CK30 Handheld

Computer

User's Manual

Addendum

ii CK30 Handheld Computer User’s Manual Addendum

Intermec Technologies Corporation

Corporate Headquarters

6001 36th Ave. W.

Everett, WA 98203

U.S.A.

www.intermec.com

The information contained herein is proprietary and is provided solely for the purpose

of allowing customers to operate and service Intermec-manufactured equipment and is

not to be released, reproduced, or used for any other purpose without written

permission of Intermec.

Information and specifications contained in this document are subject to change

without prior notice and do not represent a commitment on the part of Intermec

Technologies Corporation.

The word Intermec, the Intermec logo, Norand, ArciTech, CrossBar, Data Collection

Browser, dcBrowser, Duratherm, EasyCoder, EasyLAN, Enterprise Wireless LAN,

EZBuilder, Fingerprint, i-gistics, INCA (under license), InterDriver, Intermec Printer

Network Manager, IRL, JANUS, LabelShop, Mobile Framework, MobileLAN,

Nor*Ware, Pen*Key, Precision Print, PrintSet, RoutePower, TE 2000, Trakker

Antares, UAP, Universal Access Point, and Virtual Wedge are either trademarks or

registered trademarks of Intermec Technologies Corporation.

Throughout this manual, trademarked names may be used. Rather than put a

trademark (™or ®) symbol in every occurrence of a trademarked name, we state that

we are using the names only in an editorial fashion, and to the benefit of the trademark

owner, with no intention of infringement.

CK30 Handheld Computer User’s Manual Addendum iii

Contents

What’s New in Service Pack 2.................................................................................... 5

What Does CCX Compliance Mean? ........................................................................ 5

What is EAN.UCC Composite Symbology? .............................................................. 5

Setting Funk Odyssey Security................................................................................... 5

Selecting Funk as Your Security Choice....................................................... 6

Selecting a Profile ........................................................................................ 6

Configuring WPA Security.......................................................................... 7

Configuring 802.1x Security........................................................................ 9

Configuring LEAP Security ....................................................................... 11

Configuring Static WEP Security .............................................................. 12

Loading a Certificate ................................................................................. 13

Disabling or Modifying Keypad Functions .............................................................. 16

Using the CK30 With a Low Battery Condition ...................................................... 17

Understanding Radio Power Management Settings.................................................. 18

Using Energy Saving Mode With Your 1551E or 1553 Scanner .............................. 18

iv CK30 Handheld Computer User’s Manual Addendum

CK30 Handheld Computer User’s Manual Addendum 5

What’s New in Service Pack 2

This addendum covers the new features available in service pack

2 for the CK30 Handheld Computer. Use this addendum in

combination with the CK30 Handheld Computer User’s

Manual (P/N 073528-003) for complete information for service

pack 2. These features have been added or modified:

• CCX v1.0 compliance

• EAN.UCC Composite symbology

• Funk Odyssey™ security

• Ability to disable or modify some keypad key functions

• Radio Power Management

• Energy Saving mode with the 1551E or 1553 scanner

What Does CCX Compliance Mean?

The CK30 is now CCX v1.0 compliant. The Cisco Compatible

Extensions (CCX) Program for WLAN devices provides tested

compatibility with licensed Cisco infrastructure innovations.

The Cisco Compatible Extensions Program enables you to take

advantage of the Cisco Aironet® wireless network.

What is EAN.UCC Composite Symbology?

The EAN.UCC Composite symbology combines a linear

component (EAN-128) with a 2D component (PDF417) to

encode data. EAN.UCC Composite bar code symbols are used

for encoding identification numbers and data supplementary to

the identification in accordance with EAN and UCC application

guidelines. You must have the IT4000 imager in your CK30 to

be able to use the EAN.UCC Composite symbology.

Setting Funk Odyssey Security

Funk Odyssey security provides everything that you get with

Microsoft security with the addition of CCX compliance. Funk

security enables you to use LEAP and TTLS authentication on

your CK30.

6CK30 Handheld Computer User’s Manual Addendum

The type of security you choose is not dependent on your

authentication server. For example, you can use Funk security

with a Microsoft server.

To use Funk security, you need to:

• Select Funk security as your security choice

• Select a profile

• Set profile settings

• Download a certificate (if necessary)

Selecting Funk as Your Security Choice

The default security choice is Microsoft. If you want to use Funk

security, you need to select it as your security choice.

