IPC Gansow CT15 Series Manuale utente
CT15 - CT30 - CT15 ECS - CT45
Lavamatic 360 - Lavamatic 460
Lavamatic 15 - Lavamatic 30
Lavamatic 45
MANUALE ISTRUZIONI PER L’USO /
OPERATOR’S MANUAL / MANUELD’INSTRUCTIONS /
BEDIENUNGSANLEITUNG /
MANUALDE INSTRUCCIONES / BRUKERHÅNDBOK /
GEBRUIKERSHANDLEIDING / MANUALDE UTILIZAÇÃO /
,16758.7,216%2.ɆȺɒɂɇȺȾɅəɆɈɃɄɂɂɋɍɒɄɂɉɈɅɈȼ
/ KULLANIM KILAVUZU / 㠚ࣘ⍇ൠ䖖䈤᰾Җ
Consultare attentamente questo manuale prima di procedere a qualsiasi intervento sulla macchina
Read this manual carefully before carrying out any work on the machine
Lire attentivement ce manuel avant toute intervention sur la machine
Vorliegendes Handbuch vor jedem Eingriff an der Maschine aufmerksam durchlesen
Consulte detenidamente este manual antes de llevar a cabo cualquier trabajo en la máquina
Konsulter denne håndboken nøye før du går i gang med noen som helst type inngrep på maskinen
Raadpleeg deze handleiding aandachtig alvorens met enige werkzaamheid aan de machine te beginnen
Consulte atentamente este manual antes de efectuar qualquer intervenção na máquina
Läs noggrant igenom denna handbok innan du utför något som helst ingrepp på maskinen
ȼɧɢɦɚɬɟɥɶɧɨɨɡɧɚɤɨɦɶɬɟɫɶɫɞɚɧɧɨɣɢɧɫɬɪɭɤɰɢɟɣɞɨɩɪɨɜɟɞɟɧɢɹɥɸɛɨɣɪɚɛɨɬɵɫɦɚɲɢɧɨɣ
0DNLQHLOHKHUKDQJLELULúOHP\DSPDGDQ|QFHEXNÕODYX]XGLNNDWOHRNX\XQ
ᔰ֯⭘ᵪಘѻࡽˈ䈧࣑ᗵԄ㓶䰵䈫↔֯⭘䈤᰾Җ
GB
ENGLISH
(Translation of original
LQVWUXFWLRQV
2
CT15 TECHNICAL SPECIFICATIONS...................................................................4
CT30 TECHNICAL SPECIFICATIONS...................................................................6
CT45 TECHNICAL SPECIFICATIONS...................................................................8
MACHINE DIMENSIONS.......................................................................................10
6$)(7<6<0%2/6...............................................................................................12
%DWWHU\FKDUJHU.....................................................................................................13
)LJXUH.....................................................................................................................14
GENERAL INFORMATION....................................................................................20
Scope of the manual.....................................................................................................................20
Identifying the machine.................................................................................................................20
Documentation provided with the machine...................................................................................20
TECHNICAL INFORMATION.................................................................................21
General description.......................................................................................................................21
Legend..........................................................................................................................................21
Danger zones................................................................................................................................21
Accessories...................................................................................................................................21
6$)(7<,1)250$7,21 .......................................................................................21
Safety regulations .........................................................................................................................21
HANDLING AND INSTALLATION.........................................................................23
Lifting and transporting the packaged machine ............................................................................23
Checks on delivery........................................................................................................................23
Unpacking.....................................................................................................................................23
Power supply batteries (battery models).......................................................................................24
Batteries: preparation....................................................................................................................24
Batteries: installation and connection............................................................................................24
Batteries: removal.........................................................................................................................25
Battery charger (battery models)...................................................................................................25
Choosing a battery charger (machines without ON-BOARD battery charger)..............................25
Preparing the battery charger .......................................................................................................25
Lifting and transporting the machine.............................................................................................25
PRACTICAL GUIDE FOR THE OPERATOR.........................................................25
Controls - Description....................................................................................................................25
Mounting and adjusting the squeegee..........................................................................................26
To move the machine, proceed as follows:...................................................................................27
Mounting and changing the brush/drive disks...............................................................................27
Detergents - Instructions...............................................................................................................27
Preparing the machine for work....................................................................................................28
Working.........................................................................................................................................28
At the end of work:........................................................................................................................29
