Installation Guide
MXSO1700 Sauna
Should you require additional assistance with the
installation of your product,
please call 01908 317512
or email
customerservices@insigniashowers.com.
www.insigniashowers.com Last Modied: 29/06/2022
INSTALLATION MANUAL
MXOS1700
Outdoor Sauna Series
ATTENTION INSTALLERS:
These instrucons must be
le with the customer
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period visit
hps://www.insigniashowers.com/replacement-parts.html
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
www.insigniashowers.com Last Modied: 29/06/2022
02
Contents
Thank you for your purchase 3
Electrical & Tool requirements 4
Box contents 5
Creang the base 6
Installing the back right upright 7
Installing the back panel 8
Installing the back le upright 9
Installing the right side panel 10
Installing the right front upright 11
Installing the le side panel 12
Installing the front le upright 13
Electric box install 14
Installing the top frame 15
Floor placement 16
Placing the bench front 17
Under seat support frame install 18
Bench seat install 19
Back rest install 20
Installing the xed glass panel 21
Installing the inner roof 22
Installing the big roof 23
Installing the heater and heater guard 24
Installing the door handle 25
Installing the door 26
Installing the accessories 27
Control Panel Instrucons/Operaon 28
Before First Use—IMPORTANT 31
Sauna Room Safety Guide 32
WEEE Compliance Statement 33
www.insigniashowers.com Last Modied: 29/06/2022
03
Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with
great care to ensure you get the best out of your build and have a Sauna that will last
for many years to come! Like everything, in order to obtain a rst class product that
will serve you well for many years, the eort and correctness put into the assembly
will reect in the quality of your nish.
Please note: Like all timber products, such as garden sheds and fencing, garden
saunas require full exterior wood weatherproofing treatment after installation to
ensure long life and prevention of water ingress.
www.insigniashowers.com Last Modied: 29/06/2022
04
•Scissors
•Knife
•Spirit Level
•Tape Measure
•Philips Screwdriver
•Electric Drill
•Safety Gloves
•Safety Glasses
Tools Required
Power Rating 4.5KW
Always consult a qualied Electrician before connecon as to suitability
Your electrical contractor will understand ALL legal requirements of connecon before
undertaking any work or installaon.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF WITHOUT CONSULTATION
The MXOS 1700 is 240 volt compliant. Due the nature of use and current UK legislaon,
connecon from the house to sauna must always be completed by a qualied electrical
contractor. In all circumstances our recommendaon is direct supply your house service board.
On compleon always request a copy of a Minor Works Cercate showing completed required
connecon and circuit tests. In many cases this will be a legal requirement.
Electrics
www.insigniashowers.com Last Modied: 29/06/2022
05
What’s in the Boxes?
Contents Quanty
Back Panel
Le Panel
Right Panel
Fixed Glass
Door
Inner Roof
Big Roof
Sauna Heater
Heater Guard
1
1
1
1
1
1
1
1
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.
Contents Quanty
Light
Door Handle
Sauna Rocks
Backrest
Bench Top
Bench Vercal Supports
Under Bench Support
Screw Pack
1
1
1
1
4
4
4
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
www.insigniashowers.com Last Modied: 29/06/2022
06
Step 1 — Creang the base
Create a square using the 4 boom struts.
Note: The front strut has a groove cut out
for the front xed glass panel. Make sure
this strut is at the front of the square.
www.insigniashowers.com Last Modied: 29/06/2022
07
Step 2 — Installing rear right upright
There will be 3 screw connecons on two faces of
the upright. They should face towards the back
boom strut and right boom strut.
www.insigniashowers.com Last Modied: 29/06/2022
08
Step 3 — Installing the back panel
Li the back panel and slide the brackets over the
screw xings and lock into posion. Also ensure you
push the panel down onto the back boom strut and
ensure they lock together.
www.insigniashowers.com Last Modied: 29/06/2022
09
Step 4 — Installing the back le upright
Tilt the back panel up in order to get the back le upright to slot
into the brackets. Connect and push the right back upright down
and secure into posion.
There will be 3 screw connecons on two faces of the upright. They
should face towards the back boom strut and le boom strut.
