inVue NB80 Manuale utente
1
Netbook Security should fit
7” – 11” screens
NB80 | OM Netbook Security
security inspired by innovation
2
3
adjustment screws*
mounting screws*
washers
hex nuts
OM Key
Multi Tool
5
10
20
30
PARTS REQUIRED (not included)
7/32"
(5.5 mm)
SFKEYNDRL
or
SFKEYRFRL
AF6313
AF6315
(not included in the Multi Tool,
must be purchased separately)
security base
security arms
wrench
H.S. Bit
GETTING STARTED
* IMPORTANT: Tighten all screws extremely tight.
CAUTION: Driver bit and screws engage in only one position. Verify that driver bit is properly inserted before use.
4
Tighten mounting screws with InVue H.S. Bit
while holding hex nuts in place with a wrench.
SECURING MERCHANDISE
2 3
Loosen both adjustment screws with the InVue H.S.
Bit and slide apart the security arms.
54
1
Insert the mounting screws in the base.Remove the security base and drill the holes
with a 7/32” (5.5 mm) drill bit.
Locate the security base on the fixture and mark
the two screw holes.
5
SECURING MERCHANDISE
8 9
76 Tighten both adjustment screws on the security
arm with the InVue H.S. Bit.
Slide the security arms onto the netbook and
tighten around the netbook. Leave a small gap
approx. 1/16” (1.5 mm) between each security arm
and the netbook.
Attach security arm to the security base. You will
hear a slight “click.”
* IMPORTANT: Tighten all screws extremely tight.
CAUTION: H.S. Bit and screws engage in only one position. Verify
that driver bit is properly inserted before use.
6
Unlock the security arm with the OM Key.
UNLOCKING MERCHANDISE
2 3
1
CUSTOMER SERVICE
North America // 888.55.INVUE
Europe // +31.23.8900150
Asia // +65.6766.4844 SD0036 Rev 06/28/2010