Some useful tips to get the most from your scrubber drier ..........................................................29
Carpet cleaner accessory .............................................................................................................29
Combi accessory...........................................................................................................................29
Draining the dirty water.................................................................................................................30
Draining the clean water ...............................................................................................................30
3(5,2'62),1$&7,9,7< ....................................................................................30
%$77(5<0$,17(1$1&($1'&+$5*,1* ......................................................30
MAINTENANCE INSTRUCTIONS.........................................................................31
Maintenance - General rules.........................................................................................................31
Routine maintenance....................................................................................................................31
Squeegee blades: replacing .........................................................................................................31
Fuses: replacement (battery models) (Fig. L)...............................................................................32
)XVHVUHSODFHPHQWFDEOHPRGHOV¿J0..................................................................................32
Routine maintenance....................................................................................................................32
Six monthly operations..................................................................................................................32
TROUBLESHOOTING ..........................................................................................33
How to resolve possible problems ................................................................................................33
GB
CT15 TECHNICAL SPECIFICATIONS
CT15 B CT15 ECS CT15 C CT15 B R CT15 C R
Cleaning width mm 355 360 360
Squeegee width mm 450 430 430
Cleaning capacity per hour m2/h 1300 1300 1300
Number of brushes n° 1
Brush diameter mm 355 100
Maximum brush pressure g/cm2/
Brush rotation speed g/1° 140 600 140 1120 820
Brush motor power W 200 450 250 250 370
Drive motor power W /
Maximum speed Km/h /
Suction motor power W 550 200 400 550 400
Solution tank L 15
Dirty water tank L 16,5
Rear wheel diameter mm 250
Maximum slope % /
Gross weight Kg 95 95 52,5 74,5 69,5
Transported weight Kg 36 36 15 36 15
Number of batteries n° 2 2 / 2 /
Battery voltage V 12 12 / 12 /
Individual battery capacity Ah (5h) 29 / 29 /
Power system voltage V 24 24 110-240 24 110-240
Machine dimensions mm X=790
Z=1180
Z1=690
Y=468
X=750
Z=1180
Z1=690
Y=435
X=750
Z=1180
Z1=690
Y=435
Battery compartment dimensions
(length, width, height) mm 205x265x205 / 205x265x
205 /
Packed size (length, width, height) mm 800x450x640 900x610x960
Sound pressure LpA
(dB) 68 68 70 72 74
Measurement uncertainty K
(dB) /////
Vibration level (hand) HAV
m/sec2 111,11,61,6
Measurement uncertainty, k m/sec2 0,5 0,5 0,5 0,8 0,8
4
GB
Vibration level (body) HBV
m/sec2 /////
Measurement uncertainty, k m/sec2 /////
Maximum water and detergent
temperature °C 4 - 55
Battery charger
V 100 - 240 / 100 - 240 /
Hz 50 - 60 / 50 - 60 /
Power supply frequency Hz / / 50 - 60 / 50 - 60
Power supply V 24 24 115
110 - 240 24 115
110 - 240
Rated power W 750 650 650 800 770
Rated current A 31 27 5,6
2,8 33 6,7
3,3
Data subject to variation without warning.
5
GB
CT30 TECHNICAL SPECIFICATIONS
CT30 B CT30 ECS CT30 C
Cleaning width mm 455
Squeegee width mm 545
Cleaning capacity per hour m2/h 1670
Number of brushes n° 1
Brush diameter mm 455
Maximum brush pressure g/cm2/
Brush rotation speed g/1° 140 600 140
Brush motor power W 350 350 400
Drive motor power W /
Maximum speed Km/h /
Suction motor power W 550 200 400
Solution tank L 28
Dirty water tank L 30
Rear wheel diameter mm 250
Maximum slope % /
Gross weight Kg 126 126 81
Transported weight Kg 76 76 28
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 24
Machine dimensions mm X=850
Z=1220
Z1=745
Y=568
Battery compartment dimensions
(length, width, height) mm 240x330x220 /
Packed size (length, width, height) mm 900x610x960
Sound pressure LpA
(dB) 69 / 79,6
Measurement uncertainty K
(dB) ///
Vibration level (hand) HAV
m/sec2 1/1,1
Measurement uncertainty, k m/sec2 0,5 / 0,5
6
GB
Vibration level (body) HBV
m/sec2 ///
Measurement uncertainty, k m/sec2 / / /
Maximum water and detergent
temperature °C 4 - 55
Battery charger
V 100 - 240 /
Hz 50 - 60 /
Power supply frequency Hz / / 50 - 60
Power supply V 24 24 115
110 - 240
Rated power W 900 / 800
Rated current A 37,5 / 7
3,7
Data subject to variation without warning.
7
GB
CT45 TECHNICAL SPECIFICATIONS
CT45 B CT45 BT CT45 C
Cleaning width mm 500
Squeegee width mm 730
Cleaning capacity per hour m2/h 1750
Number of brushes n° 1
Brush diameter mm 500
Maximum brush pressure g/cm2/
Brush rotation speed g/1° 160 140
Brush motor power W 400 450
Drive motor power W 180
Maximum speed Km/h 3,5
Suction motor power W 550 400
Solution tank L 40
Dirty water tank L 45
Rear wheel diameter mm 250
Maximum slope % /
Gross weight Kg 140 145 105
Transported weight Kg 88 88 40
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 24
Machine dimensions mm X=980
Z=1290
Z1=806
Y=715
Battery compartment dimensions
(length, width, height) mm 265x335x255 /
Packed size (length, width, height) mm
Sound pressure LpA
(dB) 69 / 80
Measurement uncertainty K
(dB) ///
Vibration level (hand) HAV
m/sec2 1/1
Measurement uncertainty, k m/sec2 0,5 / 0,5
8
GB
Vibration level (body) HBV
m/sec2 ///
Measurement uncertainty, k m/sec2 / / /
Maximum water and detergent
temperature °C 4 - 55
Battery charger
V 100 - 240 /
Hz 50 - 60 /
Power supply frequency Hz / / 50 - 60
Power supply V 24 24 115
110 - 240
Rated power W 950 1130 850
Rated current A 39,5 47 7,4
3,7
Data subject to variation without warning.
9
GB
MACHINE DIMENSIONS
X-Y-Z: See “TECHNICAL SPECIFICATIONS” table
YX
Z
Z1
YX
Z
Z1
10
