In The Ditch ITD1011 Manuale utente
ITD0144
Below is a list of parts you will need to install a set of Universal Mounts.
Mounting hardware is NOT included with product.
Minimum Required Mounting Hardware List For Complete Set:
Parts List:
Item # Qty Description Part #
1 (2) Wheel Grid Mount ITD1011/
ITD1161
*Right/Left Configurations
For missing or damaged parts, please call 1-888-993-4824
(12) 5/8” Bolts (Grade 8)
(12) 5/8” Washers
(12) 5/8” Nylok Nuts
MOUNTING INSTRUCTIONS
READ ALL SAFETY WARNINGS & INSTRUCTIONS CAREFULLY
BEFORE MOUNTING OR OPERATING YOUR MOUNT
Installation Guide for Wheel Grid Mount
ITD1011/1161
1
ITD0144
Ensure adequate clearance when mount-
ing. Mounting locations vary accord-
ing to truck model, layout, and acces-
sories.
Clamp Wheel grid in position.
Mark and drill (6) mounting holes for each
Wheel Grid.
Attach using recommended hardware.
Caution
Due to variances in tool box designs, and truck configuration, ITD cannot provide ex-
plicit mounting requirements for every truck. These are only guidelines, final installation
requirements are left to the discretion of the installer. ITD will NOT warrantee any
damage to tool boxes resulting from inadequate mounting.
Before First Use Checklist:
All nuts and bolts are tight
Warning
Inspect and retighten after first 10 uses
Frame Rail
Shown with Side
Puller
