AMAZON2 SERIES

Tiny Form Factor GigE Camera

User Operation Manual

For GigE Cameras IMx-7xxG Models

USER MANUAL VERSION 1.00

Released Nov. 2012

#616, Mega Valley, Gwanyang 2-dong, Dongan-gu,

Anyang-si, Gyeonggi-do, 431-767, Korea

Phone : 82-31-423-9801 Fax : 031-423-9803

Legal Notice.

For Customers in U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense. You are cautioned that any changes or modifications not expressly approved in this manual

could void your authority to operate this equipment. The shielded interface cable recommended in this manual must be used

with this equipment in order to comply with the limits for a computing device pursuant to Subpart J of Part 15 of FCC Rules.

For customers in Europe

This apparatus has been certified to meet or exceed the standards for CE compliance per the Council Directives. Pertinent

testing documentation is available for verification.

For customers in Canada

This apparatus complies with the Class B limits for radio noise emissions set out in the Radio Interference Regulations.

Pour utilisateurs au Canada

Cet appareil est conforme aux normes Classe B pour bruits radioélectriques, spécifiées dans le Règlement sur le brouillage

radioélectrique.

Life support applications

These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can

reasonably be expected to result in personal injury. Allied customers using or selling these products for use in such applications

do so at their own risk and agree to fully indemnify allied for any damages resulting from such improper use or sale.

Before You Start

This manual should help you in the installation and setting up of the camera; and we recommend that you carefully follow the

instructions described. To ensure that your warranty remains valid, please read the manual carefully before using the camera.

DO NOT disassemble, modify or repair the camera. There are no user serviceable parts inside and disassembling the camera

may void the warranty. For prevention of fire or electric shock, DO NOT removes screws or covers from the camera.

Operation in a wet environment is NOT recommended and the camera SHOULD NOT be exposed to rain or moisture.

For prolong life and the protection of the camera’s CCD, do not point the camera directly at the sun or a strong spotlight which

may result in CCD blooming and permanent damage.

DO NOT operate the camera beyond the operation temperature range stated and AVOID usage in conditions exceeding 90%

humidity.

DO NOT use an unregulated power supply source to prevent damage to the camera’s circuits.

Use soft materials such as lens tissue or cotton tipped applicator with ethanol for CCD faceplate cleaning ONLY when necessary

and AVOID contact with fingers or any hard object. Do not use solvent, abrasives or detergent when cleaning the camera body.

Warranty shall be voided for improper use of the camera or fault caused by the user or damage caused by other equipment due

to negligence

Warranty

IMI TECH warrants the original components free of defects for one year from purchase date. This warranty covers failures and

damage due to defect, which may occur during normal use. It does not cover damages or failure resulting from mishandling,

abuse, misuse or modification. An RMA number must be obtained in advance for every repair or replacement.

Disclaimer

The information in this document has been carefully checked and is believed to be reliable. However, IMI TECH assumes no

responsibility for inaccuracies. There is no legal obligation to document internal relationships in any functional module of its

products, in either hardware or software

All the materials in this document are protected by copyright and other laws for intellectual property. They are not allowed to be

copied, reproduced or modified for any use without the permission of IMI Tech. IMI TECH reserves the right to make changes in

specifications, functions or designs at any time and without any notice. The company names in this document may be the

trademarks and trade-names of their respective owner; and are hereby acknowledged.

Amazon2 Series Operation Manual

1. Introduction.................................................................................................................. 1

1.1. Overview...............................................................................................................................................................1

1.2. Components ..........................................................................................................................................................2

1.3. Optional Accessories...............................................................................................................................................3

1.4. Dimension and Description .....................................................................................................................................4

1.5. Camera Interface ...................................................................................................................................................4

1.5.1. Trigger/Strobe/Power Connector Port.............................................................................................................5

1.5.2. Status LED for Network Connection................................................................................................................5

1.5.3. Camera Power Requirement ..........................................................................................................................5

1.6. Electrical Operating Condition .................................................................................................................................6

1.7. Pixel Data..............................................................................................................................................................7

1.8. Environmental Requirements ..................................................................................................................................9

2. Basic Installation........................................................................................................ 10

2.1. Recommended System Requirement .....................................................................................................................10

2.2. Hardware Installation...........................................................................................................................................10

