iodd ST Series Manuale utente
IODD ST/LK
QuickGuide
Supported features
XX4XX
●
●
●
●
●
●
Products
Virtual Drive
Encryption
Admin Mode
Write Protect
WinToGo
Adm
XX3XX
●
●
●
XX1XX
●
●
●
●*1
●
※ For ST/LK series, only 2.5-inch and 7mm or
smaller drives can be installed.
※ Encryption function must be [Administrator]-[User]
[2nd Password] thoroughly read the contents and
use it.
Guide Firmware / Software Download
http://dir.iodd.kr/
●*1WTG only as a physical drive.
SPECIFICATIONS
Encryption
Display
Input method
Support Drive Size
Size
Weight
material
Internal interface
External interface
Power
Supported file
Supported OS
TRIM/UAS function
● The function is only
for supported models
●
●
AES256-XTS Max. 38*2(76) digits
128x160 TFT LCD
Tact-Switch
2.5 inches (7mm or less)
80 (width) × 140 (length) × 14 (height) mm
100g
Plastic, acrylic
SATA2/SATA3 (sub-compatible)
USB-C (USB 3.1 Gen 1)
DC +5V USB power
ISO/VHD/RMD/VMDK/IMA
Win 7 and above, OSX 10 and above
Unsupported.
●
AES256-XTS BLOB encryption (up to 78 digits)
●
Bootable virtual ODD (CD/DVD/Other)
●
Bootable virtual HDD and USB drive
●
Administrator Mode / Text Viewer (ASCii/USC-2(UTF-16))
Windows-To-Go / Write Protection/ Remove safety
Multilingual / Built-n Help Key / Hotkey /OTG
Keys
File/Menu Browsing
Function Keys
Long key ( push for 3 seconds )
Start-Up keys (during startup)
File/List
UP Down
View file information
Display full name, size,
and fragmentation information of the file
work only in the text viewer
Tooltip
A description of the current menu
/ error message
Select a
File/Menu/*.txt File
Enter to Menu(or Exit)
Reconnect to PC
Unmount all
Virtual drives(VHD/ISO)
Safe Removal.
(ISO loading state is save)
Reconnect to PC with
write-protected state is toggled.
Partition selection
*Only works when unmount
all virtual drives
Reconnected with
temporarily Write Protection disabled
Go to Upper
Folder / Menu
Refresh
File list
Instantly save
Instantly saves the
current virtual drive state.
Page Down
Txt Viewer PGDN
Connected with
Unmount all virtual drives(ISO, VHD)
Reset to
factory settings
Starts with
Write Protection
Enter to menu
without connecting to PC
Displays startup key info.
without connecting to PC
Disk Status
VBUS min.voltage/drive temp/health info
Page Up
Txt Viewer PGUP
Unmount the
most recently
mounted virtual drive
UI Info
Status Icons
Mount Information Area
File List Area
Status of the device
Icon Description
Status Icons
Mount information Area
File list Area
Inform active ISO / VHD / RMD and settings.
● List folders and available files in the selected directory
●To use another partition,
Unmount all virtual drives and press button 4 for 3 seconds
to enter the [partition selection] .
windows10.iso
VHD_01_DATA
BACKUP VHD
OS
UTIL
Photobook.iso
linuxmint-17.3-cinn
Ubuntu-14.04.4.de
RMD_01_WTG
physical drive write-protect enable/disable status
Write-protect all (including virtual drives) disks
(Red)
/
Mount / unmount status of the ISO file/
Mode status (CD / DUAL / HDD)/ /
Power status (timer / sleep mode)/
AES256 encryption On
USB connection speed (3.0 / 2.0 / 1.1)/ /
/Inform write protection on / off status (VHD/RMD)
Inform mounted file name (ISO/VHD/RMD)Filename.iso
Inform status of the virtual drive (removable / fixed)/
■ Virtual Drive Function XX4XX
XX3XX
Mode Setting
● One virtual ODD / three VHDs (or RMDs) can be mounted
at the same time.
● At the first time, automatically finds mountable files on the
largest partition (GPT / MBR, NTFS / exFAT / FAT32)
You can select default partition (button 4 in the file list area)
● The advanced mode manager handles the settings
of individual virtual drives.
Press the button and select the [Mode setting] Menu.
Mode setting
To exit menu mode,
press the button and the settings is saved.
※ If any options change in the Mode Manager, the device reboots and
all currently mounted virtual drives are unmounted (ISO/VHD/RMD)
※ The drive order in menu may be same the
Virtual Drives Information Area of IODD.
//
5 - ,6-
---Disabled---
set the options of the selected (▶) drive.
Use the 5 button to enable / disable
the write protection function.
Use the 6 button to toggle
removable disk / fixed disk
You can change the order with the 3/9
buttons.The inactive bar can be moved.
Drives that are below the --Disabled--
Item are inactived.
1.Configure options for the selected
2. Configure the number of drives
and drive's order.
TXT Viewer
Keep Password 2 min
Write Protect
XX4XX
XX1XX
● TXT format file can be opened with IODD's built-in viewer.
● If used with encryption,safely view password-related text data.
In the TXT file item on the file list screen, press the or key.
● Users don't have to re-enter your password only once
within 2 minutes after entering the password.
● It reduces the number of times to enter a password for
installation work that requires a reboot.
