Invacare Dolomite Jazz 510 Manuale utente

DEALER:Keepthismanual.

TheproceduresinthismanualMUSTbeperformedbyaqualifiedtechnician.

IenI

1General

1.1Aboutthismanual

ThismanualbelongstoanInvacareaccessoryanditcontainsimportant

informationabouthandlingandassembly.Inordertoensuresafety

whenusingtheproduct,readtheusermanualoftherelatedproduct

carefullyandfollowthesafetyinstructions.

Symbolsinthismanual

Inthisusermanual,warningsareindicatedbysymbols.Thewarning

symbolsareaccompaniedbyaheadingthatindicatestheseverityof

thedanger.

WARNING

Indicatesahazardoussituationthatcouldresultin

seriousinjuryordeathifitisnotavoided.

CAUTION

Indicatesahazardoussituationthatcouldresultin

minororslightinjuryifitisnotavoided.

IMPORTANT

Indicatesahazardoussituationthatcouldresultin

damagetopropertyifitisnotavoided.

TipsandRecommendations

Givesusefultips,recommendationsandinformation

forefficient,trouble-freeuse.

Givesinformationabouttherequiredtools.

1.2Generalwarnings

Riskofdamagetotheproduct

Damagetothebrakewires

–Ifneeded,alwaysfoldthecrossbardownwardsto

protectthecablewhentherollatorisnotusedasa

walkingaid.

Riskofdamagetotheproduct

–WhenusingthecrossbaronJazz510,becarefulwhen

openingthecrossbarifthehandlesareadjustedinthe

lowestposition.Thecrossbarcanhitthegroundand

getdamagedwhenopened.

2Assembly

2.1Removingthebrakes

1.LoosenandremovethescrewandsleevenutAandtheplastic

bushingBforthewireholder.

allenkey4mm+10mmfixedspanner

2.LoosenthescrewforbrakepadC.

allenkey3mm

Jazz510/610Crossbar

enWalkingaids

ServiceManual

Jazz510/610Crossbar

3.LoosenthewireDfromthebrakepad.

4.PushtheheightadjustmentbuttonEupwards.

5.LowerthehandleFtothelowestpositioninordertoeasilyget

accesstothewireholderandbrakerod.

6.RemovethewireholderHandthebrakerodI.

7.RemovetheexistingwireJfromthewireprotection.

8.RemovetheemptywireprotectionK.

fixedspanner10mm

9.Repeattheprocedureontheoppositeside.

2.2Mountingthecrossbar

Removingtheexistinghandles

LoosenthescrewandremovetheheightadjustmentbuttonA.

allenkey2,5mm

2.LoosentheadjustmentscrewB.

allenkey3mm

3.LoosenandremovetheattachmentscrewforthehandleC.

allenkey4mm

4.RemovetheexistinghandleD.

5.Repeattheprocedureontheoppositeside.

Mountingthecrossbar

1.MountthecrossbarL.

2.TightenthescrewsforthehandlesE.

allenkey4mm

21582610-A

MounttheadjustmentbuttonDandtightenthescrew.

allenkey2,5mm

TightentheadjustmentscrewsFinordertoremovethefree

playinthehandle.

Makesurethattheheightadjustmentworkssmoothly

afteradjustmentofthescrew.

allenkey3mm

5.Repeattheprocedureontheotherside.

6.TightentheknobG.

7.ThreadthenewwireprotectionMthroughtheframefromthe

rearforktothefront.

Thelongerpartofthewireprotectionmustbethreaded

onthesidewherethecrossbarisopened.Theshorter

partofthewireprotectionisthreadedontheopposite

side.

8.ThreadthenewdoublewireNthroughthewireprotectionsM.

Theupperwiremustbethreadedthroughtheshorter

wireprotectionandthelowerwiremustbethreaded

throughthelongerwireprotection.

9.MountthetopofthedoublewireOintheattachmentP.

Makesurethewireprotectionispushedintothe

attachmentP.

10.MountthewireprotectiontotheframeQ.

fixedspanner10mm

11.MountthewireRinthebrakepad.

12.TightenthescrewS

allenkey3mm

13.Repeattheprocedureontheoppositeside.

14.

AttachthewirestotheframewithcabletiesT.

1582610-A3

Jazz510/610Crossbar

2.3Adjustingthebrakeeffect

WARNING!

Riskofinjury

Poorbrakeeffect

–Alwaysadjustthebrakeeffectaftermountingor

adjustingthebrakesystem.

2-3 mm

1.AdjustthebrakeeffectwiththeadjustmentnutV.

Distancebetweenthebrakepadandthewheelshould

be2–3mm.

fixedspanner8mm+10mm

41582610-A

Notes

InvacareSalesCompanies

Ireland:

InvacareIrelandLtd,

Unit5SeatownBusinessCampus

SeatownRoad,Swords,County

Dublin

Tel:(353)18107084

Fax:(353)18107085

[email protected]

www.invacare.ie

UnitedKingdom:

InvacareLimited

PencoedTechnologyPark,Pencoed

BridgendCF355AQ

Tel:(44)(0)1656776222

Fax:(44)(0)1656776220

[email protected]

www.invacare.co.uk

Manufacturer:

InvacareReaAB

Växjövägen303

SE-34371Diö

Sweden

1582610-A2016-02-22

*1582610A*

MakingLife’sExperiencesPossible™
