Ingersoll-Rand ST400 Series Guida all'installazione

47616906001

Edition 2

July 2018

Save These Instructions

Air Starters for Internal Combustion Engines

ST400 Series

Maintenance Information

2 47616906001_ed2

Product Safety Information

WARNING

•Failure to observe the following warnings, and to avoid these potentially hazardous situations, could result in death or serious injury.

•Read and understand this and all other supplied manuals before installing, operating, repairing, maintaining, changing accessories

on, or working near this product.

•Always wear eye protection when operating or performing maintenance on this starter. The grade of protection required should be

assessed for each use and may include impact-resistant glasses with side shields, goggles, or a full face shield over those glasses.

•Always turn o the air supply and disconnect the air supply hose before installing; removing or adjusting any accessory; or before

performing any maintenance on this starter.

General Instructions

• Reference Parts Information Manual for item number call outs.

• Do not disassemble the starter any further than necessary to replace or repair damaged parts.

• Always mark alignment between the starter housing (13) and mounting ange (5) with a permanent mark that cannot be erased or washed

away in order to retain proper orientation.

• Always use soft jaws when grasping a part in a vice. Do not tighten vice more than necessary.

• Always have a complete set of seals, gaskets, and O-Rings on hand before starting any overhaul. Never reuse old seals, gaskets, or O-Rings.

• These steps outline complete disassembly. Do not disassemble the starter any further than necessary to replace a worn or damaged part.

• Do not remove any press t part unless the removal of that part is necessary for replacement or repairs.

• Do not reuse any bearing disassembled from a press t.

• Ensure all parts are clean and free of debris or damage before assembly. Replace any damaged parts with genuine Ingersoll Rand replacements.

• Lubricate all O-Rings with O-Ring lubricant prior to assembly.

• Clean all grease and oils from housings prior to assembly.

• Never wash the Liner Assembly (9) in solvent.

Disassembly of Starter

1. Remove the Drive Pinion Screw (1) from the drive shaft and remove the Drive Pinion (2).

2. Remove the six Flange Cap Screws (3) from the Flange Cover (4).

3. Pull up on Flange (5) to simultaneously remove both the Flange Cover (4) and Flange (5).

4. Remove the Front Drive Shaft Bearing (15) from the Flange Cover (4).

5. Remove the Drive Housing Seal (16) from Flange Cover (4).

6. Place the starter in a xture with the pinion side down.

NOTICE

Use care when removing the Housing Cover Bolts (12) holding the Housing Cover (11) to the starter. The Liner (9) is spring loaded and

will protrude approximately one inch beyond the Housing (13) once released.

7. To remove the Housing Cover (11), slowly loosen the four Housing Cover Bolts (12) while holding the Housing Cover (11) in place. Make

sure the Housing Cover is not adhered to the Housing before the screws are completely removed. Remove the screws and slowly decrease

pressure from the Housing Cover allowing the spring to relax.

8. Slide the Liner Assembly (9) out of the Housing.

9. Remove the Return Spring (8).

Assembly of the Starter

1. Place the Return Spring (8) in the Housing (13).

2. Slide the Liner Assembly (9) into the Housing (13). The Liner Assembly and Housing is slotted, make sure the notch on the back of the Liner

Assembly is aligned to the notch on the back of the Housing. See Dwg. 47615017-7.

Align Notch

(Dwg. 47615017-7)

3. Attach the Housing Cover Gasket (10) to the Housing Cover (11). Align the Housing Cover to the Housing (13). Press down and torque Cover

Cap Screws (12) to 5-6 ft-lb (60-72 in-lb). Another method its install one cap screw a few threads, press on the liner with one hand and rotate

the cap in place.

4. Press the Drive Housing Seal (16) into the Flange Cover (4) with the sealing lip pointed down.

5. Press the Front Drive Bearing (15) into the Flange Cover (4). Press on outside race only.

6. Place the Flange Cover (4) in the Flange (5) so that the shoulder of the Flange Cover sits on the counter bore of the Flange.

7. Slide the ange assembly over the drive shaft. Careful not to damage the Drive Housing Seal (16).

8. Rotate Flange (5) to desired position. Install the six Flange Cap Screws (3) using a thread locking compound. Torque the Flange Cap Screws

to 9-11 ft-lb.

9. Attach the Drive Pinion (2) to the drive shaft using the Drive Pinion Cap Screw (1) with a thread locking compound on the threads of the

screw. Torque the Drive Pinion Cap Screw to 53-58 ft-lb.

47616906001_ed2 3

Test and Inspection Procedure

1. Clutch Ratcheting: Turn the drive (2) pinion by hand in the direction of starter rotation. The clutch should ratchet smoothly with a slight

clicking action.

2. Motor and Gearing Freeness: Turn the drive (2) pinion opposite the direction of Starter rotation. The pinon should turn by hand.

3. Motor Action and Pinion Engagement: Secure starter in a vise or xture that will safely allow to pinion to extend and rotate. Install a

regulator using ½”(13 mm) airline to the starter inlet. Slowly increase pressure to 30 psig, the pinion should extend 1-¼”(31.8 mm) and

rotate the direction marked on the nameplate.

Troubleshooting

Trouble Probable Cause Solution

Motor will not run and pinion does

not engage

No air supply Check for blockage or damage to air supply lines or tank.

Foreign material in starter and/or piping

Remove liner assembly and/or piping and remove blockage.

Defective control valve or relay valve Replace control valve or relay valve.

Low air signal pressure to start valve Check air supply.

Loss of Power Low air pressure to starter Check air supply.

Restricted air supply line Check for blockage or damage to air lines.

Relay valve malfunctioning Clean or replace lines or relay valve. Lube relay valve.

Foreign material in starter Remove liner assembly and remove blockage.

Damaged liner assembly components Replace liner assembly.

Motor runs and pinion engages,

but does not rotate ywheel

Damaged or broken liner assembly Replace liner assembly.

Excessive butt engagement Damaged drive pinion or ywheel Inspect drive pinion and ywheel and replace if

necessary.

Low air pressure Check air supply.

Wrong drive pinion Replace with proper drive pinion.

Oil leaking out of exhaust Oil in air supply line Inspect airline and remove source of oil including inline

lubricators.

Oil leaking from engine bell housing Replace drive seal.

Worn or damaged seals in liner

assembly

Replace liner assembly.

Air leakage Loose joints Make sure all joints are tight. Use Ingersoll Rand SMB-

441 Sealant on all NPT connections.

Worn or damaged inlet O-Ring Replace O-Ring using O-Ring lubricant.

Parts and Maintenance

NOTICE

The use of other than genuine Ingersoll Rand replacement parts may result in safety hazards, decreased motor performance, and

increased maintenance, and may invalidate all warranties. Ingersoll Rand is not responsible for customer modication of motors for

applications on which Ingersoll Rand was not consulted.

When product life has expired, it is recommended that the product be disassembled, degreased and parts be separated by material for proper

recycling.

Repair and maintenance should only be carried out by an authorized Service Center. Refer all communications to the nearest Ingersoll Rand

oce or distributor.
