Insta 780 Manuale utente
MODEL
78
0
OPERATION AND MAINTENANCE MANUAL
MNL90
78
0
Rev.
-
02.11.2020
Safety Summary
WARNING
In case of power cord damage, do not attempt to repair or rep ace the power cord.
Contact the manufacturer or the oca distributor.
WARNING
Hot surface. Avoid contact.
CAUTION
The machine is to be operated by one person on y.
CAUTION
To reduce the risk of e ectric shock and injury to persons, turn the machine off and
disconnect the machine from the power supp y before servicing and/or c eaning.
CAUTION
During norma operation, the base of the machine must be insta ed or p aced above
the wa socket on a eve , stab e surface.
NOTE
This machine uses a fuse to protect against fire and e ectric shock. For continued
protection against fire or e ectric shock, rep ace
CAUTION
Do not ean on the machine when the ower p aten is removed. Care must be taken to
prevent machine from tipping over. Keep upper p aten c ose to the center position.
NOTE
This machine is for commercia use on y.
CAUTION
To provide continued protection against risk of e ectric shock, connect to proper y
grounded out ets on y.
WARNING
For continued protection against fire or e ectric shock, rep ace on y with Type T and 2
Ampere fuse.
Internationa Symbo s
Power Off
Power On
Hot Surface
Risk of E ectrica Shock
Protective Earth Termina
Ground
Wet Conditions
Start Action
Caution – Warning
Congratu ations!
Your se ection of the Insta Graphic Systems heat sea machine is a sound business decision. Insta equipment is
the resu t of the highest qua ity engineering and time-tested design. Your new machine, combined with Insta’s
reputation for innovation in the heat-sea ing fie d, ensures that you wi be ab e to de iver the best-decorated
substrates possib e for years to come.
This manua provides the insta ation, operation, and maintenance procedures for your 780 series machine, as
we as easy to fo ow instructions for on-the-spot maintenance.
Your mode 780 machine wi have a ong, troub e-free ife. Read this manua . Keep it with your machine; it’s
your key to proper operation and asting service.
Genera Description
The 780 is an automatic dua p aten shutt e machine capab e of generating tremendous pressure that is even y
distributed across the area of the 16’’ x 20’’ p aten. The 780 machine a so features a quick-change mechanism in
the ower p aten a owing the ower p aten to be switched or rotated in a matter of seconds. The heating p aten
features a heating e ement that is dense y coi ed to de iver rapid heating and constant, ong- asting and uniform
temperatures.
P ease fi out the fo owing for future use:
MODEL NO:
SERIAL NO:
MANUFACTURE DATE:
PURCHASE DATE:
PURCHASE VENDOR:
Limited Machine Warranty
Insta Graphic Systems warrants this heat sea machine, when operated under norma conditions, to be free from
manufacturing defects in materia and workmanship for a period of one (1) year on parts and 90 days on abor
from the invoice date.
This warranty wi be effective on y when Insta authorizes the origina purchaser to return the product to the
factory in Cerritos, Ca ifornia, freight prepaid, and on y when the product upon examination has proven to be
defective.
This warranty does not app y to any machine that has been subjected to misuse, neg igence, or has been
damaged accidenta y or intentiona y.
Insta sha not be iab e for the injury, oss, or damage, direct y or indirect y, arising from the use or the inabi ity
to use the product.
No c aim of any kind sha be greater in amount than the sa e price of the product or part to which c aim is made.
Specifications
Machine Weight (Dry)
425 bs
Shipping Weight (Dry)
450
bs
Height
30 inches
Depth
40 inches
Width
42 inches
Dimensions of the p ate
400 x 500 mm
Power supp y
220/240 V Sing e phase + Ground 50/60 Hz
Power
3
3
00 W
Amperage
1
5
A
E ectronic temperature contro er
Accurate to
+/
-
1% of max temperature.