To select Funk security as your security choice

1 Press Cand then B. The System Main Menu appears.

2 Select the Configuration Utility.

3 Select Communications > 802.11 Radio > Security Choice.

4 From the Security Choice dialog box, choose Funk Security.

An alert box appears asking if you want to warm boot now.

5 Press Enter. Your CK30 warm boots.

Selecting a Profile

You can define up to four profiles for your Funk Odyssey

security. Different profiles let your CK30 communicate in

different networks without having to change all of your security

settings. For example, you might want to set up one profile for

the manufacturing floor and one for the warehouse.

To select a profile

1 Press Cand then B. The System Main Menu appears.

2 Select the Configuration Utility.

3 Select Communications > 802.11 Radio > Select Profile.

4 Select Active Profile and choose the profile you want to

name.

CK30 Handheld Computer User’s Manual Addendum 7

5 (Optional) Select Change Profile Label to give the active

profile a meaningful name.

6 Repeat Steps 4 and 5 for as many profiles as you want to

define.

7 Select the profile you want to configure with security settings.

8 Press Esc to return to the 802.11 Radio menu.

9 Configure your security settings.

Configuring WPA Security

Wi-Fi Protected Access (WPA) is a strongly enhanced,

interoperable Wi-Fi security that addresses many of the

vulnerabilities of Wired Equivalent Privacy (WEP). Instead of

WEP, WPA uses Temporal Key Integrity Protocol (TKIP) for its

data encryption method.

Currently, WPA satisfies some of the requirements in the IEEE

802.11i draft standard. When the standard is finalized, WPA

will maintain forward compatibility. WPA runs in Enterprise

(802.1x) mode or PSK (Pre-Shared Key) mode:

• In Enterprise mode, WPA provides user authentication using

802.1x and the Extensible Authentication Protocol (EAP).

That is, an authentication server (such as a RADIUS server)

must authenticate each device before the device can

communicate with the wireless network.

• In PSK mode, WPA provides user authentication using a

shared key between the access point and the CK30. WPA-

PSK is a good solution for small offices or home offices that

do not want to use an authentication server.

To use WPA security, you need:

• An authentication server (Enterprise mode only)

Note: You can also use a MobileLAN access point with

software release 1.80 or later as an authentication server. For

help, see the MobileLAN access System Manual (P/N 067150)

or MobileLAN access WA2X System Manual (P/N 073915).

• An access point with an 802.11b/g radio that supports WPA

8CK30 Handheld Computer User’s Manual Addendum

• CK30 with the 802.11b/g radio and the 802.1x/WPA

security option

To enable WPA security on your CK30

1 Make sure you have selected Funk as your security choice.

2 Make sure you have configured the communications and

radio parameters on your CK30.

3 Press Cand then Bto open the System Main Menu.

4 Choose Configuration Utility > Communications > 802.11

Radio > Profile Settings.

5 For Association, choose WPA and press Enter.

6 For Encryption, choose TKIP and press Enter.

7 For Authentication, choose TTLS,PEAP, or TLS and press

Enter.

If you choose TTLS or PEAP:

a Select User name, type your user name, and then press

Enter.

b Select Password prompt, choose Enter password now,

and then press Enter.

Note: You can use Prompt for password to troubleshoot

your connection to the network if you have problems.

c Select User Password, type a user password, and then

press Enter.

d For Validate Server Certificate, choose Enabled and press

Enter.

Note: You must have the date on the CK30 set correctly

when you enable Validate Server Certificate..

If you choose TLS:

a Load a user and root certificate on your CK30. For help,

see “Loading a Certificate” on page 13 for help.

CK30 Handheld Computer User’s Manual Addendum 9

b For Validate Server Certificate, choose Enabled and press

Enter.

c You must enter a User Name and Subject Name. You can

also enter a Server Common Name if you want to increase

your level of security.

8 Exit the Configuration Utility.

To enable WPA-PSK security on your CK30

1 Make sure you have selected Funk as your security choice.

2 Make sure you have configured the communications and

radio parameters on your CK30.

3 Press Cand then Bto open the System Main Menu.

4 Choose Configuration Utility > Communications > 802.11

Radio > Profile Settings.

5 For Authentication, choose None and press Enter.

6 For Pre-Shared Key, enter the pre-shared key or the pass

phrase.