2.3. Software Installation ............................................................................................................................................11

3. AMAZON2 Series Camera Specifications..................................................................... 12

3.1. Black and White Cameras .....................................................................................................................................12

3.1.1. IMB-720G Specification ...............................................................................................................................12

3.1.2. IMB-717G Specification ...............................................................................................................................13

3.1.3. IMB-716G Specification ...............................................................................................................................14

3.1.4. IMB-715G Specification ...............................................................................................................................15

3.1.5. IMB-712G Specification ...............................................................................................................................16

3.1.6. IMB-711G Specification ...............................................................................................................................17

3.1.7. IMB-710G Specification ............................................................................................................................... 18

3.2. Color Cameras .....................................................................................................................................................19

3.2.1. IMC-720G Specification ...............................................................................................................................19

3.2.2. IMC-717G Specification ...............................................................................................................................20

3.2.3. IMC-716G Specification ...............................................................................................................................21

3.2.4. IMC-715G2 Specification..............................................................................................................................22

3.2.5. IMC-715G Specification ...............................................................................................................................23

3.2.6. IMC-712G Specification ...............................................................................................................................24

3.2.7. IMC-711G Specification ...............................................................................................................................25

3.2.8. IMC-710G Specification ...............................................................................................................................26

3.3. Spectral Sensitivity...............................................................................................................................................27

3.3.1. Amazon2 Series B&W Cameras ...................................................................................................................27

3.3.2. Amazon2 Series Color Cameras....................................................................................................................30

4. Basic Operation and Features..................................................................................... 34

4.1. Brightness ...........................................................................................................................................................34

4.2. Auto Exposure Control..........................................................................................................................................35

4.3. Sharpness............................................................................................................................................................36

4.4. White Balance......................................................................................................................................................36

4.5. Hue & Saturation .................................................................................................................................................37

4.6. Gamma ...............................................................................................................................................................38

4.7. Shutter................................................................................................................................................................39

4.8. Gain....................................................................................................................................................................40

4.9. Trigger & Strobe ..................................................................................................................................................40

4.9.1. Supported Trigger....................................................................................................................................... 40

4.9.2. Trigger and Strobe Signal Relation ...............................................................................................................41

4.9.3. Timing Diagram for External Trigger and Shutter and Strobe .........................................................................42

4.9.4. Trigger & Strobe delay.................................................................................................................................43

4.9.5. Trigger Mode 0 ...........................................................................................................................................44

4.9.6. Trigger Mode 1 ...........................................................................................................................................44

4.9.7. Trigger Mode 2 ...........................................................................................................................................44

4.9.8. Trigger Mode 4 ...........................................................................................................................................45

4.9.9. Trigger Mode 5 ...........................................................................................................................................45

4.9.10. Trigger Mode 15.......................................................................................................................................... 46

4.10. Strobe Control Register.....................................................................................................................................47

4.11. Trigger Delay Control ........................................................................................................................................48

4.11.1. Strobe Delay / Duration Table......................................................................................................................49

4.11.2. Color (Bayer) Patterns Conversions ..............................................................................................................50

5. Advanced Features ..................................................................................................... 51

5.1. Binning Mode.......................................................................................................................................................51

5.1.1. Full Binning ................................................................................................................................................51

5.2. Partial Scan ......................................................................................................................................................... 51

5.3. One-Shot and Multi-Shot ......................................................................................................................................52

5.4. Time Stamp Register. ...........................................................................................................................................52

5.5. LUT (Lookup table) ..............................................................................................................................................53

5.5.1. 4 step knee lookup table .............................................................................................................................53

5.5.2. User defined lookup table............................................................................................................................54

5.6. User defined AE...................................................................................................................................................55

5.7. One Pixel Snow Noise Remove..............................................................................................................................56

5.8. PIO Control Register.............................................................................................................................................58

6. User Defined Registers ............................................................................................... 59

6.1. User Defined Address...........................................................................................................................................59

7. Video Formats and Modes........................................................................................... 62

7.1. Supported Video Modes by Camera Models............................................................................................................64

7.1.1. IMB-720G...................................................................................................................................................64

7.1.2. IMC-720G...................................................................................................................................................64

7.1.3. IMB-717G...................................................................................................................................................64

7.1.4. IMC-717G...................................................................................................................................................64

