IMPETUS IE 6800 Manuale utente
USER MANUAL
2
INTRODUCTION / IMPORTANT INFORMATION
PACKING LIST
ASSEMBLY INSTRUCTIONS
HOW TO MOVE THE TRAINER
TELEMETRIC HEART RATE CHEST STRAP
WARM UP / COOL DOWN
CLEANING & MAINTENANCE
RECYCLING INFORMATION
ADDITIONAL INFORMATION
3
5
6
13
14
15
16
16
16
A. Introduction
This user manual contains assembly, operation, maintenance and safety
information.
Please read and retain this manual for future reference.
B. Safety guidelines
a. Read the user manual and all accompanying literature. Follow it carefully
before using your machine.
b. This machine is intended for indoor home or commercial location use only.
c. Inspect your exercise machine prior to exercising to ensure that all parts are
tightened.
d. Make sure the trainer is stable on the floor. Avoid uneven surfaces.
e. Keep children under age of 14 and pets away from the exercise trainer at all
times.
f. Exercise equipment has moving parts. Keep others, especially children, at a
safe distance while exercise.
g. Make sure all devices are fully adjusted before use to avoid injury.
h. Remove all jewelry, including rings, chains and pins before exercising.
i. Always wear suitable clothing and footwear during exercise. Do not wear
loose fitting clothing that could become caught in the moving parts of your
exercise machine.
j. Warm up 5 to 10 minutes before each workout and cool down 5 to 10 minutes
afterward. This allows your heart rate to gradually increase and decrease and
will help prevent muscle strain.
k. Never hold your breath while exercising. You should breathe at a normal rate
in conjunction with the level of exercise being performed.
l. Rest adequately between workouts. Muscles tone and develop during these
rest periods.
INTRODUCTION / IMPORTANT INFORMATION INFORMATION
IE6800/impetus
3
IMPORTANT:
THE MAXIMUM RECOMMENDED WEIGHT CAPACITY FOR YOUR
EQUIPMENT IS KGS.
WARNING:
Before commencing with any exercise program, please consult your
family physician. If at any time during exercise you feel faint, dizzy or
experience pain, stop and consult your family physician.
The safety level of the equipment can be maintained only if it is examined
regularly for damaged and wear.
The appliances are not for children under age of 14.
IMPORTANT:
Read all instructions carefully. Assemble the unit in accordance with the
steps in the manual. Lay out all parts on the floor and check if you have all
the parts included completely before beginning assembly. In case of a
discrepancy, please contact the customer service department
150
IE6800/impetus
4
A1 B1 E1R E1L F1R
F1L G1 F3L F3R D14 F10
5MM 6MM
8MM
E4 1/2' WASHER 2PCS
A6 M10 SCREW 2PCS A7 M10 SCREW 4PCS
F6 M6 WASHER 8PCS
IE6800/impetus
15 / 13MM WRENCH SCREW SRIVER
PACKING LIST
E2 NUT 1/2”-20UNF*8T 4PCS
F7 M6 SCREW 8PCS
5
STEP 1:
Attach the MAIN FRAME (A1) to the GUIDE RAIL SET (B1) using two
SCREWS (A6) and four SCREWS (A7).
ASSEMBLY INSTRUCTIONS
A7
IE6800/impetus
6
A1
A6
B1
STEP 2:
Remove the ties from both PEDALS (D1L & D1R), and place them on top of
the GUIDE RAIL SET (B1).
IE6800/impetus
7
D1R
D1L
B1
IE6800/impetus
Step 3:
1. Attach the LEFT HANDLEBAR (E1L) to the MAIN FRAME (A1) using a
WASHER (E4), a NUT (E2) and a PLUG (D14).
2. Repeat the above steps for the other side
8
E1L
E2
D14
E4
E1L
A1
STEP 4：
1. Attach the PEDAL (F3) to the PEDAL FIXED ASSEMBLY (F1) using four
WASHERS (F6) and four SCREWS (F7).
2. Repeat the above step for the other side.
IE6800/impetus
9
F7
F6
F3
F1
STEP 5:
1. Attach the LEFT PEDAL FIXED ASSEMBLY (F1L) to the LEFT
HANDLEBAR (E1L) using a WASHER (D10), a NUT (E2) and a PLUG (F10).
2. Repeat the above steps for the other side.
IE6800/impetus
10
E1L
F1L
D10
E2
F10
