Insignia NS-PCDSSDM Manuale utente

Before using your new product, please read

these instructions to prevent any damage.

QUICK SETUP GUIDE

Dual SSD Hard

Drive Mount

NS-PCDSSDM / NS-PCDSSDM-C

PACKAGE CONTENTS

• SSD/HDD mount

• Screws for SSD or HDD (8)

• Screws for mount (4)

• Quick Setup Guide

FEATURES

• Fits up to two 2.5" hard drives to be

installed in a 3.5" HDD bay to improve

the performance of your desktop

computer by optimizing your hard

drive storage

• Supports dual SSDs or HDDs with

7 mm or 9.5 mm height, or single SSDs

or HDDs with up to 15 mm height.

• Adjustable mounting holes to

accommodate both symmetrical and

asymmetrical mounting

• SATA cable clearance reduces strain on

the connectors for long-lasting

durability

• Cutout design provides even heat

dispersion for data protection

• Black aluminum materials match the

rest of your setup while providing

durability and protection

• All mounting screws included

COMPATIBILITY

• Suitable for dual SSDs or HDDs with

7 mm or 9.5 mm height, or single

SSDs or HDDs with up to 15 mm

height.

Note: If your desktop computer is

pre-built, it may have a xed SATA

connection that is not compatible with this

product. Check the documentation that

came with your computer.

2Put your second SSD/HDD on the

mount and secure the drive to the

mount with four screws.

3Secure the mount in your computer

using four screws.

V1 ENGLISH 21-1044

SPECIFICATIONS

Dimensions (H×W×D):

3.9 × 5.6 × .8 in.

(10.1 × 14.2 × 2.2 cm)

Compatible SSD or HDD:

• Two 2.5" HDD or SSD (7 mm height)

• Two 2.5" HDD or SSD (9.5 mm height)

• One 2.5" HDD or SSD (up to 15 mm

height)

INSTALLING THE SSD DRIVE IN

THE DRIVE BRACKET

Note: We recommend that you use an

anti-static bracelet to protect your SSD

drive.

1Put your rst SSD/HDD on the

mount and secure the drive to the

mount with four screws.

ONEYEAR LIMITED WARRANTY

Visit www.insigniaproducts.com for

details.

CONTACT INSIGNIA:

For customer service, call

1-877-467-4289 (U.S. and Canada)

www.insigniaproducts.com

INSIGNIA is a trademark of Best Buy and its aliated

companies.

Distributed by Best Buy Purchasing, LLC

7601 Penn Ave South, Richeld, MN 55423 U.S.A.

SSD drive
