CS40 Options

What do you get included in the box when you order a CS40?

The CS40 also comes standard with the following:

Color Camera

EA11 Scan Engine

Aiming Pattern

1D/2D 1D Only

3.1MP Camera with LED Flash

QWERTY BatteryNumeric Universal Cell Phone Charger Kit

Part# CS40ANU1LP000Part# CS40AQU1LP000

1430mAh

1D/2D Scanner

OR + +

CS40 Vehicle Install

Portable Vehicle Install powered by the vehicle power adapter 12 or 24V.

Part Number Description

1 805-675-001 CS40 Non-Powered Vehicle Holder

2 852-072-001 Vehicle Power Adapter, CS40, RoHS

3 RAMMOUNT Suction Cup RAM Mount - (Not an Intermec Part, available from Intermec Distributors)

This charge cable plugs directly into

the bottom of the CS40.

12-24V

CS40 Charging and Communications

USB Communications and Charging

Provides ActiveSync connection and charge to the device.

To PC for ActiveSync

(must be connected for

the Y-cable to work)

Part Number Description

1 321-674-001 Power/Data Y-Cable, CS40, RoHS

Universal Cell Phone Charger Kit

is included with the CS40

CS40 Charging and Communications

Single Dock with USB Communications and Charging

Provides ActiveSync connection and charge to the device simultaneously.

To PC for ActiveSync

Part Number Description

1 871-036-001 USB Cradle, Model CS40, RoHS

2 321-674-001 Power/Data Y-Cable, CS40, RoHS

Rear View

Universal Cell Phone Charger Kit

is included with the CS40.

CS40 Charging and Communications

Desktop Dock with Spare Battery charging

Provides ActiveSync connection and two battery charging bays.

USB Cable is included with the CS40.

Part Number Description

1 DX1A06E00 Desktop Dock, CS40, no Power Cord (Power Supply Included)

OR DX1A06E10 Desktop Dock, CS40 NA Conﬁguration(with Power Cord and Power Supply included)

2 318-045-001 CS40 Spare Battery Pack (Note, all CS40’s have a battery included)

3 (see price guide) AC Power Cord

Rear View

Can charge up to two

batteries simultaneously

CS40 Charging and Communications

Dual Dock Ethernet

Dual Dock Charge Only

Part Number Description

1 DX2A16600 Dual Dock, Ethernet, CS40, no Power Cord (Power Supply Included)

OR DX2A16610 Dual Dock, Ethernet, CS40 NA Conﬁguration (with Power Cord and Power Supply included)

OR DX2A26600 Dual Dock, Charge Only, CS40, no Power Cord (Power Supply Included)

2 (see price guide) AC Power Cord

Rear View – Ethernet Dock

CS40 Charging and Communications

Quad FlexDock with Ethernet

Quad FlexDock Charge Only

Part Number Description

1 DX4A1666600 Quad Dock, Ethernet, CS40, no Power Cord (Power Supply Included)

OR DX4A2666610 Quad Dock, Ethernet, CS40 NA Conﬁguration (with Power Cord and Power Supply included)

OR DX4A2666600 Quad Dock, Charge Only, CS40, no Power Cord (Power Supply Included)

2 (see price guide) AC Power Cord

Rear View – Ethernet Dock

CS40 Battery Charging Only

4 – Position Charging

Part Number Description

1 DX2A2EE00 4-position Battery Charger, CS40, no Power Cord (Power Supply included)

OR DX2A2EE10 4-position Battery Charger, CS40, NA Conﬁguration (With Power Cord and Power Supply included)

2 (see price guide) AC Power Cord

8 – Position Charging

Part Number Description

3 DX4A2EEEE00 8-position Battery Charger, CS40, no Power Cord (Power Supply Included)

OR DX42A2EEE10 8-position Battery Charger, CS40, NA Conﬁguration (With Power Cord and Power Supply included)

2 (see price guide) AC Power Cord

CS40 – 4-Position Battery Charger

CS40 – 8-Position Battery Charger

Miscellaneous

Holster

Part Number Description

1 815-069-001 Holster with Belt Clip, CS40 Series

Purse with Shoulder Strap

Part Number Description

2 815-071-001 Purse with shoulder strap, CS40

Miscellaneous

Intermec Recommended – ATP Industrial Grade Micro SD Cards

Part Number Description

1 856-065-004 MICRO-SD CARD, 1GB, AF1GUDI, ROHS

OR 856-065-005 MICRO-SD CARD, 2GB, AF2GUDI, ROHS

OR 856-065-006 MICRO-SD CARD, 4GB, AF4GUDI, ROHS

Why ATP Industrial Grade SD?

ATP's SIP (System-In-Packaging) manufacturing process encapsulates all exposed components and points of failure to ensure the products are fully waterproof, shockproof, and ESD (Electro-Static Discharge) proof. ATP Industrial

Grade SD/SDHC Cards can withstand at least an operating/storage temperature range of at least -40 to 85 degrees Celsius. In addition to this temperature range, the cards are completely waterproof, dustproof, and ESD (Electro-

Static Discharge) proof. All ATP Industrial Grade SD/SDHC cards are produced under a stringent RoHs and Green Package compliant manufacturing process to guarantee a consistent high level of build quality and performance.

ATP Industrial SD cards deliver outstanding performance with read speed (seq) up to 18MB/sec and write speed (seq) up to 16MB/sec. All ATP Industrial Grade CF, SD, USB drives, and SSDs are constructed using best-in-class

SLC (Single-Level Cell) components with enhanced Error Correction Code(ECC) functions and wear levelling algorithms. This results in MTBF ratings over 2 million hours and the highest write cycle lifetimes in the industry.
