SMART SPRINKLER
CONTROLLER
HO-SC-6W
USER MANUAL V1.0
01 Overview
02 Features & Specifications
03 Product Diagram
04 Operation Instructions
05 Installation
06 Troubleshooting Guide
07 Product Warranty
08 FCC Requirement
09 Irrigation Schedule Table
1
1
2
3
20
27
28
28
29
CONTENTS
INKBIRD HO-SC-6W is a smart sprinkler controller that can upgrade our
water pipes into a smart automation system, saving us plenty of time we
used to spend on watering. Also, it has Wi-Fi capability that enables us to
control and monitor irrigation from our smartphones. It can control up to
6 zones and automatically start and stop irrigating at specific times we
set. Featuring multiple user-friendly functions, HO-SC-6W is an ideal
assistant to help us create a wonderful garden.
• Product Name: Smart Sprinkler Controller
• Model: HO-SC-6W
• For indoors
• Control by phone APP via Wi-Fi connections
• Control up to 6 zones of watering
• Station-based programming enables separate irrigation adjustments for
different zones to suit the specific water needs of each zone.
• 4 cyclic options (custom days/intervals/odd days/even days) to
customize irrigation schedules, enhancing flexibility on controlling.
• 6 start times to run the same program multiple times in a day.
• Manual irrigation mode to immediately water an individual zone, several
zones, or all zones at a time.
• Built-in non-volatile memory to indefinitely save the settings even after
a long time of power off.
• 2 Years of Product Warranty
01 OVERVIEW
02 FEATURES & SPECIFICATIONS
1
Controller Size：6.1"*4.7"* 1.3"
Product Weight：224g
2
3
03 WHAT YOU WILL GET
4
5
04 TOOLS YOU WILL NEED
05 PRODUCT DIAGRAM
Zone1~6
Master Valve
Common
Indicators of Wi-Fi
Connection and
Irrigation Zone
Wi-Fi Button
Setting Button
Start/Stop Button
6
24VAC –
24VAC +
Sensor PWR IN（AC24V
Power Input Port）
06
07
7
8
