USER MANUAL
Dual-Screen
Portable DVD Player
Model N° – DVPDS720-2
ENGLISHESPAÑOLFRANÇAIS
ii
TABLE OF CONTENTS
Important Safety Instructions 1
Package Contents 3
Main Unit Controls 4
Secondary Display Controls 5
Operating Instructions 6
Using the Remote Control 9
System Setup 11
Secondary Display System Setup 17
Technical Specications 18
Troubleshooting 19
Contact Technical Support 19
ENGLISHESPAÑOLFRANÇAIS
ENGLISHESPAÑOLFRANÇAIS
1
IMPORTANT SAFETY INSTRUCTIONS
For your safety, please read these instructions carefully.
1. WARNING: To reduce the risk of
electric shock, do not remove
the cover or back of the units.
There are no user-serviceable
parts inside. Contact technical
support for further assistance.
2. WARNING: To prevent re or
electric shock hazard, do not
expose the unit to rain or mois-
ture.
3. Do not expose the adapter and
portable DVD to any water (in-
cluding drips or splashes). Ob-
jects lled with liquids, such as
vases and water bottles, should
not be placed on the unit.
4. Keep the portable DVD away
from direct sunlight and heat
sources such as radiators or
stoves.
5. Do not block the ventilation
openings. Slots and openings
on the unit are provided for
ventilation. Placing your porta-
ble DVD on a cushion, sofa or
other similar surface, should
never block the openings.
6. Do not place the portable
DVD on an unstable table,
stand, tripod, bracket or cart.
The unit may fall, resulting in
possible damage or injury.
7. Never place heavy or sharp ob-
jects or pressure on the LCD
panel or frame.
8. Only use the AC adapter includ-
ed with the portable DVD play-
er. Using any other adapter will
void your warranty.
9. Unplug the power from the out-
let when the unit is not in use.
10. Dispose of this unit properly
respecting your local laws for
electronics and battery dispos-
al.
11. CAUTION: Danger of explosion
if battery is incorrectly replaced.
Replace only with the same or
equivalent type of battery.
12. WARNING: The battery (battery
or batteries or battery pack)
shall not be exposed to exces-
sive heat such as sunlight, re
or any other heat source.
13. WARNING: Excessive volume
and/or usage of earphones or
headphones can cause hearing
loss.
14. WARNING: Only use attach-
ments/accessories specied
provided by the manufacturer,
using the included AC adapter
and DC car adapter.
European Union Electronic Waste Disposal Guidelines:
This symbol means that used electrical and electronic products should not
be mixed with general household waste. For proper treatment, recovery and
recycling, please take this product(s) to designated collection points where it
will be accepted free of charge. Alternatively, in some countries you may be
able to return your products to your local retailer upon purchase of an equiv-
alent new product. Disposing of this product correctly will help save valuable
resources and prevent any potential negative eects on human health and
the environment, which could otherwise arise from inappropriate waste han-
dling. Please contact your local authority for further details of your nearest
designated collection point. Penalties may be applicable for incorrect dispos-
al of this waste, in accordance with you national legislation.
ENGLISHESPAÑOLFRANÇAIS
2
1. Warning: This DVD player uses
a laser system. Use of controls,
adjustments, or the perfor-
mance of procedures other
than those specied herein may
result in hazardous laser radia-
tion.
2. Warning: To prevent direct ex-
posure of laser beam, do not
open the unit. Laser radiation is
visible when the unit is opened.
3. Warning: Never stare directly
into the laser beam.
4. Caution: Do not install this prod-
uct in a conned space such as
a bookcase or similar unit.
5. Warning: When in use by chil-
dren, parents must ensure that
the child understands all safety
instructions, especially those
regarding overheating, electri-
cal hazards, and laser radiation.
6. Warning: If the unit overheats
or has a deformed, damaged,
or destroyed battery, stop us-
ing the unit IMMEDIATELY and
contact technical support for a
replacement.
7. Warning: Do not charge the
battery when the unit is not suf-
ciently ventilated. Such loca-
tions include: mattresses, sofas,
cushions, pillows, etc.
8. Warning: The manufacturer,
distributor, and retailers accept
no responsibility for battery
damage caused by improper
use and/or unit damage.
