Infa-secure CS7110 Manuale utente

CHILD SEAT TO BOOSTER SEAT

The photo displayed is indicative of the

type of restraint and may vary slightly

depending on the model.

IMPORTANT

Convertible Booster Seat

CS7110

CS7210

MODELS

(Forward Facing)

Suitable for children

from approximately

6 months to 4

years* of age

Suitable for children

approximately

4 to 8 years* of age

*All references to age are to an average proportioned

child. Children vary in shapes and sizes. The ages

outlined above is an approximation only.

1754:2010

Licence No. 25324

6 MONTHS

TO 8 YEARS*

SUITSSUITS

SIX MONTHS TO EIGHT YEARS*

mth. yrs.

TRAVELLING SAFELY WITH PEACE OF MIND

YEAR

yrs.

EAC

SIX

MON

mth

ELLI

The CS7110/CS7210 Convertible Car Seat is suitable for toddlers and older children as a convertible booster seat.

SUITABILITY OF THE CHILD RESTRAINT TO GROUPS OF CHILDREN

CONVERTIBLE BOOSTER SEAT (Type B and Type E)

Child Seat to Booster Seat

To be used in forward-facing position with built-in harness by children whose shoulders are above the lower shoulder height

marker (approximately 6 months of age) until their shoulders reach the middle shoulder height marker (approximately 4

years of age). Then to be used with a lap-sash seat belt until their shoulders reach the upper shoulder height marker

(approximately 6 to 8 years of age).

Continue to use this child restraint until the child reaches this limit.

Children are safest in a booster seat until their shoulders reach the upper shoulder height marker of the booster seat.

Do not use this child restraint until child’s shoulders are above the lower shoulder height marker.

Just using a seat belt is not recommended for children that have outgrown this seat. Use a larger booster seat.

INFASECURE PTY LTD

P.O. Box 487, Emu Plains

NSW 2750

Customer Service

Phone No: 02 4728 8090

DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR.

WARNING

PLEASE READ AND FOLLOW THESE INSTRUCTIONS EXACTLY

BEFORE INSTALLATION PLEASE READ CAREFULLY THE WHOLE OF THE

INSTRUCTIONS FOR INSTALLATION AND IF IN THE EVENT OF DOUBT ABOUT

THE METHOD OF INSTALLATION TO CONSULT INFASECURE OR A CHILD

RESTRAINT FITTING STATION AUTHORISED BY THE RELEVANT TRANSPORT

AUTHORITY. IN NEW ZEALAND, CONSULT THE AGENT FOR THE VEHICLE.

IMPORTANT

CS7110

CS7210

MODELS

Suitability of the child restraint

Contents

ANCHORAGE FITTINGS

- For cars tted with anchorage points

- For cars not tted with anchorage points

Restraint Guide

Padding - Combination Guide

- Information & Warnings

- CS7110/CS7210 Child Restraints (Itemised list)

- Shoulder Height Marker

SET UP

- Selection of Appropriate Padding Combination

- Adjusting Recline Angle

- Correct Shoulder Height

- Shoulder Slot Height

INSTALLATION

- Installing in Vehicle (using lap-sash seat belt)

- Installing in Vehicle (using lap seat belt)

USE

- Using Inbuilt Harness

- To Release Child

- Information & Warnings

- Shoulder Height Marker

- CS7110/CS7210 Child Restraints (Itemised list)

SET UP

- Selection of Appropriate Padding Combination

- Converting to Booster

INSTALLATION

- Installing in Vehicle

USE

- Using Lap-Sash Seat Belt

- To Release Child

CARE OF RESTRAINT

- To Remove Harness / To Replace Harness

- To Remove Cover / To Replace Cover

- Cleaning / Care and Maintenance

EXTENSION STRAPS

ACCESSORIES

Page 1

Page 2

Page 3

Page 4

Page 5

Page 6

Page 7

Page 8

Page 9-10

Page 11

Page 12-14

Page 14

Page 15

Page 16

Page 17-18

Page 19

Page 20

Page 21

Page 22-23

Page 24

Page 25

Page 26-28

Page 28

Page 28-30

Upper anchorage strap and attachment clip

must always be used

Upper Anchorage strap and attachment

clip must only be attached to the correct

anchor tting

Always ensure that the upper attachment clip

is correctly engaged to the anchor tting

This restraint is not suitable for use in a

hatchback or wagon where the anchorage

strap may fall into a split in the seat back

Straps may be damaged by unsecured cargo

in a collision. Secure or remove hazardous

cargo before using this restraint. Hatch-back

or wagon: Do not use the child restraint where

this strap may fall into a split in the seat back.

