Steering Wheel Webcam
User Manual
Introduction
Congratulations on your purchase of the IMPECCA WC100 Steering Wheel
Webcam.
Due to constant production improvement, the webcam that you have
purchased might be slightly different than the one described in this manual.
Features
* Native Resolution: 640 x 480 @ 30fps, interpolated resolution up to 2.0
Megapixels
* High Resolution CMOS Color Sensor
* Built-in image compression
* Automatic brightness adjustment
* Automatic color compensation
* USB2.0
* Built-in Microphone
* Includes CD with extra effects
Hardware Requirement
Pentium 200 or higher CPU
32MB of memory or higher
OS Supported: Windows2000/XP/Vista/windows7
Camera Installation (without driver software)
1. Plug the camera into a USB slot on your computer. The screen will
display “Found New Hardware USB Video Device”
2. Double click “My Computer”
3. Double click USB Video Device
Windows2000, XP service pack 1 Installation
Camera Driver Software Installation
1. Insert the included CD into the CD-ROM drive, and double click to start
driver installation.
2. After the installation is complete, go to the “Start” menu, select “All
Programs”, and then select “Amcap” to start the video capture.
3. Start the video capture, and choose the “Video Capture Pin…” from the
“Options” to adjust the captured picture size.
Video Power Setup
1,Insert the CD into the CD-ROM Drive. Follow directions on the Video Power Setup
Wizard. When setup is complete, Plug in your camera, and click on the
desktop.
You can choose the “capture size” from 100K to 8.0 MP
Controls
(1) : Record video
(2) : Take a picture. The picture will be stored in the installation folder.
The default path is “C:/Documents and Settings/Administrator/My Documents/Images”.
(3) : Picture will be taken in five seconds.
(4) : Change image properties
(5) : Picture will be displayed as shown below
