InMotion AIR Pro Manuale utente
E-SCOOTER
USER MANUAL
ORIGINAL INSTRUCTIONS
Contents
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Safety Instructions
Packing List
Product Function Diagram
Control Panel/Dashboard
Assembling Your KickScooter
First Ride
Charging
Learning to Ride
Security Tips
Folding and Carrying
Specifications
Maintenance
Before Your Ride
Safety Alerts & Error Messages
Trademarks and Legal Notices
Certifications
Contact
01
04
05
06
07
08
09
10
11
13
14
16
17
18
19
19
20
Electric scooter is a recreational device rather than a transporter. But once you ride it into a public community, it will also act as a transporter. Like
any riding products, an electric scooter can and is intended to move and it is therefore, of course, possible to get into dangerous situations.
Please understand that you can reduce the risks by following all the instructions and warnings in this manual, but you cannot eliminate all the risks.
Remember that whenever you ride the scooter you risk injury or death from loss of control, collisions, and falls. The electric scooter is intended for
use on flat pavement or level ground without bumps and obstacles. Be alert and slow down when entering unfamiliar areas.
Always wear a helmet when riding. Use an approved bicycle or scooter helmet that fits properly with the chin strap in place, and provides protection
for the back of your head. A long-sleeved shirt, long pants, and athletic shoes are recommended. Never ride in higheels sandals or barefooted. Long
hair or bangs that can affect vision should be tied up to avoid accidents caused by hair blocking vision.
Do not attempt your first ride in any area where you might encounter children, pedestrians, pets, vehicles, bicycles, or other obstacles and potential
hazards.
Respect the rights and property of others. Pass on the left whenever possible. When approaching a pedestrian from the front, stay to the right and
slow down. Be careful to avoid pedestrians, especially the old, children, the disabled, pregnant women. When approaching from behind, announce
yourself and slow down to walking speed when passing. Please obey local traffic laws and regulations if situation is different.
In places without laws comply with the safety guidelines outlined in this manual. INMOTION will not be responsible for any property damage, personal
injury/death, accidents, or legal disputes caused by violations of the safety instructions.
Do not allow anyone to ride your scooter on his/her own unless they have carefully read this manual and followed the riding guide video. The safety
of new riders is your responsibility. Assist new riders until they are comfortable with the basic operation of the scooter. Make sure each new rider
wears a helmet and other protective gear.
Before each ride check for loose fasteners and damaged components. If the scooter makes abnormal sounds or signals an alarm, immediately stop
riding. Diagnose your scooter via the INMOTION App and contact after-sales service at [email protected].
Be alert! Scan both far ahead and in front of your scooter - your eyes are your best tool for safely avoiding obstacles and low traction surfaces
(including, but not limited to, wet ground, loose sand, loose gravel, and ice).
1. Safety Instructions
01
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
To reduce risk of injury, you must read and follow all “CAUTION" and “WARNING" notices in this manual. Do not ride at an unsafe speed. Under no
circumstance should you ride on roads with motor vehicles. The manufacturer recommends riders aged between 14-60 years old and weigned less
than 120kg. People who should not ride the scooter include:
i. Anyone under the influence of alcohol or drugs.
ii. Anyone who suffers from disease that puts them at risk if they engage in strenuous physical activity.
iii. Persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruc-
tion concerning use of the appliance in a safe way and understand the hazards involved.
iv. Anyone who has problems with balance or with motor skills that would interfere with their ability to maintain balance.
v. Anyone who is severely overweighted (see Specifications).
vi. Pregnant women.
Vii. Riders under the age of 18 years old should ride under adult supervision.
Comply with local laws and regulations when riding this product. Do not ride where prohibited by local laws.
To ride safely, you must be able to clearly see what is in front of you and you must be clearly visible to others.
Do not ride your scooter in wet or icy weather, or on roads which are wet, muddy, icy, or that are slippery for any reason. Do not ride over obstacles
such as sand, loose gravel, or sticks. Wet, slick, bumpy, uneven or rough surfaces may impair traction and contribute to a loss of balance or traction
and could cause a fall.
Do not ride at night when visibility is limited.
Sudden acceleration ordeceleration could lead to wheel slip, collision or falls.
