Involve Audio Amp Master - 6ch Scheda tecnica
123 4 5 6
Amp Master - 6 channel
EQ EQ
Amp Master - 6ch
Quick Setup - AMP-6CH-1
WARNING: To reduce the risk of re or electrical shock, do not expose the product to rain or moisture.
WARNING: The apparatus shall not be exposed to dripping or splashing, and objects lled with liquids, such
as vases, shall not be placed on the apparatus. As with any electronic products, use care not to spill liquids
into any part of the system. Liquids can cause a failure and/or a re hazard.
WARNING: No naked ame sources, such as lighted candles, should be placed on any part of the system.
These CAUTION marks are located on your Surround Master V3 enclosure:
The lightning ash with arrowhead
symbol within an equilateral triangle
alerts the user to the presence of
uninsulated, dangerous voltage within
the system enclosure that may be of
sucient magnitude to constitute a
risk of electrical shock.
PLEASE NOTE : THERE ARE NO USER SERVICEABLE COMPONENTS CONTAINED WITHIN THE AMP-6CH-1
The exclamation point within an
equilateral triangle, as marked
on the system, is intended to
alert the user to the presence
of important operating and
maintenance instructions in this
owner’s guide.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AUSTRALIAN DESIGNED
AND MANUFACTURED Computer programs embodied in this equipment
Copyright Involve Audio 2014
AMP-6CH Amp Master - 6ch Quick Setup V1.0 © 2022 Involve Audio Pty Ltd All Rights Reserved | www.involveaudio.com
Front Panel
ON/OFF
OFFON
SOFT CLIP
Clipping No Clipping
WOOFER EQ
Active Inactive
Involve
Woofer EQ
123 4 5 6
Amp Master - 6 channel
EQ EQ
AMP-6CH Amp Master - 6ch Quick Setup V1.0 © 2022 Involve Audio Pty Ltd All Rights Reserved | www.involveaudio.com
Connections & Setup
30V DC
3
2
1 5
4
246
135
EQ
woofer
65,6
-
EQ
6EQ
Amp Master | 6 Channel Class D - 120W RMS 2Ω per channel | Ch 5 & 6 switchable involve woofer EQ
30V DC
3
2
1 5
4
246
135
EQ
woofer
65,6
-
EQ
6EQ
Amp Master | 6 Channel Class D - 120W RMS 2Ω per channel | Ch 5 & 6 switchable involve woofer EQ
POWER - DC 30V 6A
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
Power
Outlet
Power
IN
RCA INPUT
30V DC
3
2
1 5
4
246
135
EQ
woofer
65,6
-
EQ
6EQ
Amp Master | 6 Channel Class D - 120W RMS 2Ω per channel | Ch 5 & 6 switchable involve woofer EQ
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
Pre-amp
POWER - DC 30V 6A
Push stripped wires into
plug. Match polarity with
your speaker
Tighten screws to
grip wires
Push plug into
speaker socket
30V DC
3
2
1 5
4
246
135
EQ
woofer
65,6
-
EQ
6EQ
Amp Master | 6 Channel Class D - 120W RMS 2Ω per channel | Ch 5 & 6 switchable involve woofer EQ
WOOFER EQ
No EQ
active
EQ active on
Channels 5 & 6
EQ active on
Channel 6
Many thanks for purchasing your Amp Master - 6ch, we hope it brings
you many hours of listening enjoyment.
Happy Listening!
© 2021 Involve Audio Pty. Ltd. All Rights reserved
Involve audio and Involve are registered trademarks of Involve Audio Pty Ltd.
AMP-6CH Amp Master - 6ch Quick Setup V1.0
