HÄFTIGT GB

ENGLISH 4

DEUTSCH 24

Contents

Safety information 4

Safety instructions 5

Installation 7

Product description 8

Operation 9

First use 12

Daily use 12

Hints and tips 14

Care and cleaning 15

Troubleshooting 16

Technical information 19

IKEA GUARANTEE 20

Subject to change without notice.

Safety information

Before the installation and use of the appliance, carefully read

the supplied instructions. The manufacturer is not responsible if

an incorrect installation and use causes injuries and damages.

Always keep the instructions with the appliance for future

reference.

Children and vulnerable people safety

•This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved.

•Do not let children play with the appliance.

•Cleaning and user maintenance shall not be made by

children without supervision.

•Keep all packaging away from children.

General Safety

•This appliance is intended to be used in household and

similar applications such as:

–Farm houses; staff kitchen areas in shops, offices and other

working environments

ENGLISH 4

–By clients in hotels, motels, bed and breakfast and other

residential type environments

•Keep ventilation openings, in the appliance enclosure or in

the built-in structure, clear of obstruction.

•Do not use mechanical devices or other means to accelerate

the defrosting process, other than those recommended by the

manufacturer.

•Do not damage the refrigerant circuit.

•Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

•Do not use water spray and steam to clean the appliance.

•Clean the appliance with a moist soft cloth. Only use neutral

detergents. Do not use abrasive products, abrasive cleaning

pads, solvents or metal objects.

•Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

•If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons

in order to avoid a hazard.

Safety instructions

Installation

Warning! Only a qualified

person must install this

appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction supplied

with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure the air can circulate around

the appliance.

• Wait at least 4 hours before connecting

the appliance to the power supply. This

is to allow the oil to flow back in the

compressor.

• Do not install the appliance close to

radiators or cookers, oven or hobs.

• The rear of the appliance must stand

against the wall.

• Do not install the appliance where there

is direct sunlight.

• Do not install this appliance in areas that

are too humid or too colds, such as the

construction appendices, garages or

wine cellars.

• When you move the appliance, lift it by

the front edge to avoid scratching the

floor.

ENGLISH 5

Electrical connection

Warning! Risk of fire and

electrical shock.

• The appliance must be earthed.

• All electrical connections should be made

by a qualified electrician.

• Make sure that the electrical information

on the rating plate agrees with the

power supply. If not contact an

electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

electrical components (e.g. mains plug,

mains cable, compressor). Contact the

Service or an electrician to change the

electrical components.

• The mains cable must stay below the

level of the mains plug.

• Connect the mains plug to the mains

socket only at the end of the installation.

Make sure that there is access to the

mains plug after the installation.

• Do not pull the mains cable to disconnect

the appliance. Always pull the mains

plug.

Use

Warning! Risk of injury, burns,

electrical shock or fire.

• Do not change the specification of this

appliance.

• Do not put electrical appliances (e.g. ice

cream makers) in the appliance unless

they are stated applicable by the

manufacturer.

• Be careful not to cause damage to the

refrigerant circuit. It contains isobutane

(R600a), a natural gas with a high level

of environmental compatibility. This gas

is flammable.

• If damage occurs to the refrigerant

circuit, make sure that there are no

flames and sources of ignition in the

room. Ventilate the room.

• Do not let hot items to touch the plastic

parts of the appliance.

• Do not put soft drinks in the freezer

compartment. This will create pressure

on the drink container.

• Do not store flammable gas and liquid in

the appliance.

• Do not put flammable products or items

that are wet with flammable products in,

near or on the appliance.

• Do not touch the compressor or the

condenser. They are hot.

• Do not remove or touch items from the

freezer compartment if your hands are

wet or damp.

• Do not freeze again food that has been

thawed.

• Obey the storage instructions on the

packaging of frozen food.

Care and cleaning

Warning! Risk of injury or

damage to the appliance.

• Before maintenance, deactivate the

appliance and disconnect the mains plug

from the mains socket.

• This appliance contains hydrocarbons in

the cooling unit. Only a qualified person

must do the maintenance and the

recharging of the unit.

• Regularly examine the drain of the

appliance and if necessary, clean it. If

the drain is blocked, defrosted water

collects in the bottom of the appliance.

Disposal

Warning! Risk of injury or

suffocation.

• Disconnect the appliance from the mains

supply.

• Cut off the mains cable and discard it.

• Remove the door to prevent children and

pets to be closed inside of the appliance.

ENGLISH 6

• The refrigerant circuit and the insulation

materials of this appliance are ozone-

friendly.

• The insulation foam contains flammable

gas. Contact your municipal authority for

information on how to discard the

appliance correctly.

• Do not cause damage to the part of the

cooling unit that is near the heat

exchanger.

Installation

Warning! Refer to Safety

chapters.

