Inter-m V2-1000 Manuale utente

V2 SERIES

Professional Power Amplifier

V2-1000 / 2000

Professional Power Amplifier

V2 Series amplifier is Inter-M power amplifier line up for professional audio market with stable

SMPS (Switch Mode Power Supply) applied for low power consumption and light weight, also provides

powerful and high quality sound based on high damping factor.

features

• Stable SMPS(Switch Mode Power Supply) applied for low power consumption and light weight

• Compact 2U size and light weight

• Includes protection circuit to prevent a damage of over heat, short and over voltage

• High Damping Factor and low T.H.D (0.05%)

• 2Ω-load stable per channel, 4Ω-load stable in bridged mono

• S / N - Better than 106dB

• Front panel indicators for output signal, clip, protect and power

• Voltage gain selectable

• 30Hz or 50Hz HPF to protect speaker from low-frequency & Clip Limiter

*Specifications and design subject to change without notice for improvements.

specification

V2-1000 V2-2000

STEREO

8Ω (1kHz, THD 1%) 170W 280W

4Ω (1kHz, THD 1%) 300W 500W

2Ω (1kHz, THD 1%) 550W 850W

BRIDGED

8Ω (1kHz, THD 1%) 650W 1000W

4Ω (1kHz, THD 1%) 1100W 1700W

DAMPING FACTOR ≥380 ≥400

POWER SOURCE AC 220V, 60Hz AC 220V, 60Hz

POWER CONSUMPTION

1/8 power @4Ω 3A 4A

S/N (@8Ω) 106dB 106dB

Weight 10.7kg 10.9kg

Dimensions 482 (W) x 88 (H) x 407 (D) mm 482 (W) x 88 (H) x 407 (D) mm

V2-3000 / 4000

Professional Power Amplifier

V2 Series amplifier has efficient circuit design and great view of front panel for the professional audio

market, also provides powerful and high quality sound based on 2U slim rack size.

features

*Specifications and design subject to change without notice for improvements.

• Stable SMPS(Switch Mode Power Supply) applied for low power consumption and light weight

• Compact 2U size and light weight

• For better efficiency, 2-step of H-class AMP accepted

• Includes protection circuit to prevent a damage of over heat, short and over voltage

• High Damping Factor and low T.H.D(0.05%)

• 2Ω-load stable per channel, 4Ω-load stable in bridged mono

• S / N - Better than 106dB

• Front panel indicators for output signal, clip, protect and power

• Voltage gain selectable

• 30Hz or 50Hz HPF to protect speaker from low-frequency & Clip Limiter

specification

V2-3000 V2-4000

STEREO

8Ω (1kHz, THD 1%) 500W 700W

4Ω (1kHz, THD 1%) 900W 1200W

2Ω (1kHz, THD 1%) 1500W 1900W

BRIDGED

8Ω (1kHz, THD 1%) 1800W 2400W

4Ω (1kHz, THD 1%) 3000W 3800W

DAMPING FACTOR ≥400 ≥400

POWER SOURCE AC 220V, 60Hz AC 220V, 60Hz

POWER CONSUMPTION

1/8 power @4Ω 6A 7A

S/N (@8Ω) 106dB 106dB

Weight 12kg 12.1kg

Dimensions 482 (W) x 88 (H) x 407 (D) mm 482 (W) x 88 (H) x 407 (D) mm

V2-5000

Professional Power Amplifier

V2 Series amplifier has efficient circuit design and great view of front panel for the professional audio

market with stable SMPS (Switch Mode Power Supply) applied for low power consumption and light

weight, also provides Clip limiter, HPF to protect speaker from low-frequency.

features

• Stable SMPS(Switch Mode Power Supply) applied for low power consumption and light weight

• For better efficiency, 2-step of H-class AMP accepted

• Compact 2U size and light weight

• Includes protection circuit to prevent a damage of over heat, short and over voltage

• High Damping Factor and low T.H.D

• 2Ω-load stable per channel, 4Ω-load stable in bridged mono

• S / N - Better than 106dB

• Has 30Hz or 50Hz HPF to protect speaker from low-frequency

• Front panel indicators for output signal, clip, protect and power

• Voltage gain available

specification

V2-5000

STEREO

8Ω (1kHz, THD 1%) 1000W

4Ω (1kHz, THD 1%) 1700W

2Ω (1kHz, THD 1%) 2500W

BRIDGED

8Ω (1kHz, THD 1%) 3400W

4Ω (1kHz, THD 1%) 5000W

Frequency Response ±0.5 dB (20 Hz~20 kHz)

Input Sensitivity 1.4V

Voltage Gain(@ 8Ω) 36dB

T.H.D(@ 1/3 Power) < 0.1% (20 Hz~20 kHz)

S/N (@8Ω) > 106dB

Weight 12.5kg

Dimensions 482 (W) x 88 (H) x 407 (D) mm

*Specifications and design subject to change without notice for improvements.

Inter-M Corporation (IMK)

653-5 Banghak-Dong, Dobong-Ku, Seoul, Korea

Overseas Sales Team

Tel : +82-2-2289-8141~7 / Fax : +82-2-2289-8149 / E-mail : [email protected]

♣Specifications and design subject to change without notice.

www.inter-m.com

2011. 03