Always attach hook and remove slack.

FOR CARS FITTED WITH A CHILD RESTRAINT ANCHORAGE POINT

LOCATE THE ANCHORAGE POINT BEHIND THE REAR SEATING POSITION

CONSULT THE CAR OWNER’S HANDBOOK FOR LOCATION OF ANCHORAGE POINTS.

REMOVE THE THREAD PLUG FROM THE PARCEL SHELF/FLOOR/ROOF AND INSTALL THE ATTACHMENT

BOLT AS SHOWN IN FIGURE 1A & 1B.

UPPER ANCHORAGE FITTINGS

Attachment Bolt

THIS RESTRAINT MUST BE ATTACHED TO A CHILD RESTRAINT ANCHORAGE POINT IN THE CAR.

CAUTION: DO NOT OVERTIGHTEN ATTACHMENT

BOLT. MAXIMUM TORQUE IS 20NM.

WARNING

Some vehicles may have an anchor tting already

tted by the vehicle manufacturer.

If no anchorage points can be found refer to

the vehicle manufacturer, or an authorised child

restraint tting station for the best location of an

anchorage point.

Refer to the vehicle owners handbook or child

restraint tting station for the possible use of

spacers.

Some vehicles may require the use of additional

extension straps (not supplied with this child

restraint)

If so ring InfaSecure on (Aust) (02) 4728 8080 for

nearest supply location.

ADDITIONAL EXTENSION STRAPS AVAILABLE:

CS111 300mm Extension strap

CS112 600mm Extension strap

CS113 200 - 900mm Adjustable Extension strap

Attachment Bolt

FOR CARS NOT FITTED WITH A CHILD RESTRAINT ANCHORAGE POINT

SIDE VIEW

UPPER ANCHORAGE FITTINGS

FOR SEDANS ONLY

WARNING

BIRTH

MODE

2 4 6 8 10 12+

REARWARD-FACING

RESTRAINT (TYPE A1)

BIRTH TO APPROX

6 MONTHS

CONVERTIBLE

BOOSTER SEAT (TYPE B/E)

APPROX 6 MONTHS

TO 8 YEARS

FORWARD-FACING

RESTRAINT (TYPE B)

APPROX 6 MONTHS

TO 4 YEARS

BOOSTER SEAT (TYPE E)

FROM APPROX

4 YEARS 8 YEARS

CHILD SAFETY HARNESS (TYPE C)

FROM APPROX

4 TO 7 YEARS

FROM APPROX

7 TO 10 YEARS

SECUREFIT (ACCESSORY)

SAFETY RETAINING DEVICE

FROM APPROX

4 TO 7 YEARS

0 to 6 (months)

Approx 0 to 4 years

FORWARD FACINGFORWARD FACINGFORWARD FACING

BOOSTER SEATBOOSTER SEATBOOSTER SEAT

REARWARD FACING

FORWARD FACING

Approx

0 to 8 years

Approx 6 months to 4 years

Approx 4 to 7 years

(with Booster seat and lap-belt only)

CHILD HARNESS

SHOULD ONLY BE USED

IF A LAP ONLY SEAT

BELT IS AVAILABLE

ONLY USE WITH

INFA SECURE

BOOSTER SEATS

Approx 7 to 10 years

(without Booster seat

and lap-belt only)

Approx 4 to 7 years

(with InfaSecure Booster seat)

*Not applicable for 2004 Standard models

RESTRAINT GUIDE

SEAT BELT

FROM APPROX 7 YEARS

AND OVER

10 +7 +

Approx 6 months

to 8 years

Approx 4 years

to 8 years

Allowable by law More Appropriate

CONVERTIBLE

CAR SEAT

(TYPE A2/B)

BIRTH TO 4 YEARS

ZERO TO 8

CONVERTIBLE

CAR SEAT

(TYPE A1/B/E)

BIRTH TO 8 YEARS

IMPORTANT

Research has shown that the likelihood of an accessory child safety harness being used incorrectly is very high and the

risk of injuries when incorrectly used is much higher compared to a lap-sash seat belt. InfaSecure recommend that an

accessory child safety harness should only be used if a lap-only seat belt is all that is available.

