Infinity EVOLUTION 3D/4D Manuale utente

EVOLUTION 3D/4D

User Manual

External Structure

Remote Control

Your Chair

Back co

Voice command pad

& microphone

ver

Arm panel

USB charge port

Speaker

Pillow

Air ionizer

ack cushion

Footrest

Seat cushion

Caster

Welcome to

Thank you and congratulations on purchasing an Infinity Massage Chair - you’ve made a

great choice.

With over a decade of experience designing, building and servicing massage chairs,

Infinity takes pride in every chair sold, including yours. We are here for you. The US-

based Customer Care team can be reached at (603) 910-5000 or visit us online at www.

infinitymassagechairs.com and find valuable self service resources under the SUPPORT tab,

including electronic copies of all documents and video tutorials.

Inside this manual, you will find everything you need to setup and safely enjoy your

chair. Please review the entire manual before assembling or using your chair. If you are

assembling the chair yourself, please see the Assembly Guide next and reference the

online assembly video.

For convenience, we’ve also created a Quick Start Guide. We suggest you keep it in the

remote pocket as a tool to get to know all the features of your new chair.

Get ready to sit back, relax and enjoy the Ultimate Massage Experience.

We know you can’t wait to sit in your new Infinity Massage chair! Take a picture of you enjoying the ultimate

massage experience and make sure to tag us on social media with the hashtag #lovemyinfinitychair

to ensure it is in our system. This will simplify the warranty process

should you ever need it.

Alternatively, scan the QR code to go directly to the URL above.

Before assembling your chair, watch an assembly video at:

www.infinitymassagechairs.com/assembly-tutorials

Alternatively, scan the QR code to go directly to the URL above.

THE ULTIMATE MASSAGE EXPERIENCE

@infinitymassagechairs@infinitymassagechairs @infinity_chairs@infinity_chairs @infinitymassagechairs@infinitymassagechairs

SCAN CODE

Warranty Registration

Assembly Video

Chair Features

Lumbar Heat

Zero Wall Space-

Saving Technology

Air Ionizer

Manual Massage

Customization

Total Sole

Reflexology Rollers

Body Scanning

Calf Rollers &

Oscillation

Apple/Android

Application

Memory Function

Bluetooth

Zero Gravity

Intelligent Voice

Control

USB Charging Port

See page 9

See page 13See page 13 & 19See page 13

See page 10See page 6 See page 10

See page 13

See page 15

See page 14

See page 19

See page 15

See page 14

See page 18

3D/4D Massage

Table of Contents

Before Getting Started

Chair Setup

Taking Control

Installation Site

Clearance Space for the Chair

Floor Protection

Move Methods

Connect to Power

Getting Comfortable

Main Power Switch

Adjust Pillow

Reduce the Intensity of Your

Massage - Manually

Body Scanning

Legrest Extend/Retract

Getting Out Of The Chair

Auto Programs

3D Massage

MyMassage Memory

Airbag Massage

Airbag Region

Airbag Intensity

Back Heat

Foot Rollers

USB Charging Port

Air Ionizer

Bluetooth Audio

Intelligent Voice Control

App Download & Installation

Timer

Language

Bluetooth

Voice

Remote Control Screen Idle

Specifications

Trouble Shooting

Frequently Asked Questions

Manual Programs

Back Massage Technique Mode

Massage Part (Back Region)

Back Node Width

Massage Speed

Foot Rollers

Zero Gravity

Staying Safe

Set Your Environment

Settings

Build Your Own

Fixing Issues

- 4” clearance for the recline of the backrest; 24” clearance for the extension of footrest and

sliding forward of the chair.

- Keep it 3 feet away from the TV, radio or other audio & video appliance to avoid signal

interference.

Clearance Space for the Chair

Installation Site

Before Getting Started

CAUTION

- Keep the distance between the power socket and power switch within 60” to avoid damage of power cord

while massage chair sliding forward.

- Straighten the power cord while in use to avoid tangle or damage.

- When the massage chair sliding forwards or back, please check to make sure there is no children, pets or

other obstacles around to avoid accident.

We recommend to place a piece of thin carpet or soft mat underneath it to avoid damaging

the floor.

