INSTALLATION MANUAL
Centauri Series
Cree COB LED Spotlight
Your reliable LED lighting partner.
R
innovation. efficiency. sustainability.
www.innogreen-usa.com
InnoGreen USA, LLC
200 Innovation Boulevard, Technology Center
Suite 241, State College, PA 16803 USA
Phone: +1 814 272 0087
Fax: +1 814 272 0376
Email: [email protected]
InnoGreen Middle East Trading Company, LLC
Suite 601, Arenco Tower, Dubai Media City
PO Box 500403, Dubai, United Arab Emirates
Phone: +971 4 433 1251
Fax: +971 4 434 1289
Email: [email protected]
InnoGreen Canada, Incorporated
7703 Boulevard Newman, Suite 203
Lasalle Quebec, H8N 1X7 Canada
Phone: +1 514 508 9588
Fax: +1 514 508 9545
Email: [email protected]
InnoGreen Europe Limited
1 Hanger Green, Park Royal W5 2EL
London, United Kingdom
Phone: +44 208 930 2801
Fax: +44 792 221 2222
Email: [email protected]
DESCRIPTION
InnoGreen LED spotlight’s heat sink is made of die-cast aluminum with sandblasted silver surface finish.
Efficient heat dissipation with cutting-edge design. Utilizes CREE COB chip for better durability.
Most common areas of application are hotels, meeting rooms, offices, hospitals, schools, factories,
commercial lighting, shopping malls, kitchens, showrooms, indoor lighting etc.
DESCRIPTION
DESCRIPTIONPARAMETERS
> 0.375A
Current (Max)
> 0.1A Other __________
Dimmable
Dimming
- 20 to 40 deg C
Application Environment
Protection against Electric Shock
IP20
IP Rating Lens Angle:
Non-dimmable
DESCRIPTIONDIMENSIONS
INSTALLATION DRAWING
MR16 Gu10
INSTALLATION AND MAINTENANCE
1. Check if all the parts and accessories are enclosed.
2. Be sure to disconnect any power before installation.
3. Make sure the product is rmly mounted to lamp base before turning on the power supply.
SAFETY PRECAUTIONS
● Product is for indoor use only.
● Don't install around a humid environment.
● Don't drop, scratch, or squeeze the bulb.
● Don't take apart the product or replace mechanical and electronic components.
● Maintain safe distance from paper, fabric or other inammables.
● Tighten the bulb base into socket to prevent falling out.
● Don't touch the bulb with ngers after lamp works for some time. Bulb temperature is quite warm.
● Do not stare at the strong light for along time as it may cause injury to eyes.
The product should not be used for:
● For xtures and circuits with dimming functions unless specied.
● For xtures with internal control circuits (not including those which are ofcially allowed).
● For conventional direction lamp or exit lights.
● For mercury vapor lamps, sodium lamps or HID lamps
● For airtight or mechanically sealed xtures.
> 0.9
Power Factor
Units: (mm)
20 deg Other __________
Gu10: 100 to 240V
Input Voltage
MR16: 12V/24V AC/DC Other __________
INDOOR
CREE 20o
Gu10 MR16
49.5
58.0
22.0
50
22
49.5