REARWARD FACING

COMBINATION GUIDE

PADDING/INSERTS

FORWARD FACING

CHILD SEAT

(Small Child)

BOOSTER SEAT

MODEDELUXESTANDARD

(Shoulder pads & buckle pads)

FORWARD FACING

CHILD SEAT

(Large Child)

FORWARD FACING

*Diagrams are indicative of type of paddings and inserts and may not resemble the actual product.

*Padded inserts can vary according to model (If supplied).

We reserve the right to alter this product without notice.

*For detailed description and method of attachment for padded accessories refer to Accessories on page 31.

The Padded Insert/s (if tted) are

designed to provide extra

support and comfort for small

babies. Discontinue use when the

insert is a tight t or creates

discomfort for larger children.

INFORMATION & WARNINGS

Use the restraint exactly as shown in the instructions.

Supervision of children is needed because they may be able to undo buckles.

DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR.

Do not alter or modify this restraint.

Repairs must only be done by the manufacturer or agent.

Do not allow the restraint to come into contact with polishes, oils, bleach and other chemicals.

Destroy the restraint if it has been in a severe crash, even if no damage is visible.

Fit the restraint rmly to the car seat.

Fit the harness rmly to the child.

A loose restraint or harness is dangerous.

THIS RESTRAINT IS NOT SUITABLE FOR USE WHERE THE ANCHORAGE STRAP MAY FALL

INTO A SPLIT IN THE SEAT BACK. (EG HATCHBACK OR WAGON)

THIS RESTRAINT MUST BE ATTACHED TO A CHILD RESTRAINT ANCHORAGE POINT IN

THE CAR. REFER TO CAR OWNER’S HANDBOOK FOR LOCATION OF ANCHORAGE POINTS.

REFER TO A CHILD RESTRAINT FITTING STATION IF NO CAR ANCHORAGE POINTS ARE IN THE

MOTOR CAR.

Straps may be damaged by unsecured cargo in a collision. Secure or remove hazardous cargo

before using this restraint. Hatch-back or wagon: do not use the child restraint where this strap

may fall into a split in the seat back. Always attach hook and remove slack.

IF AN AIRBAG IS FITTED IN THE SEATING POSITION WHERE THE CHILD RESTRAINT IS TO BE

FITTED, FOLLOW THE VEHICLE MANUFACTURER’S WARNINGS AND INSTRUCTIONS.

When used in this mode the restraint must be used in conjunction with a lap or lap-sash seat belt.

To be used only in a forward-facing position with built-in harness by children whose shoulders are

above the lower shoulder height marker (approximately 6 months of age) until their shoulders

reach the middle shoulder height marker (approximately 4 years of age).

TO BE USED WITH A LAP-SASH/LAP-ONLY SEAT BELT THE FRONT/BACK OF MOST CARS WITH

FORWARD FACING SEATS.

Continue to use this child restraint until the child reaches this limit.

Do not use this restraint until child’s shoulders are above the lower shoulder height marker.

Children are at risk of serious injury if they move to a booster seat too early. Children that have

outgrown this restraint are safest in a booster seat until their shoulders reach the upper shoulder

height marker of the booster seat.

WARNING

CHILD

WITH INBUILT HARNESS

(Forward Facing - using inbuilt harness)

CHILD SEATCHILD SEAT

MODEL CS7110/CS7210

CHILD

WITH INBUILT HARNESS

For a vehicle without a xed parcel shelf an extension strap(s) may be needed.

If so ring (02) 4728 8080 for nearest supply location. (Refer page 13)

Seat belt extenders should not be used if the seat belt is not long enough to secure the child

restraint.