Adjustab e from
32 to 428 °F
(
0 to 220 °C
)
E ectronic
timer
Accurate to
+/
-
1%
Adjustab e from
0s to 59min 59sec
Air
Pressure
Pressure maxi.
116 psi (8 bar)
Pressure mini
58 psi (4 bar)
Pressure mini. for e ectronic pressure va ve
14.5 psi (1 bar)
Terms of use
Noise
Less than 70 dB (A)
Ambient
temperature of use
From
50°F to 95°F or
10°C to 35°C
Hygrometry
Less than 90%
Max pressing force
2080 bf
Non-contractua document: according to technica progress, we reserve the right to modify the characteristics of our products.
Features
This heat-press machine has been designed for intensive production by an operator working in front of the
machine.
Heating p ate
Emergency stop
Si icone foam
Removab e ower
p ates
Touchscreen
Hood + Re ay
+ Fuses
Power supp y
Pneumatic supp y
connection
Automatic
rotation cy inder
Foot Peda
1. SECURITY
It is recommended to read the "instructions for use" carefu y before starting any pressing operation.
The press must be used by an authorized person who has been informed of the risks that may be caused by
misuse of the equipment.
The adjustments (pneumatic, e ectrica and mechanica ) made by our technicians in the workshop as we as the
safety devices insta ed on the machine must not be modified under any circumstances. Otherwise, the company
INSTA graphics systems wi re ease a responsibi ities on possib e prob ems re ated to the said machine.
THIS DEVICE IS DESIGNED TO BE USED BY ONE USER
USE BY QUALIFIED PERSONNEL
Important points
Obtain persona protective equipment P.P.E. (g oves and g asses for examp e)
Do not touch the hot parts of the device during use.
Do not put hands between the trays once the device is turned on.
When hand ing, ensure that the operator does not risk anything in terms of burns, e ectrocution or other.
Perform a dai y inspection of the machine before starting production.
In the area around the machine, make sure there is no one before starting.
If the machine does not work proper y, switch off the power supp y immediate y and ook for the cause (see
chapter "Maintenance" in the manua ).
Safety features on the machine
Protections and safety devices must not be modified.
They must be reassemb ed in case of possib e remova for maintenance.
They must be kept in p ace and in good condition during norma operation.
The INSTA MS780 is equipped with safety systems that protect the operator from pinching.
The main security features are:
Emergency stop
Located on the front of the machine: if the operator activates it, it turns off the machine.
Security guard
Above the upper heating p ate are two tab switches.
This system prevents the risk of pinching and crushing the operator.
If the system detects an obstac e, the heating p ate rises, the rotation is deactivated immediate y and the press
goes into safety mode.
You must press the red zone on the "A arm" page, position the stem above one of the ower p ates and press the peda so
that the machine is functiona again.
Verification of the operation of the safety device
Try the emergency stop and the safety cover dai y.
After an emergency stop
In order to restart the nomina operation, check if there are any other prob ems on the machine.
Un ock the emergency stop by turning the red part: the machine wi reset automatica y.
Manual
It is provided during the de ivery of the machine, technica documentation on the components used. P ease read
it before hand ing the INSTA machine.
2. INSTALLATION OF THE MACHINE
USE BY QUALIFIED PERSONNEL
780 MODEL, 230 VOLT
Use a designated 16 Amp AC circuit.
On y industria extension cords with
proper wire size (2.5 mm
2
) sha be
used.
Do not handle the machine by the trays!
IMPORTANT
The app iance must be p ugged into a
proper receptac e of the proper size
and rating. Equa y important, the ine
vo tage must be ab e to accommodate
this app iance as we as other
appliances operating on this circuit.
a. Cut the straps from the crate and unscrew the screws ho ding the cover and the be . Remove the id and
the be from the box.
b. Remove the p astic bag protecting the machine.
c. Remove the ag screws that secure the machine to its pa et.
d. After removing the packaging, remove the security screw using the A en key 4 provided.