● If two minutes have passed since you entered the password,
or when you reboot for the second time within 2 minutes,
you must re-enter the password.
1. Press the Menu button to enter the menu screen
and select [USB Control]
2. Check or uncheck the [□Keep P.W 2min] item
Feature enable/disable
● Use the disk write-protect feature to protect your disk.
In addition to menu access, function buttons (press button
for 3 seconds) or it can be activated by the start button
( button when connected).
1. Press the Menu button to enter the menu screen
and select [USB Control]
2. Check or uncheck the [□Write Protect] item
Feature enable/disable
■Encryption & Admin XX4XX
XX1XX
● New IODD Series uses AES256-XTS encryption.
● There is no need to install a driver for encryption.
● Available for all operating systems.
● The length of the password is 4 to 38 digits(2nd Password is Same)
● Security is further strengthened with random keypad.
Enhanced Encryption
2nd Password(2nd P.W)
Admin mode
Users
IODD Admin Manager(Windows Application)
New IODD has an AES256bit-XTS up to 38-digit double encryption
and an administrator Mode so that multiple users
(administrator*1/user*4) can use one device together.
2nd password is required when setting a password on the drive and when
installing a drive with a password already set to another IODD ST/LK. Up to 38 digits
can be entered.
If lost, the password cannot be retrieved or recovered in any way
This password is used only by administrator.
If there are multiple users using the same ST/LK, you can use the administrator
mode to set individual users' passwords and drive permissions.
Administrators can reset a user's password at any time.
Only administrators can unencrypt the entire device.
Up to 4 users, excluding administrators, are set as users,
Users can use internal data within the authority specified by the administrator.
When permission is granted, the user's password can be changed.
It is an application that allows the administrator function to be used on a PC.
It has the same functions as the main body of IODD,
and the password configuration file management function is added to make
it easier to manage multiple users and passwords.
● If the administrator's password is changed, all user accounts will be deleted.
● When an administrator sets or deletes an administrator's password,
all data on the disk is initialized and all user accounts are deleted.
1. Press the Menu button to select the [Encryption] [Admin] menu.
1.1 When setting the first password, select the [Set 2nd P.W.] menu and set the 2nd P.W
2. Select the [SetEncyrption] menu. Check the notification that all data inside will be deleted.
3. Enter the administrator password twice (4 - 38 digits)
3.1 The administrator sets the first digit of the password to zero.
4. Wait for a while to finish setting up admin encryption.
5. When IODD is reconnected, the 0+administrator password set in step 3 is requested.
ex) 0 55447788
1. Press the Menu button to select the [Encryption] [Admin] menu.
2. Select the [Remove Encryption ] menu. Check the notification that all data inside will be deleted.
3. Enter the administrator password once (4 - 38자리 숫자)
4. Wait for a while to finish Remove admin encryption.
Admin | Set admin Password
Admin | Remove Admin Password
1. Press the Menu button to select the [Encryption] [Admin] menu.
2. Select the [Chg Password] menu. Check the notification [All user passwords Will be deleted]
If the Admin password is changed, all user passwords are deleted, and a new user
password must be set in Admin mode.
3. Enter the Old administrator password once (4 - 38 digits)
4. Enter the New administrator password Twice (4 - 38digits)
Admin | Change Admin Password
■ AES256 Encryption(Admin)
user identification number(Admin 0/Users 1-4)
Password (Max 37 Digits)
XX4XX
XX1XX
※ When setting/deleting the administrator password,
all data on the IODD drive is initialized.
※ Even if you forgot the administrator password, you can initialize the installed
drive and use it. Initialize the disk initialization method as MBR->GPT->MBR.
Please note that all existing data will be deleted.
※ If the 2nd password is lost, the encrypted drive cannot be used for
another IODD. It is impossible to access, so be careful not to lose it.
Notes on Encryption
Admin's User Management
● Administrators can set individual passwords for up to 4 users
and manage disk permissions
1. Press the Menu button to select the [Encryption] - [User] menu.
2. Enter 0+admin password.
3. Select the users to manage.
4. When you have finished setting, press the [ < 4 ] button to return
to the previous menu.
5. Select [Save Users].
5.1 If you exit the menu without selecting the [Save Users] menu,
Changed settings are not applied.
admin | User management
User-1
Set Password >
Del Password
□ Read Only
□ User Change
□ User Delete
A user password is a user identification (account)
number (1-4) fixed at the beginning of the password.
Read-only
The user cannot delete or change data on
the device's internal drive.
User Change
Users can change their user password arbitrarily.
Administrator can remove all user passwords.
User Delete
That user can delete their own user password.
The user account is also deleted.
1. Set or remove a user password.
2. Set the user's permission.
● The user's authority is set by the administrator.
● The user's initial password is set by the administrator.
● Even if the user changes or deletes the password,
the data inside the drive is maintained.
● Administrator can change/delete passwords of all users.
Encryption for User
Allow password change/delete
Encryption
Change Password >
Delete Password
Users can change or remove passwords
for their accounts.
Removing the password also deletes the account.
Allow Password Change
Allow Password Delete
Encryption
Change Password > Users can only change their password.
Encryption
Delete Password
Users can remove passwords
Removing the password also deletes the account.
Users will not be able to activate the [encryption] menu.
Change/Delete Password Not Allowed
1. Press the Menu button to select the [Encryption] menu.
Only menus that the user can set are displayed.
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali iodd Allegato
