Indramat TDA 1 Manuale tecnico
TDA 1
Main Spindle Controller
DOK-DIAX01-TDA********-PRJ1-EN-P
Project Planning Manual
mannesmann
Rexroth
engineering
Indramat
255533
2
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
3
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
Section
About this documentation
___________________________________________________________________
Contents
___________________________________________________________________________________________________
Presentation of the modular Main Spindle Controller TDA 1 1
___________________________________________________________________________________________________
Control cabinet design 2
___________________________________________________________________________________________________
AS programming module 3
___________________________________________________________________________________________________
Condition as-delivered 4
__________________________________________________________________
Equipment identification 5
___________________________________________________________________________________________________
Storage and transportation 6
__________________________________________________________________
Assembly 7
__________________________________________________________________
Installation guidelines 8
___________________________________________________________________________________________________
Comissioning guidelines 9
___________________________________________________________________________________________________
Servicing guidelines 10
__________________________________________________________________
Index 11
___________________________________________________________________________________________________
Supplementary documentation 12
___________________________________________________________________
4
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
5
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
About this documentation
TDA 1
Main spindle controller
Project Planning Manual
DOK-DIAX01-TDA********-PRJ1-EN-E1,44
• Mappe 7
• TDA1-PJ.pdf
• 209-0042-4112-01
This electronic document is based on the hardcopy document with document
desig.: DOK-DIAX01-TDA********-PRJ1-EN-P • 09.94
– to present the controller
– to mechanically integrate the controller into the control cabinet, and offer
guidelines on assembly and installation.
– to describe the AS programming module
– to illustrate the equipment delivered and their storage conditions
This documentation provides references to supplementary technical docu-
mentation
– for commissioning, operation and servicing
– for electrically integrating the controller, since all standardised electrical
connections for main spindle drives are contained in a separate document
– by means of the "Supplementary Overview", listing all technical documen-
tation for main spindle drives and their contents
– by means of the "Supplementary Documentation", listing all titles with their
order numbers
Titel
Type of documentation:
Documenttype
Internal file reference
Reference
This documentation
is used:
© INDRAMAT GmbH, 1994
Copyingofthisdocument,andgivingittoothersandtheuseorcommunication
ofthecontentsthereof,areforbiddenwithoutexpressauthority.Offendersare
liable to the payment of damages.
All rights are reserved in the event of the grant of a patent or the registration
of a utility model or design. (DIN 34-1)
The electronic documentation (E-doc) may be copied as often as needed if
such are to be used by the consumer for the purpose intended.
All rights reserved with respect to the content of this documentation and the
availability of the products.
INDRAMAT GmbH • Bgm.-Dr.-Nebel-Straße 2 • D-97816 Lohr
Telefon 0 93 52 / 40-0 • Tx 689421 • Fax 0 93 52 / 40-48 85
Dept ENA (MR, FS)
Copyright
Validity
Publisher
Designation of documentation Release- Coments
up to present edition date
DOK-DIAX01-TDA********-PRJ1-EN-P Sep/94 New Edition
DOK-DIAX01-TDA********-PRJ1-EN
-E1,44
Jul./97 First E-Dok
Change procedures
6
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
7
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
Table of Contents
Table of Contents Page
1. Presentation of the modular main spindle controller TDA 1 9
2. Control cabinet design 14
2.1. Operating conditions ............................................................ 14
2.2. Mechanical data ................................................................... 16
2.3. Thermal data ........................................................................ 19
2.4. Electrical data....................................................................... 22
2.5. Overview of technical data ................................................... 29
2.6. Type codes........................................................................... 30
3. Programming Module AS 31
3.1. AS programming module versions ................................... 32
3.2. AS programming module compatibility ........................... 32
3.3. Rating plate......................................................................... 33
3.4. Type codes.......................................................................... 34
4. Condition as delivered 35
5. Equipment identification 36
6. Storage and transportation 38
7. Assembly 39
8. Installation notes 41
9. Commissioning guidelines 42
10. Servicing notes 43
10.1. Fault diagnosis.................................................................... 43
10.2. Unit replacement ................................................................. 43
11. Index 45
12. Summary of supplementary documentation 48
8
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
9
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
1. Presentation of the modular main spindle controller TDA 1
Fig. 2: Modular main spindle controller TDA 1
1. Presentation of
the modular main
spindle controller
TDA 1
The main spindle controller TDA 1 is dedicated to the intelligent digital
control of INDRAMAT asynchronous main spindle motors 2AD and
frameless spindle motors 1MB with a continuous power rating of 3 to 10
kW at the motor shaft.
DrivesequippedwiththecontrollerTDA1aredistinguishedbytheirhigh
stiffnessandawidespeedrangeatconstantpower.Theyare,therefore,
particularly suited for use as a main spindle drive on numerically
controlled machine tool centres.
Besidesits wide speedrange, an a.c.main spindledrivewith TDA1has
an integral position control circuit capable of automatically positioning
thespindle (e.g.,for workpiecechange) witha maximumresolution of1/
4 000 000 revolutions in response to a signal. The internal controller
positionloopisclosedeitherbythemotorfeedbacksignal(fordirectdrive
or gear ratio 1:1) or by an additional, optional spindle feedback signal
(switchable gear, belt-driven gears).
Main Spindle Drive
Spindle positioning
10
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
The TDA 1 operates in conjunction with other controllers for feed axes.
Acombinationofpowersupplymodule,modularmainspindleandservo
drive controllers permits individual matching of the drive to the task of a
CNC machine tool.
Fig. 3: Drive package with modular main spindle controller TDA 1
Power supply
module TDA 1 Servo drive controllers
The a.c. main spindle drive with TDA 1 is also capable of operating the
spindle as a servo axis (C-axis) with a high-accuracy position control
loop. The main spindle motor is fitted with a high-resolution motor
feedbackdevicetocopewiththelowspeedsrequiredinthisapplication.
The controller detects the rotor position with a maximum resolution of 1/
2 000 000 revolutions, thus allowing even the lowest speeds to be
precisely controlled.
Since the spindle operates as an interpolating axis in C-axis mode and
the NC controls require information on the spindle position, the TDA 1
supplies compatible position signals for incremental encoders through
an optional output. The increments are derived either from the high-
resolution motor feedback device or from an additional, optional spindle
feedback device. The spindle feedback, in the latter case, is a high-
resolutionmainspindlepositionencoderfromINDRAMAT.Itismounted
directlyontothespindle.Thedefinitionoftheincrementalencoderoutput
isselectableandprovidesamaximumresolutionof360000increments/
revolution in C-axis mode.
1. Presentation of the modular main spindle controller TDA 1
C-axis mode
Controller for modular
drive package
Incremental encoder output