9. Warning: USB cables longer
than 10” (250mm) should not
be used with this unit.
Copyright Notice:
1. It is forbidden by law to copy, broadcast (via cable, wireless, or otherwise), show
in public performance, or rent copyrighted material without permission.
2. This product features the copy protection function developed by Macro-
vision. Copy protection signals are recorded on some discs. When record-
ing and playing the pictures of these discs picture noise will appear. This
product incorporates copyright protection technology that is protected by
method claims of certain U.S. Patents and other intellectual property rights
owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology must be authorized by Macrovision Corpo-
ration, and is intended for home and other limited viewing uses only unless
otherwise authorized by macrovision Corporation. Reverse engineering or
disassembly is prohibited.
charge
ove r
heat
40 C
strong
impact
ENGLISHESPAÑOLFRANÇAIS
ENGLISHESPAÑOLFRANÇAIS
3
PACKAGE CONTENTS
Your Impecca Dual-Screen Portable DVD Player includes the
following:
• 7” DVD Player
• 7” Secondary LCD Monitor
• Remote control with battery
• AC Power Adapter
• DC Car Power Adapter
• Audio/Video Cable
• Video/DC Secondary Monitor Cable
• User Manual
PRODUCT FEATURES
• 7” TFT LED Widescreen Display
with 480 x 234 Pixel Resolution
• Adjustable Aspect Ratio — 16:9 or 4:3
• Compatible with most Video, Photo, & Audio formats
• USB 2.0 Port & SD/MMC Card Playback
• Built-in Stereo Speakers 2.0 Channel
• Built-in Anti Shock protection.
• Congurable Display: Color, Contrast, & Brightness
• Worldwide Voltage: A/C 100–240v, 50/60Hz, D/C 9–12v
ENGLISHESPAÑOLFRANÇAIS
4
MAIN UNIT CONTROLS
1. SD Card Slot
2. Power On/O
3. Headphone out jack
4. AV output
5. Digital Audio output
(Coaxial)
6. USB port
7. DC OUT
8. DC IN 9-12V
9. Play/Pause
10. Up/Previous
11. Down/Next
12. Stop
13. Source
1
2
3
4
5
6
7
8
9
10
11
12
13
MAIN UNIT CONTROLS
ENGLISHESPAÑOLFRANÇAIS
ENGLISHESPAÑOLFRANÇAIS
5
SECONDARY DISPLAY CONTROLS
14. Mode
15. Up
16. Down
17. Lef t
18. Right
19. Power On/O
20. Headphone out jack
21. AV Input
22. DC IN
23. Volume dial
19
20
21
22
23
14
15
16
17
18
SECONDARY DISPLAY CONTROLS
ENGLISHESPAÑOLFRANÇAIS
6
OPERATING INSTRUCTIONS
Plug in your DVD Player:
Plug in the AC adapter into the DVD player (DC IN) and then
plug the adapter into the AC wall outlet.
If using the car charger, plug in the DC adapter into the DVD
player (DC IN) and plug the adapter into the cigarette lighter
outlet.
Only use the Impecca authorized power adapter included with
your DVD player. Using any other power adapter can damage
the unit and/or cause electrical shock, re, or even death.
ENGLISHESPAÑOLFRANÇAIS
ENGLISHESPAÑOLFRANÇAIS
7
Connecting the Secondary Display:
On the main unit, plug the Video/DC Secondary Monitor
Cable into the AV OUT and DC OUT ports.
On the secondary display, plug the Video/DC Secondary
Monitor Cable into the AV IN and DC IN ports. Remember to
turn on the Power On/O switch on the secondary display
unit if the screen remains black.
ENGLISHESPAÑOLFRANÇAIS
8
Connecting to a television or external speakers:
Connect the Audio Video Cable to the AV Out port. Connect
a standard RCA display cable (not included) to your speakers
or television set and select the correct input on your speak-
ers or television set.
Note that the secondary display cannot be connected to the
main unit at the same time as a television or external speaker.
Playing a DVD:
Slide the ‘Open’ tab on main unit. The screen will pop up, ex-
posing the disc player. Place the DVD or CD inside the player,
close the unit, and power the unit on. The DVD or media
menus will load.