Location

Refer to the assembly instructions

for the installation.

To ensure best performance, install the

appliance well away from sources of heat

such as radiators, boilers, direct sunlight etc.

Make sure that air can circulate freely

around the back of the cabinet.

Positioning

This appliance should be installed in a dry,

well ventilated indoor (garage or cellar)

also, but for optimum performance install

this appliance at a location where the

ambient temperature corresponds to the

climate class indicated on the rating plate

of the appliance:

Climate class Ambient temperature

SN +10°C to + 32°C

Climate class Ambient temperature

N +16°C to + 32°C

ST +16°C to + 38°C

T +16°C to + 43°C

Electrical connection

Before plugging in, ensure that the voltage

and frequency shown on the rating plate

correspond to your domestic power supply.

The appliance must be earthed. The power

supply cable plug is provided with a contact

for this purpose. If the domestic power

supply socket is not earthed, connect the

appliance to a separate earth in

compliance with current regulations,

consulting a qualified electrician.

The manufacturer declines all responsibility

if the above safety precautions are not

observed.

This appliance complies with the E.E.C.

Directives.

ENGLISH 7

Product description

Product overview

1 2

1Fan- cooling

2Led light

3Dairy compartment with lid

4Door balconies

5Bottle balcony with holder

6Freezing drawer

7Freezer drawers

8Control panel

9Rating plate

10 Vegetable drawer

11 Glass shelves

12 Bottle rack

Least cold zone

Intermediate temperature zone

Coldest zone

ENGLISH 8

Operation

Display

A+

1 2 3 4 5 6

1ON/OFF switch

2Freezer temperature regulator

3Fridge-Freezer temperature indication

button

4Display

5Function button

Alarm reset switch

6Fridge temperature regulator

Display

EA B C F GD

A) Fridge compartment indicator

B) Freezer compartment indicator

C) Positive or negative temperature

indicator

D) Temperature indicator

E) Fast Freezing function

F) Shopping function

G) Fan- cooling function

Switching on

1. After plugging the plug into the power

outlet, if the display is not illuminated,

press ON/OFF switch.

As soon as the appliance is turned on, the

following signals will appear on the control

panel:

• Positive or negative temperature

indicator will flash.

• the temperature flashes, the

background of the display is red and

you will hear a buzzer.

2. Press Function and the buzzer will go off

(also refer to "High temperature

alarm" ).

The display will show the actual freezer

temperature for a few seconds.

3. Set the desired temperature (refer to

"Temperature regulation").

ENGLISH 9

Switching off

Press the ON/OFF switch for more than 1

second to shut off the appliance.

After this, a countdown of the temperature

from -3 -2 -1 will be shown.

When the appliance is switched

off, the display also goes off.

Switching off the fridge compartment

To switch off the refrigerator compartment,

rotate the Fridge temperature setting

regulator counter- clockwise till position

"O".

Once the refrigerator compartment is shut

off, the only temperature which is indicated

is the one of the freezer compartment.

In this condition, the lighting in the

refrigerator compartment will be switched

off.

The freezer compartment will keep on

working.

Temperature Indication

Each time the Fridge-Freezer temperature

indication button is pressed, the display

indicates in sequence:

1. • The Fridge compartment indicator is

on.

• The display indicates the latest set

temperature for the fridge.

2. • The Freezer compartment indicator is

on (In normal conditions).

• The display indicates the latest set

temperature for the freezer.

Temperature regulation

The temperature within the appliance is

controlled by the Temperature regulator.

The temperature of the fridge compartment

may be regulated by rotating the Fridge

temperature regulator, and may vary

between more or less +2°C and +8°C.

The temperature of the freezer

compartment may be regulated by rotating

the Freezer temperature regulator, and

may vary between more or less -15°C and

-24°C.

For a correct storage of the food the

following temperatures should be set:

+5°C in the fridge

-18°C in the freezer.

During normal functioning the Temperature

indicator shows the temperature currently

set.

To operate the appliance proceed as

follows

1. turn the Temperature regulator

clockwise to obtain the maximum

coldness

2. turn the Temperature regulator counter-

clockwise to obtain the minimum

coldness.

The intermediate position is usually the

most suitable.

However, the exact setting should be

chosen keeping in mind that the

temperature inside the appliance

depends on:

• room temperature

• how often the door is opened

• the quantity of food stored

• the location of the appliance.

High temperature alarm

An increase in the temperature in the

freezer compartment (for example due to a

power failure) is indicated by:

• flashing temperature

• freezer compartment flashing (Freezer

compartment indicator/Door open alarm

indicator)

• sounding of buzzer

• red illumination of display

When normal conditions are restored:

• the acoustic signal shuts off

ENGLISH 10

Altri manuali per Haftigt

Indice

Lingue:

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente

Teledyne

Teledyne 6712FR and Istruzioni operative