Floor Protection

- Do not use the massage chair in high moisture environment such as near a swimming pool or bathroom to

prevent electric shock accident.

- Please keep the massage chair away from heated surfaces to prevent fire hazard or damage to the product.

WARNING

Massage chair

Floor

Carpet

4” 24”

Apply pressure to the back of the massage chair from behind to pivot on the Castors.

Have a second person up front to guide the Footrest until in the correct position. Maintain

clearances as mentioned above. Gently lower into place. Do not pull on the side arms.

Move Methods

Connect to Power

CAUTION

- Do not move the chair when there is user inside.

- To carry this product, do not lift by the footrest or armrest, hold the chassis and steady the backrest (have 4

or more people to carry the product).

Plug into a 110V grounded outlet.

4”

DANGER – Improper connection of the equipment-

grounding conductor can result in a risk of electric shock. Check

with a qualified electrician or serviceman if you are in doubt as to

whether the product is properly grounded. Do not modify the plug

provided with the product – if it will not fit the outlet, have a proper

outlet installed by a qualified electrician.

This product is for use on a nominal 120-V circuit and has a

grounding plug that looks like the plug illustrated. Make sure that

the product is connected to an outlet having the same configuration

as the plug. No adapter should be used with this product.

Earthing

This massage chair belongs to Level One electrical appliance, make

sure to use three-core power supply socket and to guarantee the

ground wire connected to the power supply socket has obtained

good ground connection to avoid electric leakage, electric shock

and some other negative effect during use.

Grounding Instructions

This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for

electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding

conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and

grounded in accordance with all local codes and ordinances.

- Ensure there is no damage to the

supply cord before switching on the

massage chair.

- Ensure that the main power switch is

turned off before connecting to power

CAUTION

Grounded

outlet

Grounding pin

To power up the chair, flip the main power switch located on the back of the base of the

chair to ON.

Main Power Switch

Getting Comfortable

Chair Setup

To make the massage less intense, you can add the back pad to the seat back of your

chair, or you can also fold down the neck rest to provide more cushioning between you

and the massage mechanism in the seat back. To make the foot rollers less intense, insert

the foot pads that came with your chair into the foot bed of the footrest.

Reduce the Intensity of your Massage - Manually

CAUTION

- Children should be supervised to ensure that they do not play with the chair or touch the power box.

- Always unplug the massage chair from the electrical outlet immediately after use.

- Unplug from outlet during thunder or lightening storms, and before putting on or taking off parts.

- Turn off the power switch and unplug the massage chair from the electrical outlet while not in use to avoid

children powering on the massage chair accidentally.

- When not in use for a long period of time, we recommend that the chair be covered, the power cord be coiled

and that the unit be placed in an environment free of dust and moisture.

Take a seat in the chair and take note of where the neck

pillow rests on your neck. Adjust the pillow so that it rests

comfortably in the arch of your neck. Do this by removing it

from the velcro, aligning it, and then reattaching to the velcro

once it is in the desired position.

Adjust Pillow

Main power switch

Tube fuse

Power cord input

Neck Pillow

Select any auto program and press the OK button. The chair will automatically begin

scanning your body, mapping your back, shoulders, and neck. During this process its is

importing to remain seated back into the chair without lifting your head.

The scan can be viewed on the remote control screen. If fine tuning is needed just after your

body scan, wait for the shoulder adjust prompt to appear and then use the Back Adjustment

buttons to move the massage rollers up or down for the perfect shoulder kneading position.

Body Scanning

To easily exit the chair at any time, press the ON/OFF power button

on the remote control to restore the chair to the upright position.

Getting out of the Chair

Smart tip: To increase intensity in the neck

and shoulder region, flip the pillow or the

pillow and pillow pad up so you lay directly

on the seat back pad.

Home key to select function

Sports Refresh

body sensing...

Shoulder adjust

10min

left image will be of

the body scanning

screen

Sports Refresh

body sensing...

Home key to select function

10min

Your chair will automatically set the leg length,

however, if you need to adjust, the legrest can

be extended or retracted manually. To adjust

the legrest, press the feet extend or feet retract

button.