IMPORTANT

UPPER ANCHORAGE STRAP ASSEMBLY

UPPER ANCHORAGE STRAP ADJUSTER

ATTACHMENT CLIP

ANCHOR FITTING + ATTACHMENT HARDWARE

SAFE GRIP RED BELT CLAMP (supplied in pocket)

VEHICLE SEAT BELT

“FORWARD-FACING SEAT BELT PATH” MARKER

(EACH SIDE OF RESTRAINT - COLOURED YELLOW)

COMFORT COVER

A - SEAT BASE

B - BACKREST

SHOULDER HEIGHT MARKER

HARNESS SHOULDER STRAPS

BUCKLE ASSEMBLY

HARNESS ADJUSTER

HARNESS ADJUSTMENT STRAP

10.

11.

12.

13.

14. SHOULDER PADS

15. BUCKLE PAD

16. PILLOW (if applicable)

17. PADDED INSERT (if applicable)

8 A

8 B

Smaller Toddler from

approximately 6 months of age

Do not use as a forward-facing child restraint until the child’s shoulders are above the lower

shoulder height marker (lower label).

If moving a child from rearward-facing child restraint, to forward facing child restraint the child’s

shoulders will need to be in-line or above the lower label. If the child’s shoulders are below the

lower label or if the baby’s neck muscles are unable to support their head, then the child should

remain rearward-facing.

SMALLER TODDLER

LOWER LABEL (Forward Facing)

When using the inbuilt harness the child’s shoulders must be in-line or above this marker

IMPORTANT

(Using Inbuilt Harness)

SHOULDER HEIGHT MARKER

Front

of Car

CHILD

SEAT

ABOVE THIS LINE

SHOULDERS MUST BE

FORWARD

FACING

SHOULDER HEIGHT MARKER

CHILD

WITH INBUILT HARNESS



LOWER

LABEL

Shoulder height markers are provided on this restraint for a visual indication that the child is safe to travel in this restraint.

Shoulder height markers may be hidden under a pillow in the lowest position.

LOWER

LABEL



Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali infa-secure Seggiolino auto

infa-secure

infa-secure CS4010 Manuale utente

infa-secure

infa-secure CS4210 Manuale utente

infa-secure

infa-secure CS7313 Manuale utente

infa-secure

infa-secure CS5310 Manuale utente

infa-secure

infa-secure CS5410 Manuale utente

infa-secure

infa-secure CS40 Manuale utente

infa-secure

infa-secure CS4513 Manuale utente

infa-secure

infa-secure II Series Manuale utente

infa-secure

infa-secure CS5610 Manuale utente

infa-secure

infa-secure Turn-A-Tot Manuale utente

infa-secure

infa-secure CS8113 Manuale utente

infa-secure

infa-secure CS8113 Manuale per l'uso e la cura

infa-secure

infa-secure CS9013 Manuale utente

infa-secure

infa-secure CS57 Manuale utente

infa-secure

infa-secure CS55 Manuale utente

infa-secure

infa-secure CS4313 Manuale per l'uso e la cura

infa-secure

infa-secure CS2013 Manuale utente

infa-secure

infa-secure CS6010 Manuale utente

Manuali Seggiolino auto popolari di altre marche

Britax

Britax PARKWAY SGL Manuale utente

JANE

JANE nurse cruiser Manuale utente

Digicom

Digicom Tippy Pad Manuale utente

Fisher-Price

Fisher-Price Futura 20/60 Manuale utente

Giordani

Giordani orion 012 Manuale utente

BRIO

BRIO ZENTO Manuale utente

Combi

Combi Zeus Turn 8815 Series Manuale utente

Graco

Graco Car Booster Seat Manuale utente

Coccolle

Coccolle Atira Manuale utente

hifold

hifold HF01-GL Manuale utente

CYBEX

CYBEX SOLUTION X2-FIX Manuale utente

kiwy

kiwy SLF 123 Manuale utente

Safety 1st

Safety 1st Summit ISO 30 Manuale utente

Safety 1st

Safety 1st Grand 2-IN-1 Manuale utente

Graco

Graco NAUTILUS Manuale utente

Britax

Britax Multi-Tech BB0-702-00 Manuale utente

Grammer

Grammer MSG45/421 Istruzioni operative

Nuna

Nuna REBL PLUS Manuale utente

infa-secure CS7110 Manuale utente

Manuali Seggiolino auto popolari di altre marche
