Operating Manual
Impacts Filter-Unit
DC4025
DC4025 Bedienungsanleitung/Operating Manual
Technische Daten/Technical Data
1
Chapter 1
1.1Rating PAGE: 2
1.2Unit – specifications PAGE: 2
1.3 Operative range and correct usage PAGE: 3
1.4Stand-by power supply ( generator) PAGE: 3
1.5 Advice for operators PAGE: 4
Bedienungsanleitung/Operating Manual DC4025
Technische Daten/Technical Data
2
1.1 Rating
Machine: IMPACTS FILTERUNIT
Maschinen-Type : DC4025
Manufacturer: IMPACTS GmbH
Zöllnerstr. 7
D-51105 Overath
1.2 Unit – specifications
Dimensions:
FILTER
DC 4025
Lenght 1620 mm
Width 795 mm
Height 1400 mm
Weight 460 kg
Connected loads of the electrical system:
DC4025 Power Consumption Amps
Compressor 1,5 kW max. 3,2A
Blower 4,0 kW max. 7,9A
Filter total 5,5 kW max. 12,0A
Filter a.
Subsystem Add subsystem Add subsystem
MACHINE DESIGNATION: DC4025
MACHINESERIES: FILTER
TRACTIONDRIVE: MANUELL
PERFORMANCE: upto1400m³/h
FILTRATION AREA: 44 m²
HOSE CONNECTION: VARIABLE
DC4025 Bedienungsanleitung/Operating Manual
Technische Daten/Technical Data
3
1.3 Operative range and correct usage
This specific filter unit has been designed to vacuum
dry dust .The dust collector DC4025 is exclusively
designed to be used with IMPACTS machines. It is
only allowed to vacuum dry dust. The manufacturer
will not be liable for damage resulting from such
incorrect usage. In these cases the user is
responsible for all risks.
It is designed to vacuum dry dust specified to be
Class L. (E DIN IEC 61J/94 CD)
The Filter fabric FA 6176 is certified to DIN/EN DUST
CLASSIFICATION CLASS L and M.
Do not use this equipment on applications where
you expect dust that is classified to be harmful. If
you feel uncertain, ask local authorities for
assistance.
1.4 Stand-by power supply ( generator)
If the Dc4025 is operated using a generator, the
generator must be operated in accordance with
current VDE or further local directives( This applies
in special to the protective earth conductor) in order
to ensure that all safety devices are functioning and
to be able to eliminate possible damage to electrical
components.
Bedienungsanleitung/Operating Manual DC4025
Technische Daten/Technical Data
4
During the operation of the DC 4025 in combination with
other equipment it may be possible to exceed the acceptable
noice level of 85 dB(A). This is dependend on the different
locations and the local circumstances. When the noice level
is 85 dB(A) or more, the machine operator and the persons
working near the machine must wear sound –insulating
devices.
Do not use the DC4025 in corrosive or explosive environment.
Do not vacuum flammable liquids or other flammable media.
Do not vacuum glowing particles
Do not open the dustbin while turbines switched on.
Do not use the DC4025 without a filter cartridge fitted.
1.5 Advices for operators
The dustbin of the filter unit needs regular dumping.
Do not overfill the bin to avoid dust exposure when opening
the bin
Comply with the local waste treatment regulations
considering the removed material.
DC4025 Operating Manual
Safety Advices
1
Chapter 2
2.0 Explanation of warnings and symbols PAGE: 2
2.1 Organisationel measures PAGE: 4-5
2.2 Personnel selection and qualification PAGE: 5
2.3 Safety precautions applicable to
different operating conditions PAGE: 6
2.4 Repair work , maintenance activities,
and default repair on the job side PAGE: 7-8
2.5 Definition of the Safety off position PAGE: 9
2.6 Dangerous aspects of the filter PAGE: 9
2.7 Electrical engineering regulations PAGE: 10
2.8 For special attention PAGE: 11
Operating Manual DC4025
Safety Instructions
2
2.0 Warnings and symbols
The following denominations and symbols are used in the Operating
Instructions to highlight areas of particular importance:
Symbol of operational safety.
This symbol will be shown in these Operating
Instructions next to all safety precautions that are to
be taken in order to ensure prevention to life and
injury. Follow always these instructions and take
special care in these circumstances. In addition to
these instructions, the general safety precautions and
the local accident prevention guidelines are also to be
followed. Please check, whether there are special
regulations for the particular job side.
Information, instructions and restrictions with regards
to possible risks to persons or extensive material
damages.
Particular details regarding the economical use of the
equipment
DC4025 Operating Manual
Safety Advices
3
Warning against dangerous voltages.
Indications relating to protective devices of electrical
equipment.
Indications where consultation with the
manufacturer is necessary
Instructions relating to periodical checks
Reference to important instructions contained in the
Operating Instructions
Operating Manual DC4025
Safety Instructions
4
The Oprerating Instructions are to be kept near the location
where the filter is located and must be reachable all the time!
In addition to the Operating Instructions general and legal
regulations regarding accident prevention and environmental
protection must be with and indicated every time.!
Such duties may for example relate to the handling of hazardous
substances or to the provision and wearing of personal protection
equipment as well as compliance with local traffic regulations..
The Operating Instructions must be supplemented by instructions
including the duty to supervise and report relating to particular local
working pratices, for example work organisation, work procedures
and personnel allocation.
Personnel entrusted with working with the filter must have read the
Operating Instructions before starting the work, in particular the
chapter about Safety Instructions.These has to be done before
starting any work with the filter.This particularly applies to incidental
activities such as setting up the filter, carrying out maintenance
work or training staff to work with the filter.
From time to time the working practices of the staff are to be
checked regarding awareness of safety and hazards.
Personnel must tie back long hair and not wear loose clothing or
jewellery rings. There is a risk of injury through getting stuck or
being drawn into moving machinery.
Use personal protection equipment if necessary or required
by regulations! Take notice of allsafety and hazard notices on
the filter.
All safety and hazard notices on the filter must be keept complete
and readable
2.1 Organisational measures
