefore reduced

energy consumption.

Fast Freezing function

1. Press the Fast Freezing switch to

activate the Fast Freezing function.

The Fast Freezing light will light up.

2. Press the Fast Freezing switch to

deactivate the function at any time.

The Fast Freezing light will switch off.

This function stops automatically

after 52 hours.

High temperature alarm

An increase in the temperature in a

compartment (for example due to an power

failure) is indicated by flashing of the Alarm

light.

When normal conditions are restored the

Alarm light will switch off automatically.

Acoustic alarm

An acoustic alarm will sound when the

temperature inside the freezer has risen to

a point where the safe storage of frozen

food is no longer ensured.

When normal conditions are restored, the

acoustic alarm will stop.

In any case, press the Alarm

reset switch to deactivate the

acoustic alarm.

Door open alarm

An acoustic alarm will sound when the door

is left open for around 80 seconds.

When normal conditions are restored (door

closed), the acoustic alarm will stop.

In any case, press the Alarm reset switch to

deactivate the acoustic alarm.

ENGLISH 10

Altri manuali per DJUPFRYSA

Indice

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente

Teledyne

Teledyne 6712FR and Istruzioni operative
