Ikegami ISD-A10 Manuale del proprietario

Hyper Dynamic, Super Cube DSP Color Camera

ISD-A10

Features

It realizes wide range of backlight compensation with 95dB typical/120dB maximum

of Wide Dynamic Range (WDR) function. Even in scenes of wide range illuminance,

it has capability to see a high contrast subject in a natural state.

ISD-A10 is single chip color camera employing a new 1/3-inch DPS (Digital Pixel System) imager,

which realizes a high performance and multi functions. Especially it provides a high performance

of Hyper Dynamic and smearless picture under the backlight condition. This camera provides

satisfactory performance and functions for the surveillance applications like Wide Dynamic Range,

2-way auto iris, auto-white balance and etc.

Conventional Camera

ISD-A10

Conventional Camera ISD-A10

Normal Wide Dynamic Camera ISD-A10



Image Pickup Device



Sync.



Horizontal Resolution



S/N Ratio



Minimum Sensitivity



AGC



Video Output



Electric Sensitivity-Up



White Balance



WDR Function



Iris Level



Camera ID



Lens Mount



Power Supply



Dimensions (WHD)



Weight

1/3-inch DPS Imager

Internal / Line-lock

480TV Lines

50dB

1.0 Lux/F1.4, 0.75 Lux/F1.2(AGC ON)

0.03 Lux/F1.4, 0.022 Lux/F1.2

(32 times sensitivity up)

ON (AGC, Hyper-AGC)

OFF (Low/Mid/High) Selectable

NTSC/PAL selected by a menu

Auto (Maximum 32 times)

ATW/ATW-ex/AWC/Manual Selectable

36 steps level available

Auto Adjustment

Maximum 24 characters (Alphanumeric

and symbols)

CS Mount

AC24V+/-10% 50/60Hz or DC12V(10.5~15V)

W64 x H64 x D63mm

350g (0.77 lbs) approx.

Appearance

37 Brook Avenue, Maywood, NJ 07607 Phone (201)368-9171 Fax (201)569-1626

2631 Manhattan Beach Blvd., Redondo Beach, CA 90278

Phone (310)297-1900 Fax (310)536-9550

773 Bearden Road, Waxahachie, TX 75167 Phone (972)869-2363 Fax (972)556-1057

747 Church Road, Unit C1, Elmhurst, IL 60126 Phone (630)834-9774 Fax (630)834-8689

5200 N.W. 33rd Avenue, Suite 111, Fort Lauderdale, FL 33309

Phone (954)735-2203 Fax (954)735-2227

Hyper Dynamic, Super Cube DSP Color Camera

The new DPS Imager has an exceptionally wide dynamic range. This allows

scenes to be handled that have wide range of luminance, varying from dark

to very bright.

The image provided is smear-less even in the presence of strong light. A

high level of detail can be observed in the picture even under this condition.

Fast moving objects can be captured under low light conditions.

Side View:

Video

OUT CN Camera

Setting Control

Lens CN

Power Lamp AC24V/DC12V

DC/Video
