Inventus Power SBM-01 Manuale utente

inventuspower.com

info@inventuspower.com

+1 877.423.4242

Inventus Power, Inc.

1200 Internationale Parkway

Woodridge, IL 60517

Designed & Manufactured by

Smart Battery Monitor

User Manual

SBM-01

PROformance Add-On Device

User Manual

Applicable Models

Document Information

Inventus Power® is a trademark of Inventus Power.

Technical Support

If you have any technical questions regarding the PROformance Add-On Device, please

contact our technical support team at:

Phone: +1.877.423.4242

E-mail: tech_support@inventuspower.com

Release Date Revision Scope of Change

2023-03-15 V1.4 Minor edits to V1 release

Model Part Number

U1LiFePROTM Smart Battery Monitor Kit 903-09472-001

PROTRXionTM 48V60-TRX-HD Smart Battery Monitor Kit 903-09472-002

PROTRXionTM 24V80 24V90 36V80 48V60 Smart Battery Monitor Kit 903-09472-003

PROTRXionTM 12V100-TRX-HD 24V60 Smart Battery Monitor Kit 903-09472-004

PROTRXionTM 48V60 (Old Pinout) Smart Battery Monitor Kit 903-09472-005

Contents

Introduction .................................................................................................................................... 4

Safety and Tools ............................................................................................................................ 4

Installation Guide .......................................................................................................................... 5

Operating Guide ........................................................................................................................... 8

Pin Deﬁnition ................................................................................................................................ 10

Mechanical Speciﬁcations ........................................................................................................ 10

Introduction

Thank you for choosing Inventus Power, the leading provider of advanced battery and power

systems for global OEMs.

The SBM-01 is a intelligent battery monitor, speciﬁcally designed to complement Inventus

Power PROformance batteries with an operating voltage range between 9 - 60VDC. With

integrated intelligence, the Smart Battery Monitor can receive data from the battery system

to communicate battery health, critical battery data, as well as indicate low battery capacity

(Limp Home Notiﬁcation), so the system can return safely back to a charging station.

We’ve made the SBM-01 easy to install and intuitive to setup.

• Quick installation and set up

• For step-by-step instructions, refer to this manual for easy-to-follow directions

• Need more help? Contact Tech_Support@inventuspower.com or +1.877.423.4242

Safety and Tools

Before working with any electrical products or where electricity is present, the

following guidelines are required:

• Turn o system power, disconnect battery, and place battery in ship mode

• Proper PPE (Personal Protective Equipment)

• Rubber gloves

• Safety glasses

• Removal of any jewelry

Tools Needed

• Drill and 51mm hole cutter

• Hand saw

• Insulated torque wrench

• Insulated Philips Screwdriver (optional)

• Sandpaper

Mounting Hole

NOTCH TO SECURE MONITOR

(5.5mm WIDE x 4.5mm)

CABLE

ALIGNMENT KEY

(5.14mm x 4.2mm)

CLEARANCE HOLE

(Ø51.7 ± 0.2MM)

1. Insert Smart Monitor threaded body through clearance hole (51.7±0.2mm) using alignment

key with notch (reference note above for creating clearance hole)

2. Secure monitor with nut and tighten to 3 Nm torque

3. Attach 8-pin Cable to Rear of Smart Monitor (reference pages 6-8 for speciﬁc battery model

and wire harness part number)

Note: A hole will need to be cut if the existing panel does not include a 51.7mm diameter hole.

1. Using a drill with a 51mm hole cutter, cut hole (Note: if the SBM-01 cannot be inserted

through the clearance hole easily, the hole can be increased using the sandpaper)

2. Locate top of hole, mark desired location to cut alignment notch

3. Using a handsaw, cut a 5.5mm x 4.5mm notch as shown in above ﬁgure

Installation

Ø51.7±0.2 mm

5.5±0.2 mm 4.5±0.2 mm

Cable Installation

Smart Battery Monitor SKU P/N: 903-09472-003

Applicable Battery Models:

Smart Battery Monitor SKU P/N: 903-09472-005

Reference above image

Applicable Battery Models:

M-48V60-TRX†

S-48V60-TRX†

S-36V80-TRX*

M-36V80-TRX*

S-48V60-TRX*

M-48V60-TRX*

Connection Steps:

1. Connect battery M12 signal port to cable harness

(See battery user manual for proper installation).

2. Connect Smart Battery Monitor to 8-pin connector.

*Proceed to steps 3-5 only if applicable (for 36V and 48V batteries only).

3. Connect 4-pin connector on wire harness to 4-pin connector on ring terminal harness.

4. Connect black wire M8 ring terminal to negative terminal on the battery (See battery user

manual for proper installation).

5. Connect red wire M10 ring terminal to positive terminal on the battery (See battery user

manual for proper installation).

1. Connect battery M12 signal port to cable harness

(See battery user manual for proper installation).

2. Connect Smart Battery Monitor to 8-pin connector.

3. Connect 4-pin connector on wire harness to 4-pin connector on ring terminal harness.

4. Connect black wire M8 ring terminal to negative terminal on the battery (See battery user

manual for proper installation).

5. Connect red wire M10 ring terminal to positive terminal on the battery (See battery user

manual for proper installation).

