INSTALLATION MANUAL
MXOS2000
Outdoor Sauna Series
ATTENTION INSTALLERS:
These instrucons must be
le with the customer
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding
your installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period
visit
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
www.insigniashowers.com Last Modied: 12/01/2022
02
Contents
Thank you for your purchase 3
Electrical & Tool requirements 4
Box contents 5
Creang the base 6
Installing the back le upright 7
Installing the back panel 8
Installing the back right upright 9
Installing the right side panel 10
Installing the backrest panels 11
Installing the front right upright 12
Installing the le side panel 13
Installing the front le upright 14
Electric box install 15
Floor placement 16
Installing the bench side 17
Installing the back upper bench support 18
Installing the right upper bench support 19
Installing the back lower bench support 20
Installing the right lower bench support 21
Installing under seat support frames 22
Installing benches 23
Installing top framework 24
Installing the xed glass panel 25
Installing the inner roof 26
Installing the big roof 27
Installing the door 28
Installing the heater guard 29
Installing the accessories 30
Control Panel Instrucons/Operon 31
Sauna Room Safety Guide 34
WEEE Compliance Statement 35
www.insigniashowers.com Last Modied: 12/01/2022
03
Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with
great care to ensure you get the best out of your build and have a Sauna that will last
for many years to come! Like everything, in order to obtain a rst class product that
will serve you well for many years, the eort and correctness put into the assembly
will reect in the quality of your nish.
www.insigniashowers.com Last Modied: 12/01/2022
04
• Scissors
• Knife
• Spirit Level
• Tape Measure
• Philips Screwdriver
• Electric Drill
• Safety Gloves
• Safety Glasses
Tools Required
Voltage Rang 220-240AC
Frequency Rang 50Hz
Power Rang 15.2 kW
Always consult a qualied Electrician before connecon as to suitability
Your electrical contractor will understand ALL legal requirements of connecon before
undertaking any work or installaon.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF WITHOUT CONSULTATION
All connecons MUST be carried out by an approved part P electrician and a minor works
cercate must be issued upon compleon. This product is NOT designed for DIY install and
improper installaon could be fatal.
Please use correct size and type to meet electrical codes. Leave 2 feet of slack wire at generator
locaon for nish hook-up. Connect the generator to a dedicated circuit breaker.
Electrics
www.insigniashowers.com Last Modied: 12/01/2022
05
What’s in the Boxes?
Contents Quanty
Back Panel
Le Panel
Side Panel
Fixed Glass
Door
Inner Roof (Halves)
Big Roof
Sauna Heater
Heater Stand
Heater Guard
1
1
1
1
1
2
1
1
1
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.
Contents Quanty
Light
Door Handle
Sauna Rocks
Backrests
Bench Top
Bench Vercal Supports
Under Bench Support
Screw Pack
1
1
1
2
4
4
4
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
www.insigniashowers.com Last Modied: 12/01/2022
06
Step 1 — Creang the base
Create a square using the 4 boom struts.
Note: The front strut has a groove cut out
for the front xed glass panel. Make sure
this strut is at the front of the square.
www.insigniashowers.com Last Modied: 12/01/2022
07
Step 2 — Installing rear le upright
There will be 3 screw connecons on two
faces of the upright. They should face towards
the back boom strut and le boom strut.
www.insigniashowers.com Last Modied: 12/01/2022
08
Step 3 — Installing the back panel
Li the back panel and slide the brackets over the
screw xings and lock into posion. Also ensure you
push the panel down onto the back boom strut and
ensure they lock together.
www.insigniashowers.com Last Modied: 12/01/2022
09
Step 4 — Installing the back right upright
Tilt the back panel up in order to get the back right upright to
slot into the brackets. Connect and push the right back
upright down and secure into posion.
There will be 3 screw connecons on two faces of the
upright. They should face towards the back boom strut and
right boom strut.
www.insigniashowers.com Last Modied: 12/01/2022
10
Step 5 — Installing the right side panel
Li the side panel and slide the brackets over the
screw xings and lock into posion. Also ensure you
push the panel down onto the right boom strut and
ensure they lock together.