7.1.5. IMB-716G...................................................................................................................................................64

7.1.6. IMC-716G...................................................................................................................................................65

7.1.7. IMC-715G2.................................................................................................................................................65

7.1.8. IMB-715G...................................................................................................................................................65

7.1.9. IMC-715G...................................................................................................................................................65

7.1.10.IMB-712G...................................................................................................................................................65

7.1.11. IMC-712G...................................................................................................................................................66

7.1.12. IMB-711G...................................................................................................................................................66

7.1.13. IMC-711G...................................................................................................................................................66

7.1.14. IMB-710G...................................................................................................................................................66

7.1.15. IMC-710G...................................................................................................................................................66

8. Firmware Update ........................................................................................................ 68

9. Technical Support ....................................................................................................... 68

AMAZON2 SERIES Operation Manual Page 1

Pioneer in Digital Vision Technology

1. Introduction

1.1. Overview

IMI TECH’s Amazon2 Series is compliant with the GigE Vision standard and supports GenIcam Standard. Fairly

new in the image processing industry, GigE is gaining more interest thanks to users who are familiar with the

Ethernet interface and technology. This new interface is expected to lift the barriers of bandwidth limitation found in

other interfaces such as FireWire and USB 2.0. It also resolves the limitation of cable length by supporting 100

meter distance with conventional CAT-5 cable. As GigE is a relatively new standard, we expect more and more

customers to demand new and additional feature support. We also expect a growing desire for software

interoperability due to GigE’s excellent network interface capability. The very small form factor design has expanded

implementation and broadened application areas by eliminating the limits that currently exist due to size and weight.

A large selection of cameras is available and additional cameras are scheduled to be added to the Amazon2 Series

as well. These will consist of various sensor sizes (1/4”, 1/3” 1/2”, 1/1.8”) and resolution (VGA, XGA, SXGA, UXGA)

both in color and black and white. The Amazon2 Series consist of the following models.

AMAZON2

SERIES Model Name CCD(Progressive) Resolution FPS at Max Resolution

Black &

White

IMB-710G 1/4” 656 x 488 100

IMB-711G 1/3” 656 x 484 91

IMB-712G 1/2” 656 x 484 91

IMB-715G 1/3” 1032 x 776 35

IMB-716G 1/3” 1288 x 964 30

IMB-717G 1/2” 1388 x 1040 20

IMB-720G 1/1.8” 1624 x 1232 16

Color

IMC-710G 1/4” 652 x 484 100

IMC-711G 1/3” 652 x 484 92

IMC -712G 1/2” 652 x 484 91

IMC -715G 1/3” 1032 x 772 35

IMC -715G2 1/3” 1280 x 720 30

IMC -716G 1/3” 1288 x 960 30

IMC -717G 1/2” 1388 x 1036 20

IMC -720G 1/1.8” 1624 x 1228 16

AMAZON2 SERIES’ unique features include a lookup table and external trigger mode 0, 1, 2, 4, 5, 15, one-shot

and multi-shot, a wide range of shutter speeds (1us~3600s), partial scan, and binning modes (2x2 for B&W). All

of these features provide maximum flexibility for a wide variety of applications. AMAZON2 SERIES input signals

are isolated optically to ensure quality images acquisition without the risk of noise degrading the input signal.

Industrial screw lock cable support has been added for more reliable connectivity. AMAZON2 SERIES‘s firmware

Page 2 AMAZON2 SERIES Operation Manual

Pioneer in Digital Vision Technology

can be upgraded via GigE and the latest versions are available through our website together with IMI TECH’s SDK

and demo applications.

1.2. Components

Component

Following components are either included in the camera or can be downloaded from the IMI website.

AMAZON2 SERIES

CAMERA UNIT

GigETM Digital Imaging CD(Website)

Driver

Demo Software

Manuals

User Manual

Downloadable Software

Latest Update of Firmware and Demo Applications are available on our website.

http://www.imi-tech.com

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Imi Tech Macchina fotografica digitale

Imi Tech

Imi Tech PEARL IMB-20FT Istruzioni per il montaggio

Imi Tech

Imi Tech Mx-xxxxG Series Istruzioni per il montaggio

Imi Tech

Imi Tech IMB-5200FT Istruzioni per il montaggio

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