Legrest Extend/Retract

Body Scanning Shoulder Adjust

Prompt

Extend

Retract

MyMassage 1

Auto Programs

MyMassage Memory

3D Massage

Taking Control

When massage chair is operating, press the

AUTO button on the remote control to enter

Auto Program Menu. Choose from Sports

Refresh, Extension, Rest & Sleep, Working

Relief, Neck & Shoulder, Waist & Spine,

MyMassage 1, or MyMassage 2. Press OK

to enter the program you desire. Selected

program will show on the home screen.

Your chair has the ability to save your favorite

customized massage programs to memory. To

do this, create a manual massage program

(see page 18 for instructions) with all of your

desired air, heat, speed, and intensity settings.

Storing a memory program:

After creating your custom massage in manual

mode, select AUTO from the Home display and

scroll to the bottom of the page. Here you will

see MyMassage 1 and MyMassage 2. Press OK

button to select either 1 or 2 then select “Save”.

If you save over the top of an existing memory

program, the existing program will be erased

and replaced by the most recent save.

As well as the programs in the AUTO section,

there are 3 additional 3D Massage programs. To

access, select 3D MASSAGE from Home display,

navigate to MODE and then choose from Deep

shiatsu, Healthy Breath, or Massage Extend.

Press OK to enter the program you desire.

Selected program will show on the home screen.

To adjust the intensity or region of your 3D

Massage, press up or down button to navigate

among: FORCE and PART.

Loading a memory program

Select AUTO from Home display and

scroll to the bottom of the page. Select

MyMassage 1 or MyMassage 2 and then

select “Run”. The chair will now run the

program you created.

Indice

Altri manuali Infinity Massaggiatore

Infinity

Infinity Prelude MTS Center Manuale utente

Infinity

Infinity PR Pro Manuale utente

Infinity

Infinity RT8800 Manuale utente

Infinity

Infinity IT-7800 Manuale utente

Infinity

Infinity PALISADE 4D Manuale utente

Infinity

Infinity RockerTech Bliss Manuale utente

Infinity

Infinity 8500 series Manuale utente

Infinity

Infinity RockerTech Sensation 4D Manuale utente

Infinity

Infinity Riage CS Manuale utente

Infinity

Infinity CORDLESS SHIATSU SPORT NECK & BACK MASSAGER Manuale utente

Infinity

Infinity IYASHI Manuale utente

Infinity

Infinity MOSAIC Manuale utente

Infinity

Infinity CORDLESS SHIATSU NECK & BODY MASSAGER Manuale utente

Infinity

Infinity ALTERA Manuale utente

Infinity

Infinity IT- 8000 Series Manuale utente

Infinity

Infinity Presidential Manuale utente

Infinity

Infinity Escape Manuale utente

Infinity

Infinity Riage-X3 Manuale utente

Infinity

Infinity Presidential Manuale utente

Infinity

Infinity Solstice 4D Manuale utente

Infinity

Infinity Deluxe Genesis SE Manuale utente

Infinity

Infinity RT1880 Manuale utente

Infinity

Infinity Syner-D Circadian Manuale utente

Infinity

Infinity IT-8500 X3 Manuale utente

Manuali Massaggiatore popolari di altre marche

ELEEELS

ELEEELS P2 Manuale utente

Cenocco

Cenocco CC-9111 Manuale utente

Panasonic

Panasonic EP790-C1 Manuale utente

Human Touch

Human Touch NOVO Manuale utente

Adler

Adler AD 2167 Manuale utente

Taurus

Taurus Wellness TW-MC-M Manuale utente

Hydas

Hydas LH-095 Manuale utente

AEG

AEG FM 5567 Manuale utente

OBH Nordica

OBH Nordica Shiatus Tunes Manuale utente

Hutech

Hutech Q9 Manuale utente

Medisana

Medisana MM 825 Manuale utente

SOLAC

SOLAC Therma Hydro Manuale utente

Invacare

Invacare Texas Manuale utente

Casada

Casada Bismarck II Manuale utente

Fujiiryoki

Fujiiryoki Cyber-Relax EC-1700 Manuale utente

Medisana

Medisana HM 886 Manuale utente

HoMedics

HoMedics BA-C200 Manuale utente

Repose

Repose Lynton Manuale utente