Do not ride faster than the speed limit.
Do not attempt to charge your scooter if it, the charger, or the power outlet is wet.
Only use the INMOTION supplied charger. Use only with FY-4202000 supply unit. Do not use a charger from any other different product models.
Use only INMOTION approved parts and accessories. Do not modify your scooter. Modifications to your scooter could interfere with the operation
02
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
of the scooter, could result in serious injury and/or damage, and could void the limited warranty.
Children should not use scooter or play with scooter parts. Cleaning and maintenance shall not be done by children without supervision. The vehicle
vibration will cause the driver's body vibration while riding.
Please park on flat pavement, such as on a slope, the scooter kickstand must be facing downhill to prevent capsizing. Please check whether the
scooter is parked stably to prevent it overturned.
Perform regular inspections of equipment and conduct regular cleaning on your scooter for better ride experience.This scooter contains batteries
that are not replaceable.
Use any battery charger other than the original.
detachable supply unit.
Any load attached to the handlebar will affect the stability of the vehicle.
Braking distances may be extended in wet weather.
LPA and LWA: Do not exceed 70dB(A).
In any case, anticipate your trajectory and your speed while respecting the code of the road, the code of the sidewalk and the most vulnerable.
03
21.
22.
23.
24.
26.
25.
27.
28.
29.
Please carefully check whether the items in the packing box are complete and intact. If there is any part missing or damaged, please contact your point
of purchase or email to manufacturer.
Please retain the box and packaging materials at least 15 days in case you need to ship your E-Scooter in the future.
1*Power cable 1*Power adapter
Quick Start Guide
1*Handlebars
1*M5 Wrench 1*M6 Wrench 1*Inner tube
2. Packing List
04
Assembled E-Scooter
User Materials
Accessories
User Manual
3. Product Function Diagram
05
Dashboard
Power button
Throttle
Bell
Brake lever
Headlight
Stem
Folding mechanism
Front fork
Front mudguard
Front wheel
Head unit clip
Handlebar
Charging port
Head unit mount
Taillight
Plate
Bracket
Rear wheel
Rear reflector
Footrest
Kickstand
Front reflector
Air valve
4. Control Panel/Dashboard
06
For drive mode For sports mode
Speedometer
Battery level
Speed unit
Error indicator
Pedestrian mode Cruise mode
Light icon Bluetooth icon
On power-on state, click once to turn on/off the headlight
Double click to switch the riding mode
Power button: Long press for more than 2s to power on/off
The max. speed is 25km/h, suitable for general riders
The max. speed is 35km/h, suitable for skilled riders
Shows the speed of the scooter in real time, the speed will be shown as two short lines when the vehicle is locked
The battery level is indicated by 5 bars, the last bar flashing indicates a low-battery level
The light icon will be on after turning on the light, and it will go out after switch the light off
Cruise mode is activated automatically when the same speed is maintained. Press the brake or the throttle to go
back to the manual mode
The icon indicates that the scooter has detected an error. Refer to the error code table to find solutions
Press and hold the button for 2 seconds to turn the electric scooter on/off. When the scooter is on, press the
button to turn the headlight on/off, and press twice to switch modes
The max. speed is 6km/h
For drive mode
For sports mode
Speedometer
Battery level
Light icon
Cruise mode
Error
Pedestrian mode
Power button
Steps to change the unit between the Imperial System and the Metric one: Hold the handlebar, short press the power
button for 3 times
Speed unit
Km/h
mph
To avoid personal injury, please follow the instructions shown in the diagram for assembly operation and inspection.
Children are not allowed to involve in assembly operations.
NOTE: Use the M6 wrench to re-tight the folding part's nuts in case it's loosen after long time use.
(No need to tight it during assembling since it has been firmly installed)
5. Assembling Your E-Scooter
07
R
L
5
6
2. Unfold the stem and fasten the folding wrench. Make sure
the unlocking key springs up normally after fastening. Be sure
to buckle up properly.
4. Install the handles on the stem and firmly tighten it
according to the correct position and direction marked on
the label.
M5 Wrench
M6 Wrench
4
3
1. Open the package, take out the inner tray and scooter.
3. Place the brake lever on the handlebar, tighten it firmly with
hex wrench to be sure it won't loosen.
