ILVE PRO-LINE Series Istruzioni operative
EN
cod. EI33960020000EN
IT18/2018
AU11/2019
PRO-LINE, PROFESSIONAL PLUS &
MAJESTIC SERIES
GAS & INDUCTION COOKTOP
WITH ELECTRIC OVEN
FREESTANDING COOKERS
USER, OPERATING & INSTALLATION MANUAL
Although we encourage you to dive right in, as the owner of a brand new ILVE oven we’d also
like to invite you to attend a complimentary 2 hour masterclass. As part of the class you’ll
learn how to prepare and cook a number of delicious signature ILVE dishes, not to mention
our top tips for getting the most out of your ILVE oven. From improving cooking results to
general maintenance information, we know you’ll enjoy this comprehensive, fun masterclass.
Simply go to ilve.com.au/bookings or Phone 1300 MY ILVE (694 583)
YOUR FREE MASTERCLASS
ilve.com.au
Congratulations, you are now the proud owner of an ILVE cooking appliance. Thank you for
purchasing ILVE and welcome to the exciting world of cooking the ILVE way.
This instruction manual has been specially created to inform you of the full range of features your
ILVE appliance has to offer and serves as an introduction to the wonderful benefits of ILVE’s dynamic
cooking systems.
We present detailed information on each of the advanced cooking systems built into ILVE appliances.
Once you have read this section you will be able to choose the most appropriate settings for your
appliance when cooking different types of food.
We ask you to read the instructions in this booklet very carefully as this will allow you to get the best
results from using your appliance.
KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.
OPEN 24/7
ILVE ACCESSORIES ONLINE SHOP
For a wide range of Genuine ILVE accessories at the
click of a button shop.ilve.com.au
iWarranty
REGISTER YOUR WARRANTY ONLINE NOW
GO TO: https://support.eurolinx.com.au/#/form/warrantyregistration
As a part of our continued customer service offering, you can
now register your ILVE products online at
https://support.eurolinx.com.au/#/form/warrantyregistration
Just follow our simple online registration process.
Please ensure that you always keep your proof of
purchase in order for your warranty to remain valid should
you ever need to use it.
As always, you can contact us on
1300 856 411
7
OPERATION / USER
IMPORTANT SAFETY WARNINGS
First operation of the oven
INSTRUCTIONS FOR USE
Using the hob
Use of a steak grill
Proper use of burners
Use of the gas fry-top
Induction Cooktop
Electric Multifunction Oven
Professional PLUS ‘E3’ Series
Majestic Series
CLEANING AND MAINTENANCE
Bulb replacement
Removing the door
Door cleaning and Glasses
Tips for cleaning the hob
Tips for cleaning the oven and front panel
Recommendations for cleaning the cooktop
PROBLEM SOLVING
General problems
COOKING CHART
Ventilated convection oven
Static oven
8
15
16
16
17
18
21
23
31
36
42
49
49
50
51
52
53
54
56
57
59
63
64
64
64
65
66
67
67
70
70
73
75
75
97
99
101
CONTENTS
INFORMATION - To be reminded to the user
INSTALLATION
Installation of the cooker
Room ventilation
Positioning of the appliance between furniture
How to install the xing bracket
ELECTRICAL CONNECTIONS
Groups of cooking
ADJUSTMENT
Replacement of the injectors for models
Adjustments minimum GAS ow
WIRING DIAGRAM
Key
NOTES
WARRANTY
EUROLINX CONTACT INFORMATION
USER GUIDE INSTALLATION
8
IMPORTANT SAFETY
WARNINGS
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with appliance. Cleaning and user
maintenance shall not be made by children.
• This appliance must be installed by suitably qualied technicians and in line with
local regulations.
• As well as being shown on the packaging, the data plate is applied to the oven
door frame and is visible with the door open.
• These warnings refer to different models of appliances. Make sure you identify
the model you own (see the data plate).
• These warnings are valid for the countries mentioned on the data plate.
• Before using the cooker, read the instructions booklet carefully. It contains very
important information regarding safety during installation, use and maintenance.
• The instructions booklet must be kept with care for later consultation.
• Electrical safety of this cooker is guaranteed only if it is correctly grounded as
required by local regulations. It is important to ensure that these regulations
have been enforced; if in doubt, contact a skilled technician to have the electric
system checked. The manufacturer is not responsible for damage caused by a
bad grounding system.
9
OPERATION / USER
IMPORTANT SAFETY
WARNINGS
• Before powering the appliance, check that the technical features shown on the
data plate match those of the electrical system.
• Installation / adjustment must be carried out by qualied personnel.
• Make sure that air around the appliance can circulate freely.
• This appliance is not connected to an evacuation device for combustion
products, therefore ventilation of the room must be considered carefully and
meet local regulations.
• When using a gas appliance, heat and moisture are generated. Good ventilation
of the kitchen must be guaranteed by keeping the natural aeration vents open or
by installing a mechanical aeration device (range-hood). An intensive and
prolonged use of the appliance may result in the need for supplementary
ventilation such as opening a window or increasing the power of the hood (if
present).
• Do not block ventilation or heat dissipation openings.
• The supply cable (if tted) is supplied without a plug. To connect It, please refer
to the paragraph “electric connection” in the installation guide. It is
recommended to not use adapters, multiple-outlet plugs or extensions. If the
supply cable is damaged it must be replaced by an authorised service person.
• When the appliance is not in use for a prolonged time, switch off the electrical
supply and turn off the gas.
• The appliance must be used only for the purposes for which it was intended i.e.
cooking food in a domestic or similar to domestic environment. Any other use
(for example, heating a room) is incorrect and may be dangerous. The
manufacturer declines all responsibilities for damage caused by incorrect uses.
• The appliance is not destined to be activated by means of an external timer or a
remote control.
10
IMPORTANT SAFETY
WARNINGS
• The use of any electrical appliances requires that a number of fundamental rules
must be respected:
1. Never touch the appliance when you have wet or damp hands or feet;
2. Never use the appliance barefoot;
3. Avoid using extension cables;
4. Never pull the electric cable to remove it from the power socket;
5. Do not expose the appliance to atmospheric agents (rain, sun, etc...);
• CAUTION: During use of the appliance some parts may become very hot. Keep
out of reach of children. Absolutely do not touch the elements inside the oven
during or immediately after use.
• Before cleaning the appliance or carrying out maintenance, disconnect the power
supply by removing the plug from the socket or switching off the switch.
• In case of breakdown or malfunction, switch off the appliance. Do not attempt
any repairs; these must only be performed by an authorised service centre.
Always request original parts. Failure to comply with these instructions may
compromise the appliance’s safety.
• Never place unstable or deformed pans on the burners or on the electric hot-
plates as they could topple accidentally.
• When the appliance is not being used, make sure the knobs are exactly in
the “ ”/“ ”/ position.
• Don’t leave the hotplate on with no pans on it, as it would reach the temperature
fast and possibly damage the appliance and your counter tops.
• The electric plates remain hot after using them. Be careful not to touch them.