† This SKU is compatible only with older models of S/M-48V60-TRX (MFG Date before March 1, 2023) where pin 6 is auxilary

power

Not to scale

1.8m1.8m

S-24V80-TRX

M-24V80-TRX

S-24V90-TRX

M-24V90-TRX

Smart Battery Monitor SKU P/N: 903-09472-002

Applicable Battery Models:

M-48V60-TRX-HD

S-48V60-TRX-HD

1. Connect battery signal port to cable harness (See battery user manual for proper installation).

2. Connect Smart Battery Monitor to 8-pin connector

1 2

2.0m2.0m

Not to scale

Smart Battery Monitor SKU P/N: 903-09472-004

Applicable Battery Models:

S-12V100-TRX-HD

M-24V60-TRX

S-24V60-TRX

Connection Steps:

1. Connect battery M12 signal port to cable harness

(See battery user manual for proper installation).

2. Connect black wire M8 ring terminal to negative terminal on the battery (See battery user

manual for proper installation).

3. Connect red wire M8 ring terminal to positive terminal on the battery (See battery user

manual for proper installation).

4. Connect Smart Battery Monitor to 8-pin connector.

1.8m1.8m

Not to scale

Smart Battery Monitor SKU P/N: 903-09472-001

Applicable Battery Models:

M-12V40-U1

S-12V40-U1

M-24V20-U1

S-24V20-U1

1. Connect battery RJ-45 signal port to cable harness

(See battery user manual for proper installation).

2. Connect black wire M6 ring terminal to negative terminal on the battery (See battery user

manual for proper installation).

3. Connect red wire M6 ring terminal to positive terminal on the battery (See battery user

manual for proper installation).

4. Connect Smart Battery Monitor to 8-pin connector.

1.8m1.8m

Not to scale

Operating SBM-01

1. Display

2. MODE Button

• Activates display while in shutdown or sleep mode

• Shuts down monitor when pressed for 3 secs

• Toggle between Home Screen and Status Screen

Once the monitor is installed, powered up, and establishes communication with the battery, the

Startup Screen will be displayed for 3 seconds, followed by the Home Screen. To shutdown the

monitor, hold the MODE button for 3 seconds.

The monitor will go to sleep after 5 minutes of battery inactivity and the display will turn o. To

activate the display, tap the MODE button.

Note: Reference Battery User Manual and Battery Software User Guide for more information

on fault codes displayed by the Smart Battery Monitor.

Get To Know Your Smart Monitor Display Settings

Startup Screen Home Screen Status Screen

• Battery State of Health

displayed for 3 seconds

• Battery charging icon

(only in charge mode)

• State of Charge (%)

• Battery Runtime Remaining

• Battery Voltage (V)

• Battery Fault Alert (only

appears when there is a fault)

• ERROR: Battery Fault Code

• BATT TEMP: Battery

Temperature (°C)

• LIFE AH USED: Cumulative

lifetime discharge capacity

(Ah)

• CURRENT: Charge/Discharge

Current (A)

• SW VER: Battery Software

Version [BQ, ATSAM, SBM-01]

Battery Sleep Screen Limp Home Screen

• Indicates the battery is in

Sleep Mode.

• Operate the system to wake

up the battery and re-

establish communication with

the Smart Battery Monitor.

• Indicates the battery has low

State of Charge and should

be charged.

Connector Pin Deﬁnition

Pin Signal Description

1 CANH CANbus high signal

2 CANL CANbus low signal

3 Aux Power Auxiliary Power

4 Ground Ground

5 B+ Battery Positive

6 B- Battery Negative

7 Sense - Sense Negative

8 Sense + Sense Positive

PIN 8

PIN 4

PIN 5

PIN 1

Mechanical Dimensions (SBM-01)

All dimensions are in millimeters. For tolerances and inches, please reference datasheet.

Need More Help?

Contact Tech_Support@inventuspower.com

+1.877.423.4242

19.4

(VIEWING AREA)

29.0

(VIEWING AREA)

7.4 30.0

56.000

43.1

51.2

4.9

4.3

UNRELEASED DRAFT

FOR PROTOTYPING ONLY

REVISIONS

REV.

DESCRIPTION

DATE

ECN

AUTHOR

CHECKED

CREATED

DATE

NAME

SIZE

PART NO.

REV

1 OF 1

SCALE: 1:1

UNLESS OTHERWISE SPECIFIED:

THIS DOCUMENT AND ANY ASSOCIATED DATA CONTAIN

CONFIDENTIAL, PROPRIETARY INFORMATION THAT IS

INVENTUS POWER PROPERTY. DO NOT DISCLOSE TO OR

DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY

INVENTUS POWER.

4/29/2022

DIMENSIONS ARE IN

TOLERANCES:

Description

INTERPRET GEOMETRIC TOLERANCING

PER: ASME Y14.5M-2018

THIS DOCUMENT MAY CONTAIN U.S. EXPORT CONTROLLED TECHNICAL DATA AND/OR TECHNOLOGY. U.S. GOVERNMENT APPROVAL

MAY BE REQUIRED PRIOR TO DISCLOSURE TO NON-U.S. PERSONS, (WHEREVER LOCATED); OR AS AUTHORIZED BY U.S. LAW AND

REGULATIONS.

sbm-01-rENDER-DRAWING

eli.goldin - 11/11/2022 12:27:13 PM

DECIMALS

ANGLE

EXPORT CONTROL

ROHS CERTIFICATION

REQUIRED WITH

DELIVERY

REACH

CERTIFICATION

REQUIRED WITH

DELIVERY

MATERIALS USED IN

THIS PART MUST BE

CONFLICT FREE

MINERALS

PROJECTION

DESCRIPTION:

CROSS REFERENCE PART NO.

X X

N/A
