INSTRUCTION &
OPERATIONS MANUAL:
IV605BV
OPEN 24/7
ILVE ACCESSORIES ONLINE SHOP
For a wide range of Genuine ILVE accessories at the
click of a button shop.ilve.com.au
Important safety instructions
When using electrical appliance basic safety precautions
should be followed, including the following:
warning: to reduce the risk of burns, electric shock, fire,
injury to persons or exposure to excessive microwave
energy:
1.Read all instructions before using the appliance.
2.Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals or vapors
in this appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not designed for
industrial or laboratory use.
3.Do not operate the oven when empty.
4.Do not operate this appliance if it has a damaged cord or
plug, if it is not working properly or if it has been
damaged or dropped. If the supply cord is damaged, it
must be replaced by the manufacturer or its service gent
or a similarly qualified person in order to avoid a hazard.
5.Warning: when the appliance is operated in the
combination mode, children should only use the oven
under adult supervision due to the temperatures
generated.
6.Warning: only allow children to use the oven without
supervision when adequate instructions have been given
so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
7.To reduce the risk of fire in the oven cavity:
2
a.When heating food in plastic or paper container, keep
an eye on the oven due to the possibility of ignition.
b.Remove wire twist-ties from paper or plastic bags before
placing bag in oven.
c.If smoke is observed, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
d.Do not use the cavity for storage purposes. Do not leave
paper products, cooking utensils or food in the cavity
when not in use.
8.Warning: liquid or other food must not be heated in sealed
containers since they are liable to explode.
9.Microwave heating of beverage can result in delayed
eruptive boiling, therefore care has to be taken when
handle the container.
10.Do not fry food in the oven. Hot oil can damage oven
parts and utensils and even result in skin burns.
11.Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode even after microwave heating has ended.
12.Pierce foods with heavy skins such as pota toes, whole
squashes, apples and chestnuts before cooking.
13.The contents of feeding bottles and baby jars should be
stirred or shaken and the temperature should be
checked before serving in order to avoid burns.
14.Cooking utensils may become hot because of heat
transferred from the heated food. Potholders may be
needed to handle the utensil.
3
15.Utensils should be checked to ensure that they are
suitable for use in microwave oven.
16.Warning: it is hazardous for anyone other than a trained
person to carry out any service or repair operation which
involves the removal of any cover which gives protection
against exposure to microwave energy.
17.This product with the class I equipment,the definition of
class I which protection against electric shock does not
rely on basic insulation only but which includes an
additional safety precaution, in that conductive
accessible parts are connected to the protective earthing
conductor in the fixed wiring of the installation in such a
way that conductive accessible parts cannot become live
in the event of a failure of the basic insulation. For class
b equipment is equipment suitable for use in domestic
establishments. For domestic purpose.
18.This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge,unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
19.Children should be supervised to ensure that they do not
play with the appliance.
20.The microwave oven is only used in freestanding.
21.Warning: do not install oven over a range cooktop or
other heat-producing appliance. If installed could be
4
damaged and the warranty would be avoid .
22.The accessible surface may be hot during operation.
23.The microwave oven shall not be placed in a cabinet.
24.The door or the outer surface may get hot when the
appliance is operating.
25.The temperature of accessible surfaces may be high
when the appliance is operating.
26.The appliance shall be placed against a wall.
27.Appliance is not to be used by children or persons with
reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, Unless they have been
given supervision or instruction.
28.Children being supervised not to play with appliance
29.Warning: if the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person
30.The instructions shall state that appliances are not
intended to be operated by means of an external timer or
separate remote-control system.
31.The microwave oven is for household use only and not
for commercial use.
32.Never remove the distance holder in the back or on the
sides, as it ensures a minimum distance from the wall for
air circulation.
33.Please secure the turn table before you move the
appliance to avoid damages.
34.Caution: it is dangerous to repair or maintain the
5
appliance by no other than a specialist because under
these circumstances the cover have to be removed which
assures protection against microwave radiation. This
applies to changing the power cord or the lighting as well.
Send the appliance in these cases to our service central.
35.The microwave oven is intended for defrosting, cooking
and steaming of food only.
36.Use gloves if you remove any heated food.
37.Caution! Steam will escape, when opening lids or
wrapping foil.
38.If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle.
This appliance can be used by children aged from 8
years and above and persons with educated
physical,sensory or mental capabilities or lack of experi-
ence and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe
way and understand the hazards involved.Children shall
not play with the appliance.Cleaning and user mainte-
nance shall not be made by children unless they are older
than 8 and supervised.
Keep the appliance and its cord out of reach of children
less than 8 years.
CAUTION: Hot surface.
6
SPECIFICATIONS
Power consumption:
Output:
Grill Heater:
Operating Frequency:
Outside Dimensions:
Oven Cavity Dimensions:
Oven Capacity:
Uncrated Weight:
0W
2,450MHz
592mm(L) X 380mm(W) X 390mm(H)
330mm(L) X 330mm(W) X 230mm(H)
25 litres
Approx. 16.5kg
RADIO INTERFERENCE
Microwave oven may cause interference to your radio, TV, or similar equipment. When interference occurs, it may be
eliminated or reduced by the following procedures.
a. Clean the door and sealing surface of the oven.
b. Place the radio, TV, etc. as far away from your microwave oven as possible.
c. Use a properly installed antenna for your radio, TV, etc. to get a strong signal reception.
BEFORE YOU CALL FOR SERVICE
1. If the oven will not perform at all, the display does not
appear or the display disappears:
a) Check to ensure that the oven is plugged in securely. If it
is not, remove the plug from the outlet, wait 10 seconds
and plug it in again securely.
b) Check the premises for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be operating properly,
test the outlet with another appliance.
2. If the microwave power does not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely closed to
engage the safety interlocks. Otherwise, the microwave
energy will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT THE AUTHORIZED SERVICE AGENT.
Note:
The appliance is for household use for heating food and beverages using electromagnetic energy and for indoor
use only.
40
1 00W
900W
2
220-240V~50Hz,1
7
INSTALLATION
1. Make sure all the packing materials are removed from
the inside of the door.
2. Inspect the oven after unpacking for any visual
damage such as:
Misaligned Door
Damaged Door
Dents or Holes in Door Window and Screen
Dents in Cavity
If any of the above are visible, DO NOT use the
oven.
3. This Microwave Oven weighs 1
placed on a horizontal surface strong enough to
WARNING-THIS APPLIANCE MUST BE EARTHED.
1. The plug socket should be within easy reach
of the power cord
2. This oven requires 1.5 KVA for its input.
consultation with service engineer is
suggested when installing the oven.
support this weight.
4. The oven must be placed away from high temperature
and steam.
5. DO NOT place anything on top of the oven.
6. DO NOT remove the turn -table drive shaft.
7. As with any appliance, close supervision is necessary
when used by children.
CAUTION:This oven is protected internally by
ac 250V,10 Amp Fuse.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains leads of the appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with the
letter E or by the earth symbol coloured green of green-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.
7.6 kg and must be