The pre-shared key must be a value of 32 Hex pairs. The pre-

shared key must be preceded by 0x. The value must match

the key value on the access point. The pass phrase must be

from 8 to 63 characters.

7 Exit the Configuration Utility.

Configuring 802.1x Security

802.1x security provides centralized user authentication using an

authentication server, authenticators (access points), and

supplicants. These components communicate using an EAP

authentication type, such as TLS (Transport Layer Security) or

PEAP (Protected Extensible Authentication Protocol). 802.1x

security provides data encryption using dynamic WEP key

management.

To use 802.1x security, you need:

• An authentication server

10 CK30 Handheld Computer User’s Manual Addendum

Note: You can also use a MobileLAN access point with

software release 1.80 or later as an authentication server. For

help, see the MobileLAN access System Manual (P/N 067150)

or MobileLAN access WA2X System Manual (P/N 073915).

• An access point with an 802.11b/g radio

• A CK30 with an 802.11b/g radio and the 802.1x/WPA

security option

To enable 802.1x security on your CK30

1 Make sure you have selected Funk as your security choice.

2 Make sure you have configured the communications and

radio parameters on your CK30.

3 Press Cand then Bto open the System Main Menu.

4 Choose Configuration Utility > Communications > 802.11

Radio > Profile Settings.

5 For Association, choose Open and then press Enter.

6 For Encryption, choose WEP and then press Enter.

7 For Authentication, choose TTLS, PEAP, or TLS and then

press Enter.

If you choose TTLS or PEAP:

a Select User name, type your user name, and then press

Enter.

b Select Password prompt, choose Enter password now,

and then press Enter.

Note: You can use Prompt for password to troubleshoot

your connection to the network if you have problems.

c Select User Password, type a user password, and then

press Enter.

d For Validate Server Certificate, choose Enabled and press

Enter.

Altri manuali per CK30

Indice

Altri manuali Intermec Palmare

Intermec

Intermec CN3 Series Manuale utente

Intermec

Intermec Data Collection PC Manuale utente

Intermec

Intermec CS40 Vehicle Power Adapter Manuale utente

Intermec

Intermec CK61 Manuale utente

Intermec

Intermec CK70 RFID Manuale utente

Intermec

Intermec CK3 Series Manuale utente

Intermec

Intermec CK3a Manuale utente

Intermec

Intermec 6640 Manuale per l'uso e la cura

Intermec

Intermec CN50 Manuale utente

Intermec

Intermec CK30 Manuale utente

Intermec

Intermec CK61 Manuale utente

Intermec

Intermec CN70 RFID Manuale utente

Intermec

Intermec CN4 Manuale utente

Intermec

Intermec CK32 Manuale utente

Intermec

Intermec Trakker Antares 2420 Manuale utente

Intermec

Intermec CN70e 1000CP02W Manuale utente

Intermec

Intermec 600 Series 600 Manuale utente

Intermec

Intermec Oracle-Ready CK31 Manuale utente

Intermec

Intermec CK1 Serial Dock Manuale utente

Intermec

Intermec Trakker Antares 243X Manuale utente

Intermec

Intermec PEN*KEY 6400 Manuale utente

Intermec

Intermec CK60 Ethernet Multidock Manuale utente

Intermec

Intermec 751G Manuale utente

Intermec

Intermec CN2G Manuale utente

Manuali Palmare popolari di altre marche

Honeywell

Honeywell Dolphin 9900 Manuale utente

Honeywell

Honeywell CN75 Manuale utente

MiTAC

MiTAC Mio 168 Manuale utente

Wasp

Wasp WDT92 Manuale utente

Texas Instruments

Texas Instruments TI-Nspire Manuale utente

AXEM Technology

AXEM Technology MBS Manuale utente

Armstrong

Armstrong Brain Wave Istruzioni per il montaggio

Unitech

Unitech TB128 Manuale utente

Symbol

Symbol MC9000-G Manuale di installazione e funzionamento

Unitech

Unitech HT1 1D Batch Manuale utente

Ingenico

Ingenico IWL220 GPRS Manuale utente

Symbol

Symbol c2000 Manuale utente

Symbol

Symbol MC18 Manuale di installazione e funzionamento

Acer

Acer n20 Manuale utente

Docomo

Docomo F-04H Manuale utente

Toshiba

Toshiba e350 Series Manuale utente

Palm

Palm Tungsten E2 Manuale

Alien

Alien ALR-H460 Manuale utente
